- Page 1 Instruction manual GV-12V100Ah GV-12V100Ah Smart GV-12V200Ah Smart GV-24V100Ah Smart...
- Page 2 Dear client, this manual contains all the necessary information for installation, use and maintenance of GS-Power GV Series LiFePO4 batteries. We ask you to read these instructions carefully before using the product. In this manual, the GV series batteries are also referred to as LiFePO4 battery.
-
Page 3: Table Of Contents
Table of contents Safety guidelines and measures 1.1. General 1.2. Waste management 1.3. Safety symbols and markings on the product 1.4. The meanings of the symbols Introduction 2.1. Product description 2.2. Intended use 2.3. Glossary of terminology 2.4. Symbols used Product specifications 3.1. - Page 4 Installation 4.1. General information 4.2. Unpacking 4.3. Commissioning the battery 4.3.1 Placement of the battery 4.3.2. Connecting cable 4.4. Connecting a charger to the battery 4.5. Disconnecting a battery Use of the battery 5.1. Charging current Inspection and cleaning 6.1. General information 6.2.
-
Page 5: Safety Guidelines And Measures
• Keep the original product documentation or have the link to our website (www.GS-Power.net) ready. • You can access the website via the QR code on the battery or the packaging. There you have the option of downloading these operating... -
Page 6: Safety Symbols And Markings On The Product
• It is best to fully charge the battery after use and repeat this after longer storage. The battery has a low self-discharge rate (max. 2-3 % per month). Do not charge the LiFePO4 battery below 0 °C / 32°F! The BMS prevents the battery from being charged below 0°... -
Page 7: The Meanings Of The Symbols
Please keep away from children! 2. Introduction 2.1. Description of product GS-Power LiFePO4 batteries are lightweight, compact and offer a high level of performance. The LiFePO4 batteries have been specially developed for marine applications. Please note that LiFePO4 batteries must be handled differently from conventional lead-acid batteries. We would like to ask you to pay attention to the warnings indicated on the battery.There is a risk of fire and burns if used improperly or carelessly. - Page 8 Never short-circuit the battery contacts (plus to minus). Do not connect the power cables in reverse (polarity). Do not operate the LiFePO4 battery beyond the maximum specifications given in the data sheet 2.2. Intended use For our models with a BMS (Battery Management System), it is not necessary to use an external under- and overvoltage protection, as this is taken over by the BMS.
-
Page 9: Symbols Used
It can also serve as a reminder for the user. 3. Product specifications 3.1. Technical data 3.1.1. Electrical property Label GV-12V100Ah GV-12V100Ah smart GV-12V200Ah smart GV-24V100Ah smart Capacity 100 Ah /200 Ah Rated voltage 12,8 V / 25,6 V... -
Page 10: Temperature Properties
3.1.3. Lade- und Entladeeigenschaften Label GV-12V100Ah GV-12V100Ah smart GV-12V200Ah smart GV-24V100Ah smart Charging method CCCV/IU Charging voltage 10V–14,6V / 20V–29,2 V Maximum charging current Final discharge voltage 14,6 V / 29,2 V Discharge current continuous 150A / 100 A Discharge pulse current (10sec) 450A / 300 A Tabelle 4. - Page 11 Victron Blue Smart IP67 Ladegerät 12/17 Victron Blue Smart IP67 Ladegerät 12/25 4. Installation Table 7. optional small 12V chargers, for more options please email "info@gs-power.net" 4.1. General information Never install or use a damaged battery. Do not short-circuit the battery.
- Page 12 Use the appropriate cable for the connections to avoid overheating or unnecessary losses. It is better to use cables that are too thick. Screw the cable connections or GS-Power copper bars tightly (M8), a loose cable leads to high heat development.
- Page 13 5. Use of the battery 5.1. Charging current The LiFePO4 battery from GS-Power can be charged in about two hours (50A) depending on the charger. When using more powerful chargers, do not exceed the maximum charg- ing current of 50A. Otherwise, the service life will be reduced, especially for batteries with smaller capacity.
- Page 14 LiFePO4 battery during storage. If these instructions are not followed and the LiFePO4 battery is no longer charged when checked, consider it potentially damaged. Do not attempt to charge or use it. Contact your dealer or GS-Power. The self-discharge of the LiFePO4 battery is approximately <10% per year.
- Page 15 Failure to inspect the products within the specified time and to inform the dealer (seller) or GS-Power of any defects will be considered as satisfactory delivery by GS-Power.
- Page 16 (a) general wear and tear, (b) short circuit, (c) overcharging, (d) deep discharge, (e) overheating of GS-Power products, (f) installation of the GS-Power product by persons who are not able to (g) any other improper use contrary to the operating instructions or the safety instructions of GS-Power, (h) any use contrary to the product specifications of this product, (i) any force majeure.
- Page 17 Power pursuant to the coverage of this insurance policy for that particular type of loss. GS-Power has insured itself against certain risks. These policies contain a customary limitation on the insurance benefit payable to GS-Power if and to the extent the event is a Covered Event.
- Page 18 GS.net GmbH & Co KG Bachstr.15 63762 Großostheim Germany...
