DSE NOVA User Manual

Warm white led blinder
Hide thumbs

Advertisement

Quick Links

Download this manual
NOVA WARM WHITE LED
BLINDER
USER MANUAL
Please read the instructions carefully before use.

Advertisement

loading
Need help?

Need help?

Do you have a question about the NOVA and is the answer not in the manual?

Questions and answers

Summary of Contents for DSE NOVA

  • Page 1 NOVA WARM WHITE LED BLINDER USER MANUAL Please read the instructions carefully before use.

  • Page 2: Table Of Contents

    5. Fixture Cleaning STATEMENT FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE INSTALLING AND POWERING YOUR NOVA WARM WHITE LED BLINDER. This device has left our premises in absolutely perfect condition. In order to maintain this condition and to en-sure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this manual.
  • Page 3 overload wall outlets and extension cords as this can result in fire or electric shock. DO NOT allow anything to rest on the power cord. DO NOT locate this fixture where the cord may be damaged by persons walking on it. Make sure that the power cord is never crimped or damaged by sharp edges.
  • Page 4 approximately 20 minutes prior to manipulate with it. Operate the fixture only after having familiarized with its functions. DO NOT permit operation by persons not qualified for operating the fixture. Most damages are the result of unprofessional operation. Please use the original packaging if the fixture is to be transported. Please consider that unauthorized modifications on the fixture are forbidden due to safety reasons.

  • Page 5: Technical Specifications

    2. Technical Specifications FEATURES Features:  Easy multi fixture hanging system, outdoor version available;  4x 100W 3000k LED, no ultraviolet radiation;  Over 50,000 hours life of the LED light source;  1300 lux in 5 meters;  60 degrees beam angle; ...
  • Page 6 DISPLAY MENU MAIN MENU Sub-menu Values Default DMX address ADDRESS 1 - 512 setting Channel 1Ch Channel 3Ch Channel Channel 4Ch Channel 9Ch Channel 9Ch Channel 10Ch CONFIGURATION Disable MODE Screen on Disable Enable Disable Keep DMX Disable data Enable Enable Fast Mode Enable...
  • Page 7 MAIN FUNCTIONS 1. ADDRESS: current DMX address A. Setting DMX address by button  Press [ENTER] button when shown the address menu, then adjust the DMX address by pressing [UP] and [DOWN] buttons.  Press [ENTER] to confirm or pressing [ESC] to return to main menu. B.
  • Page 8 C. Keep DMX data  Press [ENTER] button when shown the keep DMX data in the sub- menu and by pressing [UP] and [DOWN] buttons, enabling or disabling the function LEDs all on. D. Fast mode  Press [ENTER] button when shown the fast mode menu, then select able or disable by pressing [UP] and [DOWN] buttons.
  • Page 9 Fast to 241-255 Random slow 4CH MODE Function Value Description Remark LED head 1 000-255 0-100% LED head 2 000-255 0-100% LED head 3 000-255 0-100% LED head 4 000-255 0-100% 9CH MODE Function Value Description Remark Master 000-255 0-100% Dimmer Fine Master 000-255...
  • Page 10 Inverted square 128-191 S-curve 191-255 10CH MODE Function Value Description Remark Master 000-255 0-100% Dimmer Fine Master 000-255 0-100% Dimmer 000-015 No Function Slow to 016-240 Strobe Strobe fast Fast to 241-255 Random slow LED head 1 000-255 0-100% LED head 2 000-255 0-100% LED head 3...

  • Page 11: Troubleshooting

    4. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and fan. 1. Check the connection of power and main fuse. 2. Measure the main voltage on the main connector. 3.
