Black Lion Audio PBR TRS-BT Quick Start Manual

CONNECTING BLUETOOTH
Once you have installed your PBR TRS-BT where you need it, plug it in to
an appropriate power source. Note: The power supply is only needed for
Bluetooth audio.
Plug in your equipment to the correct outlets on the PBR TRS-BT.
Once the power supply is pluged into the power inlet, the PBR TRS-BT Blue-
tooth is active. To sync your device to the PBR TRS-BT, press and hold the
Bluetooth Sync button. Once the Bluetooth Status LED has started to blink,
devices are able to find the PBR TRS-BT via Bluetooth connection.
To sync another device to the PBR TRS-BT, press and hold the Bluetooth
Sync button.
PBR TRS-BT
46-Point Gold-Plated TRS Patchbay plus Bluetooth®
4
1
5
1. Power Inlet: Connect power supply here. Power is only necessary for
Bluetooth connection.
2. Bluetooth Sync: This button operates the Bluetooth Sync. Press and
hold this button to set the PBR TRS-BT to "sync mode", when connect-
ing new devices.
3. Bluetooth Status: When this LED is blinking, the PBR TRS-BT is ready
to be paired. When this LED is lit, the PBR TRS-BT is synced to a device.
4. Bluetooth Left Output: This TRS jack outputs the left channel of the
Bluetooth audio.
5. Bluetooth Right Output: This TRS jack outputs the right channel of the
Bluetooth audio.
3
2
