- Page 1 SIM535 Technical Reference Manual RELEASE Revision B2 ©Serious Integrated, Inc. SIM231_TRM_B2ENUS Arrow.com. Downloaded from...
-
Page 2: Important Legal Notice
TRADEMARKS AND COPYRIGHTS The “Serious” name and stylized Serious mark are trademarks of Serious Integrated, Inc. The information herein, unless otherwise indicated, is Copyright 2013-2014 Serious Integrated, Inc. Third party brands and names are the property of their respective owners. -
Page 3: Table Of Contents
Hardware ......................................... 8 Software .......................................... 8 Getting Started ......................................9 Ordering Information ....................................10 Order Codes ........................................ 10 SIM535 Family Member (Variant) Overview ........................... 11 LCD Options ........................................ 12 Development Kits ..................................... 13 Specifications ........................................14 DC Maximum Ratings ....................................14 DC Operating Characteristics ................................ - Page 4 Haptic Feedback ....................................27 Power Supplies ......................................28 Power Input: +VEXT ..................................28 Turning SIM535 Off: PWRDWN# ..............................28 +3.3V (+3V3) and +1.25V (+1V25) Regulation ........................28 USB Device (“Function”) Power: USBF_VBUS ......................... 29 USB Host Power: USBH_VUSB ............................... 29 LCD Panel Backlight Power: BLEN and BL_LED+/BL_LED- ..................
- Page 5 Device IDs ....................................... 46 Software ........................................46 USB2.0 High-Speed Device Port ..............................46 USB2.0 High Speed Embedded Host Port ..........................46 Additional Information ....................................47 RELEASE Revision B1 ©Serious Integrated, Inc. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from...
-
Page 6: Document Information And Applicable Products
This symbol indicates an advanced tip for hardware or software designers to extract interesting or unique value from the Serious Integrated Module. Pay special attention to this note – items especially subject to change, or related to compatibility, functionality, and usage. -
Page 7: Introduction
The possibilities are endless: the SIM535 module contains not only a powerful MCU but also a suite of hardware features that are commonly needed in many designs. An alarm panel, for example, could be as simple as a SIM535 connected to another PCB with a $0.20 MCU, a few relays and a battery. -
Page 8: Hardware
-3.6 to 5.5V DC powered Within the SIM535 are numerous family members, or “variants”. Each variant has a slightly different set of features and price points for an OEM to select the appropriate feature/cost point for their specific application. -
Page 9: Getting Started
Powering from the 16-pin Power/Communications Connector All SIM535 development kits come with a 16 pin wire harness for prototyping that can connect in to the 16-pin Power/Communications Connector. An AC power adapter with fixed 5VDC@1A output or similar lab power supply can be connected to the power pins of this harness to power the SIM535. -
Page 10: Ordering Information
SIM order codes are constructed as follows: As of the time of this document’s publish date, the current order codes are as follows: Order Code Description Detail SIM535-A01-DEV- 01 Dev Kit Includes Serious SHIP Programming SIM115-A01-R45ALL Adapter (SPA200-A00), no JTAG... -
Page 11: Sim535 Family Member (Variant) Overview
SIM535 FAMILY MEMBER (VARIANT) OVERVIEW As of the time of this document’s publish date, the variants (aka family members) are: Family Variant SH7269 SH7269 SH7269 SH7269 MCU Max MHz MCU FLASH/RAM(kB) 0/2560 0/2560 0/2560 0/2560 JTAG E10 Debug ... -
Page 12: Lcd Options
LCD OPTIONS Consult the following table for available LCD Options on the SIM535 family at the time of this document release. Not all authorized Serious LCD options are available for all variants: for an up-to-date list, contact an representative. For a... -
Page 13: Development Kits
The SIM535 is intended for GUI development with the Serious Human Interface™ Platform and has limited support from Renesas for C-level development, therefore the standard SIM535 development kit has no JTAG debugger included. Customers who which to do C/JTAG-level development will need a Tag-Connect TC2070 adapter cable and a Renesas E10 programmer/debugger. -
Page 14: Specifications
DC OPERATING CHARACTERISTICS MODULE LEVEL The following DC characteristics apply to all variants of the SIM535, and do not include LCD backlight power which must be added to the total depending on the LCD option selected: NOTE: All numbers in colored italics are pre-production estimates. -
Page 15: By Subsystem
No device inserted; device power is in addition to this number. 50% white/50% black or 50% RGB pixel intensity 100% white MCU I/O Many I/O signals on the SIM535 are directly and exclusively connected to SH7269 MCU pins. Consult the SH7269 data sheet for complete specifications of each pin. -
Page 16: Environmental Characteristics
Do not expose to high temperature and/or high humidity testing with the protective sheet place. Slowly remove the protective sheet to minimize potential static electricity creation. RELEASE Revision B1 ©Serious Integrated, Inc. Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 17: Pressure And Impact
If cleaning of the LCD panel surface is necessary, Isopropyl or Ethyl alcohol, either 100% or mixed 50%/50% with distilled water, may be used on a moist clean soft cloth. Do not use abrasive, ketone-containing, and aromatic solvents which will damage polarizer materials. RELEASE Revision B1 ©Serious Integrated, Inc. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 18: Physical Characteristics
The outer dimensions of the SIM535 are 165mm x 123mm. Any connectors populated along the bottom edge may extend up to an additional 2mm beyond the 123mm of the PCB. The SIM is designed to be mounted using four M4 machine screws. -
Page 19: Daughter Card Physical Guidelines
SIM revisions. It is possible to create a single daughter card that can dock into numerous SIMs, including the SIM115, SIM231, and SIM535. Consult the respective Technical Reference Manuals (TRMs) to validate a compatible footprint: there are slight differences in the physical and electrical characteristic for daughter cards across different SIMs. -
Page 20: Serious Communications Modules
Serious Communications/Power Module 117 (SCM117) family, for example, is a series of flexible and production-worthy communications and power conversion accessory boards for use with Serious Integrated Modules (SIMs). The SCM117 can dock directly into newer SIMs such as the SIM115, SIM231, and SIM535 forming a low profile and cost effective combination. - Page 21 Example SCM117 Docked into SIM535 v2.3 The SCM117 family has numerous members, or “variants”, implementing all or a subset of the following: RS232, RS422, RS485, and CAN transceivers Renesas RX111 MCU for local protocol translation and control DC-DC converter for powering the SCM and attached SIM from network-borne power ...
-
Page 22: Hardware Overview
Not all features are available on all SIM5353 variants (family members). GRAPHIC COLOR LCD DISPLAY AND TOUCH OPTION The SIM535’s Liquid Crystal Display (“LCD” or “glass”) has an on-glass row-column driver chip for illuminating pixels but has no on-glass frame buffer or memory. The... -
Page 23: On-Module Peripherals
ON-MODULE PERIPHERALS The SIM535 contains numerous on-module peripherals – many common to a vast and diverse set of OEM applications, including a Real Time Clock/Calendar (RTCC) (battery-backed on some modules), temperature sensor, USB device, USB host, boot Serial FLASH, high speed UART(s), EEPROM, bi-color indicator LED, a user “select” switch, and more. -
Page 24: Power
POWER The SIM535 module can be powered from 5VDC 1A typical supply applied to the signal available on several +VEXT connectors: Power and Communications Connector 60-Pin Board-to-Board Expansion Connector SHIP Programming Port In the software development environment, the... -
Page 25: Module Feature Detail
MODULE FEATURE DETAIL SIM535-A01 v2.0 Component Side View RENESAS SH7269 MCU At the heart of the SIM535 is a 266MHz 32-bit Renesas SH7269 MCU equipped with extensive analog and digital peripherals. Features include: MCU Core & Memory 266MHz 32-bit core with 16KB cache ... -
Page 26: Lcd Display
LCD DISPLAY The LCD display (or “glass”) on the SIM535 is a 7” diagonal active area 800x480 TFT with optional 4-wire resistive touch layer. Various LCD options are available for the SIM535; see Ordering Information for more details. The LCD display has no on-glass frame buffer or memory. The MCU is responsible for delivering pixel data at a specific frequency to the LCD display as well as various clock signals otherwise the display will not function correctly and will not display a stable image. -
Page 27: Proximity Sensing
Since the backlight on the SIM535’s LCD display can be very bright, especially in low ambient light environments, software may want to modulate the backlight brightness to improve readability as well as backlight LED longevity. The ALS is connected to an MCU analog input ( ) and the ambient light intensity can be derived from the ADC value. -
Page 28: Power Supplies
USBH_AUX_5V 9.6-18V LED Backlight Constant Current BL_LED+/- TURNING SIM535 OFF: PWRDWN# All regulators on the SIM535 can be turned off via the signal, available on the following connectors: PWRDWN# 16-pin Power/Communications Connector 60-Pin Board-to-Board Expansion Connector is weakly pulled high on the SIM to deliver the default powered-on behavior. Driving this signal to... -
Page 29: Usb Device ("Function") Power: Usbf_Vbus
SIM535 exceeds the USBF_VBUS ability of the USB specification. The signal is only used by logic on the SIM535 to determine if an external USB USBF_VBUS host has connected to the device port. -
Page 30: Batttery Backed Real Time Clock/Calendar (Rtcc): +Vbat
CR1025-type 3V coin cell battery populated. This is not designed to be a rechargeable battery, nor does any circuit on the SIM535 supply power to charge this battery. The only purpose and connection of this coin cell battery is to... -
Page 31: Sdram
SDRAM The SIM535, depending on the variant, includes a Micron 32MB SDRAM or equivalent with a 16-bit data bus configuration. The SDRAM can operate at up to 133 MHz depending on the MCU core frequency. The MCU’s built-in SDRAM controller can be configured to enable this memory in random access or burst modes. -
Page 32: Eeprom
SD CARD SOCKET The SIM535 module has a full sized SD Card socket, suitable for use with FLASH cards and other low power type devices. Writing software and implementing hardware for use with SD Cards may require a license from the Association. -
Page 33: Serious Serial Number
Serious Serial Number (SSN) for the module. All values are stored in Big Endian Locations … 0x08 0x0F order. Note that the SH7269 MCU on the SIM535 is also Big Endian. The following table shows Variant and LCD Option maps, correlating the values at locations respectively 0x0B 0x0C... -
Page 34: Cryptographic/Authentication Device
Atmel ATSHA204 Data Sheet for programming and hardware information of the ATSHA204 device. PCB TEMPERATURE SENSING Some SIM535 variants also contain an On Semiconductor NCT75 or equivalent for measuring the system/PCB temperature. This sensor is excellent for keeping track of general system temperature, but is not an ambient air temperature sensor: accurate air temperature sensors require separation from the circuit board in order to isolate the sensor from heating sources on the board –... -
Page 35: Clocks, Oscillators, And Time Keeping
There are many producers and consumers of stable clock signals (or “clocks”) on the SIM535: 1) The SH7269 is driven a 13.33 MHz clock signal, which is internally in the MCU multiplied by 20 to yield a 266MHz CPU clock speed. -
Page 36: External Rtcc With Optional Battery Backup
RTC clock input mode. The variant can be determined at runtime by reading the variant information from the Serial FLASH. The MCU’s RTCC is not battery-backed: when system power is lost from the SIM535 (or the signal is asserted) PWRDWN# the MCU’s RTCC stops operation and timekeeping is lost. -
Page 37: I2S Inputs And Outputs
SHIPEngine has built-in audio support. With only a few lines of code you can, for instance, deliver an ADPCM .wav file to the I2S outputs. PIEZO SOUNDER Some SIM535 variants include a piezoelectric sounder suitable for notifications, alarms, etc. The sounder is activated by applying a frequency to the signal. The MCU can hardware-PWM this signal... -
Page 38: User Pushbutton Switch And Leds
Some SIM535 variants have a bi-color (red/green) LED located on front of the display-side of the module. A bi-color LED is actually two independent LEDs in one package: the LED on the SIM535 has red and green LEDs that, when both are on, have an amber hue. -
Page 39: I2C Device Summary
PJ23/IRQ3 *The Serious SHIPBridge protocol, when used over the SPI port communicating between the SIM and the connected host, uses this interrupt to signal data ready by the host device. RELEASE Revision B1 ©Serious Integrated, Inc. Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 40: Connectors
CONNECTORS The following table summarizes the signals available on the various connectors. Not all capabilities are available on all variants: consult the SIM535 Family Member (Variant) Overview. Schematic Signal(s) Notes Net Names Power +VEXT +VEXT +3V3 +3V3 USBF_VBUS Only used to sense presence of external USB host... -
Page 41: 16-Pin Power/Communications Connector (J8)
SPI Slave Select PJ12-PH1/AN1 There is no legacy full-level RS232 port on the SIM535. However, a simple and very inexpensive adaptor (such as the CircuitMonkey.com USB-Serial TTL Adapter) can be easily attached to primary 3.3V UART Tx/Rx signals to enable full serial-over-USB communications to a PC. -
Page 42: 60-Pin Board-To-Board Expansion Connector (J7)
SIM535, the SIM535 Serial/Power Expansion Connector is one of the most flexible off-module connectors available and exposes many more signals. Often a simple daughter-card will be attached to the SIM535 using this connector to adapt the SIM535 to a particular system environment. - Page 43 Connected to both MCU pins; do not drive both simultaneously. Do not connect SIM generated +3.3VDC output; see +3.3V Regulation +3V3 PWRDWN# SIM Power Down, weakly pulled high; see Turning SIM535 Off: PWRDWN# +VEXT Main input power. See Power Supplies. Ground PF4/SSISCK0...
-
Page 44: Usb A Host Port
USB MICRO B DEVICE PORT All SIM535 variants have the USB device (or “function” in USB nomenclature) circuitry populated and connected to the MCU’s USB port. However, only some SIM535 variants (family members) have the USB Micro B connector present. The... -
Page 45: Ship Programming Connector 200 (Spc200)
PCB through a simple set of landing pads and guide holes. The SIM535 has a 14 pin pad-set designed to accommodate the TC2070-IDC-NL... -
Page 46: Universial Serial Bus (Usb)
UNIVERSIAL SERIAL BUS (USB) All SIM535 variants have a single USB 2.0 High Speed (480Mbit/s) device (or “function”) capability, though not all variants have the associated Micro B connector. The USB Device signals are also available on other connectors (if... -
Page 47: Additional Information
ADDITIONAL INFORMATION The home page for SIM535 technical documentation is: www.seriousintegrated.com/docs/SIM535 Further documentation, including schematics, SolidWorks/STEP files, and more can be found there. Information about the SHIP Programming Port, including the SHIP Programming Connector 200 (SPC200) SHIP Programming Adapter 200 (SPA200) can be found at www.seriousintegrated.com/SPAs.
