Summary of Contents for PowerSafe TMC 500W
- Page 1 Switchboard Thermal Management System • Designed & tested for Australian conditions • Multiple fans and heatsinks in each assembly 1800 338 979 • Safe for indoor & outdoor use – IP65 powersafe.net.au • OLED monitoring screen and test function sales@powersafe.net.au...
- Page 2 Powersafe Thermal Management Systems are the industry leading solution for switchboard thermal performance and safety Introduction Congratulations on your purchase of a Powersafe TMC-500W thermal management system. These units offer unsurpassed protection against component over-temperature failure. The unit has been built tough for indoor and outdoor use on a range of switchboard enclosures.
-
Page 3: Kit Contents
Kit Contents: • 1x TMC 500W top assembly • 1x LRS-150-24 power supply unit • 1x power supply DIN mounting bracket • 1x NTL152 150W heater • 1x steel mounting plate • 12x M5 nuts • 12x M5 spring washer •... -
Page 4: Installation Precautions
• Install power supply inside enclosure in a location away from direct heat sources. • Install heater in bottom corner of enclosure in a location allowing sufficient air flow and away from combustible materials. 15/09/2022 TMC 500W User Instructions and Installation powersafe.net.au... -
Page 5: Installation Instructions
Take precautions to prevent swarf/ debris from falling onto internal components. Debur any sharp or proud edges. Treat any raw metal surfaces for rust prevention. 15/09/2022 TMC 500W User Instructions and Installation powersafe.net.au... - Page 6 M5 washer, secured with a spring washer and standard nut. The assembly should only be earthed at one point. 15/09/2022 TMC 500W User Instructions and Installation powersafe.net.au...
- Page 7 Check earth continuity of exposed parts of assembly <0.5 Ohms. Do not apply test voltages above operational voltage to assembly components. Check polarity of all field wiring to prevent damage to components. 15/09/2022 TMC 500W User Instructions and Installation powersafe.net.au...
- Page 8 Ensure all 4x fans are running to full RPM and temperature and humidity readings are accurate. If system fails, contact point of purchase for repair/ replacement. Home screen Test screens 15/09/2022 TMC 500W User Instructions and Installation powersafe.net.au...
-
Page 9: Technical Specifications
Max. current 1A (240V) Regular checking of the unit by a qualified person is mandatory to the safe operation of the unit and the individual components. Powersafe Max. power 150W recommends 3 monthly intervals for inspections. Inspections may be... -
Page 10: Troubleshooting
Reduce load on switchboard components to allow internal temperature to High Temperature Alert Internal temperature too high drop For 4 fan operation (2 internal and 2 external) Both dip switches are “ON” 15/09/2022 TMC 500W User Instructions and Installation powersafe.net.au... -
Page 11: Warranty
Powersafe Products undertakes to repair or replace at its option the defective product or part thereof with a comparable product or part at least equivalent as to the performances •... - Page 12 • Small Outdoor Power Boards • Braided Extension Leads • 3 Phase Extension Leads • Cable Covers • Lead Stands • Industrial Switchgear • Construction lighting • RCD DUO - Earth Voltage Sensor • Thermal management systems 1800 338 979 sales@powersafe.net.au www.powersafe.net.au...
