hatch ELP20-2060-UNV-SD Installation And Instructions

BEFORE BEGINNING INSTALLATION, READ THESE IMPORTANT SAFETY INSTRUCTIONS
When using electrical equipment, basic safety precautions should always be followed including:
WARNING: Risk of fire or electric shock. Fixture wiring and
electrical parts may be damaged when drilling for installation of LED
Emergency Driver. Check for enclosed wiring and components.
WARNING: Risk of fire or electric shock. The LED Emergency Driver
installation requires knowledge of luminaire electrical systems. If not
qualified, do not attempt installation; contact a qualified electrician.
WARNING: Risk of fire or electric shock. The LED Emergency Driver
is only for use with surface mount or recessed Type IC or Non-IC
products listed to UL Standards. Suitable for use in damp locations
and plenum spaces. Not for use in heated air outlets or hazardous
locations.
WARNING: Risk of fire or electric shock. Do not alter, relocate or
remove wiring, lamp holders, power supply or any other electrical
component.
WARNING: To prevent wiring damage and abrasion, do not expose
wiring to edges of sheet metal or other sharp objects.
WARNING: Do not make or alter any open holes in the wiring
enclosure or electrical component enclosure during installation.
Only the open holes indicated in the instructions may be added or
altered as a result of installation. Do not leave any other open holes
in the wiring enclosure or electrical component enclosure during
installation.
CAUTION: Before installing, make certain the AC power to the
fixture is off.
CAUTION: Confirm there is 120-277V at the fixture before
beginning installation.
CAUTION: To prevent electrical shock, only mate the unit connector
after the installation is complete and before the AC power to the
fixture is back on.
CAUTION: This fixture provides more than one power supply
output source. To prevent electrical shock, disconnect both normal
and emergency sources by turning off the AC branch circuit and
disconnecting the unit connector.
1
WWW.HATCHLIGHTING.COM • 7821 W
IMPORTANT SAFEGUARDS
Note:
Installation requires application of
the Luminaire Modification Label provided
in your kit, as per UL. This label states: "This
equipment has more than one connection
point." This label must be applied to the fixture
housing during installation.
SAVE THESE INSTRUCTIONS
Use with grounded, UL Listed, damp location rated fixtures.
C B . T , FL 33614 • pH: 813.288.8006 • FX: 813.288.8105 • S
OOdLANd eNTer Lvd AMpA
E M E R G E N C Y L E D D R I V E R
I N S TA L L AT I O N A N D O P E R AT I N G
I N S T R U C T I O N S
ELP20-2060-UNV-SD
CAUTION: Do not look directly at the LED light source for extended
periods of time to prevent harm to eyes.
CAUTION: This is a sealed unit. Components are not replaceable.
Replace entire unit when necessary.
CAUTION: This Emergency LED Driver requires an unswitched AC
power source of 120-277V, 50/60 Hz. The AC LED driver MUST
be on the same branch circuit as the Emergency LED driver.
CAUTION: Verify that the LED load requirements match/are
compatible with the emergency driver selected.
CAUTION: Do not use outdoors.
CAUTION: Do not mount near gas or electric heaters.
CAUTION: Install in accordance with the National Electrical Code
and regulations
CAUTION: Do not mount in locations or at heights in which the
emergency driver could be tampered with by unauthorized personnel.
CAUTION: Do not use this equipment for anything other than its
intended use.
CAUTION: Do not use accessory equipment not recommended by
the manufacturer as this may cause an unsafe condition.
CAUTION: Use with grounded, UL Listed, damp location rated
fixtures. Emergency Driver case should be grounded.
CAUTION: The equipment is intended for ordinary locations and for
permanent installation into one or more Listed emergency luminaires.
LED Emergency Driver
Test Button
Tek Screws
Installation Guide
Luminaire Modification Label
Screw Wire Connectors
Wall Plate
Wall Plate Screws
The following are included:
PARTS QUANTITY
@ . r : 07/28/2020
ALeS HATCHLIGHTING COM ev
1
1
2
1
1
2
1
2
