Summary of Contents for GES INTERNATIONAL RAPTOR ALARM ANF2059
- Page 1 ALARM ALARM E L E C T R O N I C S E C U R I T Y S Y S T E M S GPS GSM Satellite Tracker GPS GSM Satellite Tracker INST ALLATION AND OPERATING MANUAL INST ALLATION AND OPERATING MANUAL distributed by distributed by...
-
Page 2: Table Of Contents
ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S Index 1. Introduction ....................... 3 2. General Information ....................3 3. Applications....................... 3 4. -
Page 3: Introduction
Installation and user manual 1. Introduction Thank you for purchasing the satellite tracking device. Before using the device, please read this manual carefully. It contains all the technical data and instructions for the best use of the device. The information contained herein may be subject to change without notice. The manufacturer and the retailer accept no responsibility for any errors or omissions in this document. -
Page 4: Installing The Sim Card
ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S 5. Installing the SIM card Use the supplied screwdriver to open the back cover of the locator;... -
Page 5: Initialising The Device
Installation and user manual 7.3 Advanced electrical connection If you wish to use the device as an independent alarm, connect the cables as follows: BLACK - 12 Vdc + 15 permanent PURPLE SOS button during GREEN Door activation + ignition + 12 Vdc BLUE Door activation -... -
Page 6: Authorisations
ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S The new password 888888 has been successfully changed. It is important to remember the password as you will be asked for it when you want to reset the device to factory settings. -
Page 7: Intelligent Tracking By Time Interval And Distance
Installation and user manual This set of commands must be 3 digits long and the maximum value must be 255. 13.2 Tracking with unlimited number of times in time interval Send an SMS with the words “fix030s030m *** n + password” to the device. The device continuously sends an SMS containing latitude and longitude at intervals of 30 seconds when ACC (Auto track continuously) is on and every 30 minutes when ACC is off. -
Page 8: Locating Via Lbs
ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S 18. Localisation via LBS When the tracker does not receive valid GPS signals, it signals the location via the GSM network Location Based Service (LBS);... -
Page 9: Checking Incoming Messages And Remaining Credit
Installation and user manual then imported and displayed on the web monitoring platform www.gpstrackerxy.com , via the “Data Import” function. 20.5 Loading data Send an SMS to the localiser with the message “load+password” the recorded data with the current calendar date will be downloaded automatically to the active monitoring platform. The localiser will send an SMS with the message “load OK”... -
Page 10: Motor Lock
ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S 24. Engine block N.B.: This function is only valid if the engine block relay is connected. Send an SMS with the text “stop+password”... -
Page 11: Alarm Message Sending Frequency
Installation and user manual 29. Frequency of alarm message sending You can decide how many times the alarm messages are to be sent. Send an SMS containing the message “xtime+password+005” to the localiser and the message will be sent 5 times after an alarm is detected. The SMS alarm message is sent 5 times by default. - Page 12 ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S longitude+space+areaname,distanceM”, where latitude and longitude represent a geographical point and distance the value of the radius to be tracked; the unit of distance from the point (radius) can be expressed in metres (M) or kilometres (K).
-
Page 13: Alarms
Installation and user manual 31. Alarms 31.1 Open door alarm The tracker sends an SMS with the message “Door alarm+lat/long” to the authorised numbers at 3-minute intervals when the car door is opened if the alarm is active. The tracker siren (if connected) sounds for 20 seconds, and sounds at 20 second intervals if the door remains open. -
Page 14: Programmed Activation
ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S “sleep+password+shock”; in the absence of alerts from the shake-sensor and with no current in the ACC circuit, the device turns off the GSM and GPS detectors;... -
Page 15: Setting The Time Zone
Installation and user manual 36. Setting the time zone Send the localiser an SMS with the words: “time+space+zone+password+space+local time zone”; the localiser sends an SMS with the message “time OK”. For example: send “time zone123456 1” (where 1 is the time zone of Italy during standard time). If the time zone is negative like “-2”... -
Page 16: Switching To Gprs Mode
ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S set the UDP protocol. Send the locator a sms with the text GPRS+password,1,1”, now the device will be set to UDP protocol. -
Page 17: Setting The Monitoring Centre Number
Installation and user manual 40. Setting the monitoring centre number To set up this function you need to send an SMS to the localiser with the message “centernum+password+space+number”; the localiser will reply with the message “centre num ok”. After setting up this function, all self-tracking and alarm messages will be sent from the localiser to this number. -
Page 18: Troubleshooting
ALARM ALARM Satellite tracker E L E C T R O N I C S E C U R I T Y S Y S T E M S 42. Troubleshooting The localiser does not switch on Check that the batteries are charged •... - Page 19 Installation and user manual 43. Note To all residents of the European Union Important environmental information about this product This symbol on the product or on its packaging indicates that it is forbidden to dispose of the product into the environment at the end of its life cycle as it may be harmful to the environment.
- Page 20 ALARM E L E C T R O N I C S E C U R I T Y S Y S T E M S Distributed by GES INTERNATIONAL S.r.l. GES INTERNATIONAL S.r.l. Via Giuseppe Di VIttorio, 307/31A 20099 Sesto San Giovanni (MI) Tel.
