User Guide
The most complete solution for water damage prevention
Since 2014, Water-Protec has aimed to protect its clients' living
environments from water damage, in the easiest and most
comprehensive way possible. The equipment is designed to protect
against water damage by shutting off the water supply to the home
in case of water detection. In the event that the sensors installed at
Warranty
Water-Protec products are manufactured according to the highest quality standards in the industry. This is
why Water-Protec offers the owner of a system a 5-year warranty on the stainless steel actuator and valve,
2 years on parts including the control panel, the sensors, the wired sensors, the remote control and the
adapter and 1 year on the installation performed by our Water-Protec certified network, from the original
date of purchase or installation.
If a part is proven to be defective during the warranty period, Water-Protec will provide, free of charge, the
parts necessary to restore the system to working order. A proof of purchase (sales invoice) must accompany
any warranty claim. Defects or damage caused by the use of parts other than original Water-Protec parts are
not covered by this warranty.
Please note that the warranty does not include damage caused by improper installation or improper use of
the product. In this case, labour or replacement of parts will be at the owner's expense.
For a claim request, please first contact our technical service at the number at the bottom of the page.
They will then guide you through the process of sending the defective part with a Return Merchandise
Authorization (RMA) number, or by email at: orders@water-protec.com
1 833 487-7997

Thanks

Thank you for choosing Water-Protec. We want to offer you the best product that protects you from
water damage and we want to give you peace of mind. We invite you to read this guide carefully. It
contains useful information about the system.
1, avenue Liberté, Candiac (Québec) J5R 3X8 - Bureau : 1 866 724-8071
strategic locations detect the presence of water, a signal is quickly
transmitted to the control panel which activates the electronic
valve(s), thus preventing any excessive damage that could have been
caused by the water leak.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E 2.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Water Protec E 2.0

  • Page 1 User Guide Thanks Thank you for choosing Water-Protec. We want to offer you the best product that protects you from water damage and we want to give you peace of mind. We invite you to read this guide carefully. It contains useful information about the system.
  • Page 2 Live with peace of mind Contenu de base Valve : A smart stainless steel valve is installed at the main water inlet and will automatically shut off water supply if sensors detect a leak. This valve can handle a pressure of 150 Psi and it is a full port valve. Control Panel : This panel gives you access to the main control functions of the system.
  • Page 3 Our system is designed in Canada and is recognized by most insurers Getting ready First, check the content of the box: make The sensors are powered The sensors are powered by two 3V sure all parts are present and that you by two 3V batteries.
  • Page 4 Live with peace of mind Installation de la valve Now that all the preparation is done and that the sensors are We recommend that correctly synchronized and identified, you can install the valve. the valve be installed First, find an installation point for the valve. It must be located by a certified plumber immediately after the residence’s main water supply and, where applicable, before the junction of the outdoor sprinklers.
  • Page 5 Our system is designed in Canada and is recognized by most insurers WiFi Setup Mode You can choose to connect your system to the Internet. This allows you to view its status from a secure portal and receive notifications by email or text message. It is also possible to share your system status with other users. To enter Wi-Fi mode, press and hold the Cancel button for...
  • Page 6 Live with peace of mind Alarms with valve closure and audible warnings without valve closure Cancel LEDs are green when the sensor status is normal. The button sensor has not been in motion for 1 minute). The auto-reset delay can be used to silence an active audible alarm. The audible alarm depends on the type of alarm.
  • Page 7 Our system is designed in Canada and is recognized by most insurers Procedure following a water detection alarm If one of the sensors detects water, the system will close the water inlet valve and audible alarm will sound for 15 minutes. Cancel To stop the audible alarm, press the button on the control panel.
  • Page 8 Live with peace of mind Connection to the alarm system 1-2 : Alarm IN Alarm relay 3-4 : Alarm OUT (NO) The alarm relay connects the NO/NC 4-5 : Alarm OUT (NC) (Normally Open - Normally Closed) contacts 6-7 : Low battery signal 1 2 3 4 5 6 7 to the alarm system.
