- Page 1 ASSEMBLY INSTRUCTIONS 42" Round Conference Table 36" Square Conference Table Lot Code # NEED HELP? Call 1−800−950−4782 www.bbffits.com Part Number A179922A Keep manual for future reference.
-
Page 2: Important Safety Information
A179922A IMPORTANT SAFETY INFORMATION WARNING Do not move unit when loaded. Doing so could cause instability, product collapse, tip over, and/or serious injury. No mueva la unidad cuando esté cargada. Hacerlo puede causar inestabilidad, que el producto se derrumbe, que se la caiga encima y/o heridas (golpes) serias. -
Page 3: Exploded View
A179922A EXPLODED VIEW... -
Page 4: Parts List
A179922A PARTS LIST 99TB42RCS 99TB42RMR 99TB42RMC A [1] W171596 A [1] W171595 A [1] W171594 B [1] W174220 B [1] W174222 B [1] W174224 C [2] W174221 C [2] W174223 C [2] W174225 99TB42RHC 99TB42RAC A [1] W179033 A [1] W171597... - Page 5 A179922A FASTENERS [ 4 ] H24806 [ 4 ] H71659 Caster Insert KD Cam [ 4 ] H39696 [ 1 ] H175474 X-Base Strap LEVELER [ 13 ] H26053 #10 x 1-1/4" [ 4 ] H72988 KD Bolt [ 6 ] H38169 Wood Dowel [ 4 ]...
- Page 6 A179922A ATTENTION Common assembly techniques. Técnica común de ensamblaje. Techniques communes d’assemblage. −Use a screwdriver with H72988. −Favor de usar un desarmador con el tornillo H72988. −Utilisez un tournevis avec H72988. −Wood dowel installation. −Instalación del tornillo de madera. −Installation de chevilles de bois. −Panel to panel attachment.
- Page 7 A179922A STEP [ 2 ] Wood Dowel [ 4 ] [ 2 ] #10 x 1-1/4" Caster Insert [ 2 ] [ 2 ] Bracket Leveler...
- Page 8 A179922A STEP [ 4 ] Wood Dowel [ 4 ] [ 2 ] #10 x 1-1/4" Caster Insert [ 2 ] [ 2 ] Bracket Leveler...
- Page 9 A179922A STEP [ 4 ] KD Bolt 99TB42Rxx 99TB3636xx...
- Page 10 A179922A STEP [ 3 ] [ 5 ] Wood Dowel 1/4 x 2 #10 x 1-1/4" [ 1 ] An assistant is required. X-Base Strap Es necesario un ayudante. Un assistant est nécessaire.
- Page 11 A179922A STEP An assistant is required. [ 4 ] Es necesario un ayudante. Un assistant est nécessaire. KD Cam...
- Page 12 A179922A STEP With an assistant carefully stand unit upright. Con un asistente cuidadosamente levante la unidad a una posición vertical. Avec l’alde d’un assistant placesz solgneusement l’unite debout. Maximum Weight: 125 Lbs. Peso Máximo: 125 Libras Poids Maximum: 56.7 kilogramme Maximum Weight: 125 Lbs.
