Page 3 OXSIGHT Onyx User Guide v2.5 Thank you for purchasing OXSIGHT Onyx®. This User Guide will help you get started with using the device (we refer to it simply as Onyx throughout the guide). For service and after sales support: OXSIGHT Ltd.
Page 4: Table Of Contents
Contents Safety information ......Intended use Box contents ........Features .......... Headset Control buttons LED indicators Getting started ......Charging Switching on and off Powersaving modes Fitting/wearing Onyx Using Onyx ........Zooming the live image Refocusing the image Page 2...
Page 5 Pausing the live image Menu modes Changing the display brightness TV mode Face mode Applying image effects Changing settings Software updates Troubleshooting ......General information ...... Specifications Intellectual property rights Open source software Restrictions on use Correct disposal Authentication information Warranty Page 3...
Page 6: Safety Information
Safety information Read this important safety information before using the device. Heed the warnings and cautions to prevent injury to yourself and others, and to avoid damaging the device. Retain this safety information. Symbols used in this document Symbol Meaning Warning: This symbol indicates that failure to comply with the stated safety warnings and information could result in serious personal injury or even death.
Page 7 If the device becomes damaged or malfunctions in any way stop using the device immediately. Continuing to use a damaged or faulty device may result in nausea or injury. Contact the OXSIGHT Care Team for assistance. Page 5...
Page 8 Device usage precautions Cautions Stop using the device immediately if your skin becomes itchy or you develop any unusual rashes after touching the device. If you sweat while using the device, wipe any moisture from both the device and your face. Do not attempt to open up or tamper with the device or modify the software or operating system on the device in any way, either yourself or by asking someone else to...
Page 9 Doing so could lead to electric shock, fire or deterioration of performance. OXSIGHT only recommends the use of the charging accessories provided with the device. See page 49. Do not use the AC adapter or cables if they are damaged as this may result in electric shock.
Page 10 Cautions Do not puncture, open or disassemble the battery contained in the device. Do not attempt to service or replace the battery. Contact the OXSIGHT Care Team for guidance. Do not dismantle, open, short-circuit or manipu late the device. Risk of electric shock! Danger of electric shock! Unplug before cleaning.
Page 11: Intended Use
• Onyx is designed to improve the ability to carry out tasks such as reading, watching TV, and recognising faces. This can help with work, study, social situations, and hobbies.
Page 12 • Onyx may also be used by children over 11 years old, but only on the approval of their optician. Children wearing the device must be supervised at all times by a responsible adult. • Onyx is compliant with IEC/EN 60601-1 with additional test...
Page 13 The device must not be used during any activity that could be considered hazardous. Failure to follow this advice may lead to serious injury and even death. Onyx is not designed to cure, restore vision, or halt a degenerative eye condition. Page 11...
Page 14 • Allow the device to dry thoroughly. • Regularly check for any cracks or case damage to the headset, USB cable and charger. In case of damage stop use immediately and contact Onyx customer support for assistance. Page 12...
Page 15: Box Contents
Box contents Check that the following items are included in the box: • Onyx headset (page 14), with fitted forehead pad and nose bridge • USB-C cable (page 20) • Charger and international plugs (page 20) • Plastic arms with adjustable/removable head strap (page 25) •...
Page 16: Features
Features Headset Camera Control buttons (page 16) Page 14...
Page 17 Proximity sensor (page 24) Left LED (page 18) Forehead pad (page 28) Right LED (page 19) USB port (page 20) Adjustable eyepieces (page 30) Nose bridge (page 29) Page 15...
Page 18: Control Buttons
Control buttons Use the six buttons on the top of Onyx to switch on and off, pause the display, and access modes and settings (e.g. zoom). The table on the next page gives an overview of what the buttons are used for.
Page 19 Icon Button Function Power/ Switch on and off (page 22). Default Exit the current mode or menu and return to the view default view (page 35). Zoom in/ Zoom in (page 32). Scroll up Scroll up list of menu options (page 35). Zoom out/ Zoom out (page 32).
Page 20: Led Indicators
LED indicators The Onyx LEDs indicate charging and operational status. Left LED Behaviour Meaning Flashing green Starting up/Sleep mode (page 24) Solid blue then off Operational Flashing orange Shutting down Flashing purple Update mode (page 44) Flashing red Startup error (page 45)
Page 21 Right LED Behaviour Meaning Flashing red Battery low (less than 5%) (page 20) Solid white Charging (page 20) Page 19...
Page 22: Getting Started
Getting started Charging Ensure the device is fully charged before using it for the first time. Caution: Do not leave the device connected to the charger for long periods of time or overnight. Do not cover the device when on charge. Page 20...
Page 23 Full charging of the device takes approximately one hour. Unplug the USB cable and charger when charging is complete. Note: You can use Onyx while it is still connected to the charger/ power outlet, but take care not to strain or break the USB cable. It is best to remain seated while using Onyx in this way.
Page 24: Switching On And Off
Start-up is complete when the display shows the full colour camera view. You can now start using Onyx. – If Onyx does not start up as expected, see page 45. Note: There is a short delay between pressing and seeing Onyx on the display.
Page 25 Checking the battery level The device is powered by an integrated rechargeable Li-Ion battery (see page 49). To check the battery level (when Onyx is on): Press and release The battery level will be displayed on the screen. • The full charge is 100%.
Page 26: Powersaving Modes
You can wake Onyx up simply by picking it up and placing on your face again. – If you pick Onyx up while it is in Sleep mode, the Left LED turns solid blue for a short time then goes out. •...
Page 27: Fitting/Wearing Onyx
Please try on your Onyx, adjusting the head strap to ensure that it is held securely and comfortably to your head. If you can’t position Onyx comfortably in line with your eyes, or if it is putting too much pressure on your nose, you may need to change the nose bridge (see page 29).
Page 28 Fitting the head strap Fit the head strap if you want to use Onyx hands-free. One head strap is supplied already fitted to the arms. There is also a spare head strap. To fit the head strap: Clip the arms onto the brackets on the sides of the headset.
Page 29 Page 27...
Page 30 Fitting a new forehead pad The forehead pad makes Onyx comfortable to wear and helps keep the lenses at the right distance from your eyes. The lenses should be close enough to your eye to get a good image from the display, but not so close as to be touching your eye lashes.
Page 31 Fitting a new nose bridge If the headset is pushing too heavily onto your nose, you might want to use a smaller nose bridge. To fit a new nose bridge: Grip the nose bridge and pull firmly away from the headset. Align the replacement nose bridge so that the rubber guide point fits within the guide hole in the headset.
Page 32 Adjusting the eyepieces Onyx works best when your eyes are in the centre of each eyepiece. To adjust the eyepieces: Slide the eyepieces left or right until you feel like each of the lenses is aligned directly in front of your eyes.
Page 33 Using the lanyard The supplied lanyard allows you to hang the headset around your neck when not in use. This keeps the device within easy reach when you are using it intermittently for hobbies or detailed work. To use the lanyard: Attach the lanyard clips to the headset via the small circular holes at the bottom of each headset bracket.
Page 34: Using Onyx
Using Onyx Zooming the live image There are six levels of image zoom: –1, 0 (default), 1, 2, 3, 4. To magnify or shrink the image by one level: Press To reset the zoom to the default value: Press and release...
Page 35: Pausing The Live Image
Pausing the live image You can pause the live image if you want to focus on specific details in the field of view. To pause the live image: Press – The button will vibrate when it is pressed. – The word Paused will show in the display when the image is paused.
Page 36: Menu Modes
Menu modes Onyx has two menu modes, Basic and Advanced. Switch between these modes using (see page 36). Options available in the different menu modes • In Basic menu mode, the options are: – Brightness: See page 36. – TV: See page 37.
Page 37 You cannot zoom in and out when in menu mode. • to select a menu option. You cannot refocus or zoom Onyx when in menu mode. Selecting menu options To enter menu mode and make a selection: Press to display the main menu.
Page 38: Changing The Display Brightness
Switching between Basic and Advanced menu mode Press to display the main menu. Press to scroll to Basic or Advanced (only one of these options will be available). Press to activate the new menu mode. Do one of the following: –...
Page 39: Tv Mode
TV mode TV mode is available in Basic and Advanced menu modes. In this mode, Onyx optimises the camera exposure for viewing TV screens, particularly in darker environments. To use TV mode: Press Press , scroll to TV and press to enter the TV submenu.
Page 40 Things you can do while in TV mode: While in TV mode, you can: • Refocus the image. See page 32. • Zoom in and out. See page 32. • Pause the live image. See page 33. To exit TV mode: Press and release .
Page 41: Face Mode
Face mode Face mode is only available in Advanced menu mode. In this mode, Onyx will lock onto and track any image that it recognises as a face and keep it in the centre of the screen. To use Face mode: Point Onyx towards a face.
Page 42: Applying Image Effects
Applying image effects Effects are only available in Advanced menu mode. You can apply one or more effects (filters) to the current image: • Edges: Edges in the display will be exaggerated and turned white. The rest of the image will be black. •...
Page 43: Changing Settings
Changing settings In Advanced menu mode, you can change some Onyx settings (text position, text size and stereo overlap). Note: If you need to know how to swap between Advanced and Basic menu modes, see page 34. Changing the text position...
Page 44 Changing the text size To change the text size in the display: Press Press , scroll to Settings and press Press , scroll through the Settings menu options and press to select Text Size. Press to scroll and to select one of the following –...
Page 45 Changing the stereo overlap If you feel a bit cross-eyed using the device, you can change the amount of difference between the left and right display. To change the stereo overlap: Press Press , scroll to Settings and press Press , scroll through the Settings menu options and press to select Stereo Overlap.
Page 46 Software updates From time to time we might want to update your Onyx with new software. Please visit our website for information about the latest update. You can also scan the QR code below for details. https://www.oxsightglobal.com/onyx-user/software To enter Software Update mode: Press and hold for four seconds to switch the device off.
Page 47: Troubleshooting
Troubleshooting Most problems can be solved by switching the device off and on again. If your problem cannot be rectified using the below advice, please contact your OXSIGHT Care Team for assistance. Onyx will not switch on • Check that the device is fully charged.
Page 48 Power button • Press and hold for five seconds, then release. This will reset Onyx to its default settings. You will then need to switch Onyx back on again by pressing Onyx will not charge • Check that the device is switched off before charging.
Page 49 If the Right LED flashes red, the battery charge is less than 5%. Switch Onyx off and plug it into the charging accessory. See page Onyx is switched on, but the display is mostly black with a few small icons •...
Page 50 The image on my display seems smaller than normal • Press several times until the picture seems a comfortable size. See page 32. The image in my display seems blockier or shakier than normal • Press several times until the picture seems a comfortable size, usually when the Zoom level on the display shows –1.
Page 51: General Information
General information Specifications Item Description USB Type-C connector for charging/updates OLED display resolution 454 x 454 pixels Headset Camera resolution 5 Megapixels OXSIGHT Part number - E21008-076 1m data and charging cable USB cable USB Type-A to USB Type-C Page 49...
Page 52 Nominal Voltage 3.7V WARNING: Fire, explosion and severe hazard. Do not short circuit, crush, puncture, incinerate, or disassemble. Rechargeble cells will naturally reduce in capacity over long term use. Contact Onyx customer service for support and advice if needed. Page 50...
Page 53 Water IPX0 and Dust Protection WARNING: Do not use Onyx in the rain, when at the beach or swimming pool, or in or near a bathtub or shower. Do not submerge the Onyx in any type of liquid. Page 51...
Page 54: Intellectual Property Rights
Intellectual property rights OXSIGHT Onyx™ is a registered trademark of OXSIGHT Ltd. The customer recognises and agrees that all rights, intellectual property and trademarks in relation to this device are the property of OXSIGHT Ltd., whether registered or not. Under the terms and conditions of the sale the customer is granted...
Page 55: Open Source Software
Open source software The device uses software owned by OXSIGHT as well as the following Open Source Software components: Linux Kernel and drivers, Android OS, Gstreamer and plugins, kmsbootanim, tengine, opencv, grpc, meson, gobject-introspection, flashrom, armnn, tensorflow-lite, libx264, ffmpeg. Open Source licenses these components are licensed...
Page 56: Correct Disposal
Correct disposal The WEEE (Waste Electrical and Electronic Equipment) marking on this device indicates that this device should not be disposed of with general household waste. Users should contact their local waste disposal provider or local council for details of how to dispose of the device without doing undue harm to human health or the environment.
Page 57: Warranty
Warranty This OXSIGHT Onyx has been inspected and tested prior to shipping to ensure the device delivers the expected high standards of operation and reliability. OXSIGHT offers a warranty period of twelve months after the date of delivery of the device against defects in materials and manufacture under normal use.
Page 58 • Damage due to operation of the OXSIGHT Onyx with equipment not supplied or approved by OXSIGHT Ltd. You may be asked to provide proof of purchase, bearing the date of dispense, in order to receive warranty service. Page 56...
