VITREOUS CHINA
Semi Inset vanity Basin
Installation instructions for Semi Inset Vanity basin
THIS BASIN MUST BE INSTALLED BY A LICENSED PLUMBER IN ACCORDANCE
WITH LOCAL REGULATIONS
Remove all products from packaging:
Check the product for damage, if the product is damaged return to store of purchase.
Check the product is complete with all components required to install.
This product is to only be installed by a licensed plumber, failing to do so will void
warranty.
This product is to be installed as per Australian Standard and local authority
requirements.
Basin Installation:
1.This basin is supplied with a cut out template, due to manufacturing variations
it is recommended you cross check the cut-out template dimensions against
the physical basin dimensions and adjust cut out size as, or if required.
2.Lay the template in the desired position on the bench and tape down to secure
the template into position.
3.Prior to cutting the hole, check to ensure the cut-out does not interfere with
draws or internal walls of the vanity cabinet.
4.Cut the hole into the vanity cabinet top.
5.Fit the basin into the cut-out hole to ensure the basin fits correctly and no further
adjustment of the cut-out hole is required.
6.Prior to fitting the basin it is recommended the tapware and waste are assembled
to the basin for ease of assembly.
7.Prior to fitting the basin to the bench top run a plumbers grade silicone seal
around the cut-out hole.
8.Insert the basin into the bench top cut-out and align so the basin is square to
the vanity cabinet top.
9.Apply a bead of plumbers grade silicone around the outer edge of the basin
to prevent water going under the basin. Allow the silicone to dry.
10.Connect Basin to drainage system as per Australian standards and local
authority requirements.
2018-12/Version 1.0
Munich
Product code:MU7063C
CARE & MAINTENANCE
Avoid using abrasive or acid based cleaning products.
WARRANTY:
This basin is warranted to be free from manufacturing defects for a period of:
10 Years vitreous china
1 Year, parts and labour.
This warranty does not cover against normal wear and will be voided if the product
is misused or not installed in accordance with these instructions.
In the event this product is rendered obsolete and a replacement product is required.
Oliveri Solutions Pty Ltd reserves the right to supply a product of equal substitution
at their discretion.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have
the goods repaired or replaced if the goods fail to be acceptable quality and the
failure does not amount to a major failure.
SERVICE
If the basin requires servicing, please contact your installer (preferably the one who
installed it). If the installer is satisfied that the problem is not due to poor installation,
contact T2 Services Pty Ltd for assistances on:
Ph :( 07) 55960738
Fax :( 07) 55273353
Email:oliveri@t2services.com.au
https://oliveri.com.au/service-and-warranty
If the warranty service agent finds that the basin is not faulty, T2 Services Pty Ltd
reserves right to pass on any callout fee to the householder.
MU7063C Installation Instructions
