Carry Freedom Y-Surf Manual

MANUAL
english
Y Surf Manual
Welcome
Thank you for buying a Carry Freedom Y-Surf
attachment for your Y-large trailer. These
instructions will help you get the most out of
your new Y accessory.
Read these instructions carefully before use.
IMPORTANT:
It is your responsibility to understand these
instructions. We do not accept responsibility
for how you use, modify, ride, or load the
trailer. You must decide if what you are doing
with the trailer is safe, within your ability, and
within the law. Please check your highway
laws concerning bicycles and trailers.
Parts List
2 x u-shaped side bar
1 1
2 x adjustment post
2
2 x crossbar
3
2 x foam for crossbar
4
4 x square rubber tube cap
5
4 x bolt/washer/binder bolt for adjustment post assembly M6
6
4 x rubber cap round for crossbar
7
4 x rounded plastic saddle washer, bolt and washer for crossbar assembly M8
8
4 x eye ring and spring washer
9
4 x bolt/washer/washer/nyloc nut M6
10
5
4 x
6
4 x
8
4 x
GB
7
4 x
9
4 x
2
2 x
3
2 x
10
4 x
Y-SURF
Tools
needed for assembly
1 x allen key 4 mm
1 x allen key 5 mm
1 x allen key 6 mm
1 x wrench 10 mm
1 x electric drill (pre-2017 trailers)
1 x 6,5 mm drill bit (pre-2017 trailers)
4
2 x
1
2 x
