Summary of Contents for binardat SIG1
- Page 1 Outdoor Wireless Bridge User Manual 2.4G/5.8G Bridge Multi-language Version English/Deutsch/Italian/ French/Spanish...
- Page 2 Hardware connection schematic diagram 2.4G Bridge 5.8G Bridge (1) 5.8G Bridge (2) Interface Descriptions DIP Switch: To adjust the transformation between the main AP mode and the secondary AP mode of the bridge. DC: Power interface,12V 1A DC power interface. Digital Switch/Reset: Both digital switch and reset button, short press the button when electrifying, the numeric value of the digital tube will be added one and press 15 seconds, the device will be restored to the...
- Page 3 Signal indicator: Master AP: Output power indicator lamp. When the output power is less than 17dbm, the SIG1 light lit, the output power is between 17~19dbm, the SIG1-SIG2 lights lit, the output power is between 20~22dbm, the SIG1-SIG3 lights lit, the output power is at 23dbm and above, the SIG1 to SIG4 lights lit.
- Page 4 10~16dbm,the SIG1-SIG2 lights lit,the output power is between 20~22dbm,the SIG1-SIG3 lights lit,the output power is at 23dbm and above,the SIG1 to SIG4 lights lit. Subordinate AP: Signal connection intensity indicator Running flowing water light when connection fails.
- Page 5 Digital tube and wireless channel comparison table 2.4G Bridge G Bridge Note: 1. The default channel bandwidth of the wireless bridge is 40MHz; 2. The number of channels supported by some wireless bridges will vary. Please refer to the actual product. Setting up a bridge in a browser Computer settings 1.
- Page 6 Login management interface The default mode of the device is the bridge mode, open the computer browsers, after entering its address 169.254.254.254, the bridge device list will be displayed, and clicks on the [login] button to log in to the device.
- Page 7 Description: The device supports bridge mode and route mode in the“M” AP mode, but only support the bridge mode in the “S” AP mode. Wifi settings Note: Some wireless bridges do not have this function. Please refer to the actual product for details. The default WiFi name of the 2.4G Bridge is Brap-2G-XXXX, the password is 88888888.
- Page 8 Schnittstellenbeschreibungen DIP-Schalter: Zum Einstellen der Transformation zwischen dem Haupt- AP-Modus und dem sekundären AP-Modus der Bridge. DC: Stromschnittstelle, 12 V 1 A DC-Stromschnittstelle. Digitaler Schalter/Reset: Sowohl digitaler Schalter als auch Reset- Taste, drücken Sie kurz die Taste beim Elektrifizieren, der numerische Wert der digitalen Röhre wird eins addiert und 15 Sekunden drücken, das Gerät wird auf die Werkseinstellung zurückgesetzt.Schnelle Kopplung DigitalschaltersEins-zu-Eins-Pairing-Methode...
- Page 9 Accoppiamento rapido dell'interruttore digitale Metodo di abbinamento uno a uno 1. Comporre un ponte su "M" e un altro ponte su "S". 2. premere premere il pulsante "Dig SW/Reset", ogni valore del tubo digitale ne aggiungerà uno (ciclo 0-9-A-F). 3. Il bridge accoppiato è impostato sullo stesso valore e può essere accoppiato correttamente.
- Page 10 Appariement rapide du commutateur numérique Méthode d'appariement un à un 1. Composez un pont sur "M" et un autre pont sur "S". 2. Appuyez brièvement sur le bouton "Dig SW/Reset", chaque valeur de tube numérique en ajoutera un (cycle 0-9-A-F). 3.
- Page 11 Emparejamiento rápido del interruptor digital Método de emparejamiento uno a uno 1. Marque un puente a "M" y otro puente a "S". 2. Presione brevemente el botón "Dig SW/Reset", cada valor de tubo digital agregará uno (ciclo 0-9-A-F). 3. El puente emparejado se establece en el mismo valor y se puede emparejar con éxito.
- Page 12 Wuhan niannianxingchen Technology Co.,Ltd. No. 349 Guanshan Road, Gaoxin Avenue, Wuhan, Hubei, China support@binardat.com www.binardat.com...
