1. Safety Information 1.1 General Warnings • Cautions / precautions must be observed when installing, using, maintaining and discontinuing use of this equipment; • Before carrying out any operation (assembly, use, maintenance and reuse after prolonged use of the equipment), read the manual carefully; •...
2. Technical Characteristics 2.1 Main Components For the equipment described in this manual, safety in use, cleaning, maintenance and maximum hygiene are guaranteed by the design and special design of all parts, as well as the use of stainless steel and other materials suitable for contact with the foods. The equipment was designed with the following characteristics: •...
When installing, it is essential to make this manual available to the professionals who will carry it out. To ensure correct operation and safety, the equipment must be positioned in an airy environment and on a sufficiently wide, well-leveled, dry and stable bench, away from sources of heat and water taps, and at an average height of 80 cm.
ATTENTION! Before turning on your equipment, always check that the mains supply voltage is the same as the equipment voltage. If it is not the same, contact the manufacturer or authorized dealer. The supply voltage of this equipment is 110 V (60 Hz) or 220 V (50 or 60 Hz) single-phase, as can be verified on the voltage label affixed to the power cable or as indicated on the nameplate data label, which is located on the right side of the equipment (see the figure on this label in item 2.2 of this manual).
4. Equipment Use 4.1 Utility This equipment is exclusively intended for grinding and chopping different products dry or with a small addition of liquids. 4.2 Commands The equipment consists of only the on/off switch that is positioned on the front of the equipment.
Page 9
Check the disassembly and assembly processes described below. • Disassembly: 1. Before starting the disassembly process, disconnect the equipment from the mains; 2. Unlock the lid by rotating it clockwise and pull it upwards; 3. Pull the coupling upwards, removing it (be careful when handling it so as not to cut yourself with the blades);...
Page 10
With the bowl in place, assemble the coupling. Hold it firmly by the upper side and fit it into the axle, pushing it until it hits the end of the stroke. If you don't feel it tapping, it may not have been fitted correctly.
Page 11
• When you have pieces of food (for example, vegetables such as tomatoes, onions, peppers, etc.), place them in the bowl, respecting the “MAX” level. indicated on the inside of the bowl; • Lock the lid on the bowl (see the assembly process on page 14); •...
ATTENTION! Never open the lid with the equipment on, nor should you put your fingers, hands or objects (such as spoons and knives) inside the bowl, as this could cause accidents. Do not open the lockers with the equipment switched on and do not forget to close them when assembling the bowl back.
ATTENTION! Do not insert the detachable parts (plastic lid, coupling and stainless steel bowl) in the dishwasher. The PET-G (polyethylene terephthalate) materials of the lid and the stainless steel of the metal parts are not suitable for use in the dishwasher. Take care when cleaning the blades as they are extremely sharp.
6. ANEXXES Electrical Schematic CUT.4 – Voltage 110 V or 220 V – 50 Hz or 60 Hz NOTE: In the wiring diagram above, white wires are represented by pink. ATTENTION: The ground connection varies depending on the plug type. For the electrical installation, observe the regulations in force in the country, especially with regard to the earth connection (if applicable).
Electrical Schematic CUT.6/8 – Voltage 110 V – 60 Hz On/Off Switch Motor Single-phase Equipment Structure NOTE: In the wiring diagram above, white wires are represented by pink. ATTENTION: The ground connection varies depending on the plug type. For the electrical installation, observe the regulations in force in the country, especially with regard to the earth connection (if applicable).
Electrical Schematic CUT.6/8 – Voltage 220 V – 50 Hz or 60 Hz On/Off Switch Motor Single-phase Equipment Structure NOTE: In the wiring diagram above, white wires are represented by pink. ATTENTION: The ground connection varies depending on the plug type. For the electrical installation, observe the regulations in force in the country, especially with regard to the earth connection (if applicable).
Spare Parts List Position Code Description Quantity Position GAB178 Structure SUC012 CUT.4 Bowl Support SUC021 CUT.6/8 MTE194 Electric Motor 1/2 HP 60 Hz 110 V CUT.4 MTE195 Electric Motor 1/2 HP 60 Hz 220 V CUT.4 MTE250 Electric Motor 1/2 HP 50 Hz 220 V CUT.4 MTE096 Electric Motor 3/4 HP 60 Hz 110/220 V...
Page 20
IMG BRASIL Gastronomy Machinery Industry Ltda. CNPJ 11.193.347/0001-14 - CREA 131726-3 Road. Antônio Heil - KM 23 Nº 5825 - Neighborhood: Limoeiro ZIP CODE 88352-502 - Brusque - SC - Brazil Phone/fax. +55 47 3251-5555 - Web Site: www.metvisa.com.br Mail: sac@metvisa.com.br - export@metvisa.com.br...
