RG R14-0001 Quick Start Manual

Quick Start Guide
Wireless Pager Standalone Kit
Applies to product codes:
R14-0001

System Contents

Monitor RG41 Wireless Jill
Sensor RG49 Wireless Seatgard
RG47 Wireless Bedgard
RG38 Wireless Floorgard / RG59 Wireless Floorgard
RG39 Wireless Under-mattress Pad
Transmitter RG9 Wireless Pad Transmitter

Sensor Placement

RG47 Bedgard: Place on top of the mattress and under the bed sheet. The pad
can be placed anywhere between the shoulders to the hips depending on the
condition of the patient and how early you want the alert.
RG39 Under-mattress:
at the lower back level. On profiling beds make sure it will not entrap the
mechanism when the bed is being adjusted.
For further guidance on placement, please refer to the pad positioning flyer.
RG49 Seatgard: Place mat on the relevant seat on top of or under a cushion,
giving consideration to the position of the monitor and the least intrusive
method of installing the equipment.
RG38/RG59 Floorgard:
as a doorway or side of the bed.

Receiver/Monitor Placement

The Jill pager can be wall mounted using the supplied bracket, worn around
the neck on a lanyard or clipped onto a pocket.

General Operation

The pager device can receive signals from a sensor and reset alarms by
pressing and holding the cancel button. Multiple pagers can also be used for
this set-up.
| R14-0002 | R14-0003
R14-0006
Place under the mattress across the width of the bed
Place mat at or near to the area to be monitored such
| R14-0004
| R14-0008
| R14-0005 |
