- Page 1 Heated Glass Top Vacuum Press OPERATOR’S MANUAL This user’s manual refers to the following models: Model Working Area HGP220 25” x 37” (635mm x 940mm) HGP260 35” x 47” (890mm x 1194mm) HGP360 42.5” x 66.5” (1080mm x 1689mm) HGP560 50.25”...
- Page 2 Copyright © 2012 Drytac Corporation All rights reserved. No part of this publication may be utilized or reproduced in a retrieval system, or transmitted in any form or by any means; electronic, mechanical, photocopying, recording, or otherwise, without prior written permission from Drytac Corporation.
-
Page 3: Overview
Our “Start to Finish” strategy sums up Drytac’s unique ability to manage all phases of the customer experience: product quality and performance, manufacturing and distribution, training and technical support and the industry’s best customer service. -
Page 4: Table Of Contents
Table of Contents Overview........................... 3 Safety Considerations ....................... 5 Press Set up ........................5 Stand Assembly ........................ 6 Connecting the Vacuum Pump ..................7 Electrical Connection ......................8 Main Controls........................8 Initial Test ......................... 9 Temperature Controls ...................... 10 Operating the Vacuum Pump .................... 9 Principles of Operation...................... -
Page 5: Safety Considerations
• Ideally, the vacuum press should be used with a metal stand (available from Drytac). If a stand is not used, the press must be located on a sturdy table or countertop capable of supporting its weight (refer to Technical data in this manual). The largest model (HGP560) is supplied with a stand, which must be used due to the weight of the unit. -
Page 6: Stand Assembly
larger models should be used with a floor stand due to their size and weight. The ideal working height of the press will vary depending on the operator. We suggest a height of 28 to 31 inches (700 to 790 mm). It is critical that the lid of the press is able to open fully. Please be absolutely sure that nothing interferes with this! For proper operation, it is very important that the press be flat and level. -
Page 7: Connecting The Vacuum Pump
Push the diaphragm back into position ensuring it fits into the three clips at the back of the press and re-fit the three screws at the front of the diaphragm. Stand Assembly Instructions for Small Models (HGP220 / 260/ 360) Component list: •... -
Page 8: Electrical Connection
Plug the electrical cord from the pump into the matching connector on the rear of the vacuum press. All four models of the Drytac Glass Top Vacuum Press require single-phase AC power. The current and power requirements are different for each model, and are summarized below. -
Page 9: Initial Test
VACUUM PRESSURE GAUGE: Indicates actual vacuum pressure. A normal reading is 25” or higher (with the variable pressure adjustment set to maximum). AUTO / MANUAL SWITCH: Acts as a simple On/Off switch for the pump if you do not need to use the Timer. -
Page 10: Temperature Controls
ADJUSTING THE TEMPERATURE CONTROLLER (FARENHEIT) To adjust the pre-set temperature, press and hold Button1. Then use Button 2 to increase or Button 3 to decrease the pre-set temperature. Once the desired level is reached, release Button 1 to set the desired temperature. When current is flowing through the heating element, a small red dot next to OUT1 will glow. -
Page 11: Principles Of Operation
When in Program mode, either the minutes or seconds digits will be flashing to indicate that you may change them as desired. To Change the Preset Time Enter the Program mode by pressing Button 1; either the minutes or seconds digits will flash. To alternate between minutes and seconds press Button2. -
Page 12: Fundamentals Of Drymounting
your job. It is important that the press be operated at the correct temperature to activate the adhesive and bond the materials. See page 8 for more on temperature controls. Time (Dwell): This factor works in conjunction with temperature to create a permanent bond between materials. -
Page 13: Fundamentals Of Laminating
Laminating is the process of applying a thin clear film to the surface of a print, photograph or other type of graphic. Drytac manufactures a wide range of Artshield™ UV HeatSet laminating films for use with the Hot Press. The materials are activated by temperatures in the 185° F-210° F (85° C- 99°... - Page 14 Illustration 12B: Applying Artshield laminate to the print/photo. Your actual settings will vary according to the size of the press, type of dry mounting tissue, type of mounting substrate, the artwork material used (in terms of material and the size of the print. See specific product specifications for recommended dwell times (dwell times provided are for paper graphics).
-
Page 15: Preparing Substrates
Note: Put the foam overlay blanket directly on top of laminating film. Do not put release paper/film between film and foam overlay blanket or between foam overlay blanket and top of press. PREPARING YOUR MOUNTING SUBSTRATE Once have decided most appropriate adhesive/substrate combination for your application, it is important that you properly prepare your substrate before... -
Page 16: Troubleshooting, Vacuum
Latch Adjustment: The latches on the front of the unit should close easily with a comfortable “click”. If they are too loose or if they need excessive pressure to close, they can be adjusted by turning the latch on the pivoting, threaded shaft. -
Page 17: Troubleshooting, Electrical
3. Misalignment of press lid: To verify this, do the “bookmark” test. Cut thin strips of paper and place at different sections of the seal all the way around the press. Close the lid and secure the latches, then try to remove the paper strips. The paper will normally be held tight. If the paper can be pulled out, this will indicate there is a gap between the seal and the lid of the press. -
Page 18: Contact Information
CONTACT INFORMATION Drytac Corporation (USA) Drytac Europe (UK) 5601 Eastport Blvd. Filwood Road, Fishponds Richmond, VA 23231 Bristol BS16 3RY, United Kingdom Toll Free Phone: 800-280-6013 Phone: +44 (0) 117-958-6500 Toll Free Fax: 800-622-8839 Toll Free Phone: 0845-070-0660 (UK only) E-mail: sales@drytac.com... -
Page 19: Warranty
Hot Press and want to assure you that we will do our best to see that your experience with your new machine is a positive one. Every Drytac machine is designed and manufactured to give many years of dependable service.
