RG R13-00011 Quick Start Manual

Quick Start Guide
Cordless Jack Nurse-call
Applies to product codes:
R13-0001 1

System Contents

Monitor RG5 Cordless Jack
Sensor RG1 1 / RG49 Cordless Seatgard
RG13 / RG47 Cordless Bedgard
RG59 Cordless Floorgard
RG39 Cordless Under-mattress Pad
Transmitter RG9 Cordless Pad Transmitter

Sensor Placement

RG13 / RG47 Bedgard:
The pad can be placed anywhere between the shoulders to the hips depending
on the condition of the patient and how early you want the alert.
RG39 Under-mattress:
at the lower back level. On profiling beds make sure it will not entrap the
mechanism when the bed is being adjusted.
For further guidance on placement, please refer to the pad positioning flyer.
RG1 1 / RG49 Seatgard:
a cushion), giving consideration to the position of the monitor and the least
intrusive method of installing the equipment.
RG59 Floorgard: Place mat at or near to the area to be monitored such as a
doorway or side of the bed.

Receiver/Monitor Placement

The Jack should plug straight into any available nurse-call port with the switch
set according to mono/stereo operation.

General Operation

When a sensor pad is triggered, the jack activates a timed alarm output to
the nurse-call, which can only to be reset at the nurse-call point.
| R13-0002 | R13-0003
R13-0006 | R13-0007
Place on top of the mattress and under the bed sheet.
Place under the mattress across the width of the bed
Place mat on the relevant seat (on top of or under
| R13-0004 | R13-0005
| R13-0008
|
