- Page 1 2.4GHz 2 Channel Radio Control System Model: SR2S www.absima.com...
- Page 2 Model: SR2S 2.4GHz 2 Channel remote system You also can contact our service center: www.absima.com...
-
Page 3: The Special Symbols
Model: SR2S 2.4GHz 2 Channel remote system 3. The special symbols Do not use this product in bad weather such as rainy or thundering to assure the safety of you and others. Before you use the product, please make sure the movement of server are corresond with the direction of joystick. -
Page 4: Transmitter Parameters
Model: SR2S 2.4GHz 2 Channel remote system 5. Transmitter parameters Channels: 2 Frequency band: 2.4GHz Power resource: 1.5V*8 „AA“ battery Program type: AFHDS Modulation type: GFSK RF power: <20 dbM Static current: <250mA Size: 189x97x218mm Weight: 575g Color: black Antenna length: 26mm 6. -
Page 5: Each Part Of The Transmitter
Model: SR2S 2.4GHz 2 Channel remote system 7. Each part of the transmitter Throttle/Brake Steering stick Stick Throttle/Brake Trim Steering trim Power inidcator light Power switch BIND knob Battery Battery cover... -
Page 6: Receiver And Servo Connection
Model: SR2S 2.4GHz 2 Channel remote system 8. Receiver and servo connection Channel 1: Steering servo Channel 2: Speed controller Channel 3: Battery connection for gas powered models BIND/VCC: BIND process... - Page 7 Model: SR2S 2.4GHz 2 Channel remote system 9. 2.4GHz Operation notes It use digital transmission mode, and this prevent outside interference effective active and passive. 9.01 Matching (code) Our products are well matched in the factory, you don´t need to match by yourself. If you...
- Page 8 Model: SR2S 2.4GHz 2 Channel remote system Switch on 9.03 Switch off 1. Cut off the ESC or receiver power supply. 2. Cut off the transmitter power supply. Switch off...
- Page 9 Model: SR2S 2.4GHz 2 Channel remote system 10. Failsafe Fail safe function – digital protection against radio interference. The safety electronic can detect reception of a “false” or incomplete radio signal. E.g. due to a low transmitter battery or environmental radio interference which reach the model, or if the model is out of the transmitter range.
