Summary of Contents for Carry Freedom Y
- Page 1 MANUAL XL english a bike trailer revolution...
- Page 2 Parts List Y trailer x-large - maximum load 90 kg (200 lbs), with Quick Release axle 50 kg Y large - Hitch arm load (nose weight): min. 3 kg, max. 10 kg 1 x tow arm 2 x wheel 2 x velcro load strap...
- Page 3 FINISH: DEBUR AND DO NOT SCALE DRAWING REVISION DIMENSIONS ARE IN MILLIMETERS sandblasted BREAK SHARP Used GmbH - Carry Freedom SURFACE FINISH: EDGES TOLERANCES: anodized, silver LINEAR: +/- 0,5 mm ANGULAR: Drawings Property of the USED GmbH, Am Bahnhof 3, 49610 Quakenbruck, Germany...
- Page 4 Assembly Fix the frame (#4) to the load bed (#7), using the bolts, washers and nuts provided (#6). The frame is attached to the non-griptape side of the loadbed (#7). Important: We also suggest a drop of oil on the thread to make the assembly easier.
- Page 5 Waterproof Ortlieb Rack Packs can clip directly to the load bed, the 48 l for the Y small, and the 90 l for the Y large. Carradice of Nelson make a special Y-Bag for Carry Freedom Y small.
- Page 6 The hitch-arm load (nose weight) must be within A box can be bolted permanently to the Y or fitted this range: 3 kg to 8 kg (Y small) - 3 kg to 10 kg (Y with our box quick release. The center of the box...
- Page 7 85 or 105 cm. The normal width is 50 good condition, are there any tears? and regulations about lights and reflectors. We cm for the Y small and 65 cm for the Y large. Mainly have tested the trailers against the German Law on DO THIS: used for Kayaks and canoes when extra width is lights and reflectors.
- Page 8 Safe a large FAQ. Also check the Downloads Page. A bicycle towing a bicycle trailer handles Contact us if anything is still unclear. Check out the other trailers in the Carry Freedom normally. It corners predictably, and remains portfolio: Blog manoeuvrable.
