EVOCLEAR
MEDIA FILTERS
Installation and Operation Manual for
EVOCLEAR MEDIA FILTERS
S SERIES | E SERIES
This equipment must be installed and serviced by a qualified technician. Improper installation can create electrical
hazards which could result in property damage, serious injury or death. Improper installation will void the warranty.
This manual contains important information about the installation, operation and safe use of this product. Once
the product has been installed this manual must be given to the owner/operator of this equipment.

Advertisement

loading
Need help?

Need help?

Do you have a question about the EVOCLEAR S Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Evolution EVOCLEAR S Series

Summary of Contents for Evolution EVOCLEAR S Series

  • Page 1 EVOCLEAR MEDIA FILTERS Installation and Operation Manual for EVOCLEAR MEDIA FILTERS S SERIES | E SERIES This equipment must be installed and serviced by a qualified technician. Improper installation can create electrical hazards which could result in property damage, serious injury or death. Improper installation will void the warranty. This manual contains important information about the installation, operation and safe use of this product.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1.0 FOREWORD ....1 2.0 SAFETY..... . 1 3.0 INSTALLATION .

  • Page 3: Foreword

    The operating safety of the filter is only guaranteed if the installation and operation instructions are correctly followed. In the event of defective operation or fault, contact Evolution or its nearest authorised service agent. To reduce the risk of injury, do not permit children to use this product.

  • Page 4: Installation

    INSTALLATION GENERAL 3.1.1 Position the filter as close to the swimming pool/spa as possible. 3.1.2 Position the filter so it is free from flooding, drainage infrastructure and areas where water may pool, such as ditches, guttering, garden hollows, etc. 3.1.3 Position the filter so that the piping connections, Multiport Valve and winter drain is convenient and accessible for operation, servicing and winterising.
  • Page 5 FILLING THE FILTER MEDIA 3.2.1 Before filling the filter media into the filter vessel, carry out a visual check of the laterals. Look for broken or loose laterals. Replace if necessary. 3.2.2 To eliminate stress on the laterals, fill the filter vessel half full of water to provide a cushioning effect when the filter media is poured in.

  • Page 6: Multiport Valve Operation

    MULTIPORT VALVE INSTALLATION 3.4.1 Top Mount Media Filters are supplied with either a top mounted screw down Multiport Valve or a clamp down Multiport Valve. 3.4.2 Side Mount Media Filters are supplied with a side mounted Multiport Valve with a plumbing kit designed to be connected to the side ports of the filter.
  • Page 7 FILTER - POSITION FOR FILTRATION. Incoming water from the piping system is automatically directed by the Multiport Valve to the top of the filter bed. As the water is pumped through the filter bed, dirt and debris are trapped by the filter bed. The filtered water is returned from the bottom of the filter vessel through the Multiport Valve and back through the piping system.

  • Page 8: Initial Startup Of Filter

    INITIAL STARTUP OF FILTER Be sure the correct amount of filter media is in the filter vessel and that all connections are hand tightened. Depress Multiport Valve handle, rotate to the BACKWASH position, and open the air release valve on the filter or Multiport Valve. Note: To prevent damage to control valve seal, always depress handle before turning.
  • Page 9 CONDITIONS FOR BACKWASHING 6.3.1 The requirements for backwashing are determined by the following conditions: 1. The flow rate through the filter bed decreases until it is insufficient to meet the demand. 2. The debris removal efficiency of the filter bed decreases to the point where filtered water quality deteriorates or results in dirt or debris returning to the pool.

  • Page 10: Maintenance

    MAINTENANCE The filter media will only require replacement once it has reached the limits of its designated life. Refer to the product information of the particular filter media used. To ensure the maximum life of the selected filter media, please follow the procedures below: 1.

  • Page 11: Troubleshooting

    TROUBLESHOOTING Fault/Problem Possible Causes and Remedies Scoring or jamming with foreign matter or debris. If this condition persists after Above normal or rinsing, disassemble the valve to clear dirt and debris. Continued operation of the excessive force valve may result in a non-sealing condition (damage to spider gasket). This will lead to operate the to water loss to the backwash line or to inefficient filtration.
  • Page 12 1/33 Hinkler Drive, Highland Park QLD 4211, Australia +61 7 5565 0000 Unless otherwise indicated, copyright in the content of this document is the property of Evolution Water and Lighting Solutions under Australian copyright law. Unless otherwise indicated, content may not be reproduced or transmitted without our prior written permission.

This manual is also suitable for:

Evoclear e series
