The SDX-15 Alarm
System
for
Piped Medical Gases
issue 11
02-06-2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDX-15 and is the answer not in the manual?

Questions and answers

Related Manuals for SHIRE CONTROLS SDX-15

Summary of Contents for SHIRE CONTROLS SDX-15

  • Page 1 The SDX-15 Alarm System Piped Medical Gases issue 11 02-06-2021...
  • Page 3 10 years from the than a buzzer, to give a mellow sound which, whilst date of supply of the original system. The SDX-15 is fully drawing attention to the alarm condition, can be back compatible with earlier SDX-15 alarms and indeed tolerated by sta otherwise occupied.
  • Page 4 Connect the inter-panel signal wiring to terminals 1 & 2 for the condition relating to the faulty line, and a system on the power supply board, observing polarity. fault visual and audible alarm will appear on this panel. WARNING. Ensure that cable screen,...

  • Page 5: Computer Interfaces

    Remember that a plant to alarm interface is A 230Vac, 50/60 Hertz supply is required. cheaper than a one service repeater with internal Note. This is the only item on the SDX-15 transmitter for locations where local indication is required.

  • Page 6: Operation

    If a Contact Line fault (number 4) is indicated, Section 7 check that resistors are t ted in all unused conditions on OPERATION ¡ the internal transmitter, that the termination boards are All that is required for routine operation is for t ted and the cabling between termination board and to mute the audible alarm on alarm panels in their ¡...

  • Page 7: Section 8 Fault Finding

    FAULT FINDING ¡ Properly installed, the SDX-15 alarm system will panel is set to be a central. If it is then t a service ¡ give many years of trouble-free service. Experience exchange board (Remember.

  • Page 10: Declaration Of Conformity

    Tel. (01279) 434399 United Kingdom www.shirecontrols.com Product Type SDX-15 Plant Alarm System Includes SDX-15 Plant Alarm SDX-15 Remote & Internal Transmitter SDX-15 Plant To Alarm Interface SDX-RTX1 Transmitter SDX-15 Interfaces Year of manufacture 2021 Standards used To which this declaration relates is in...
