MOVING STRAPS
READ ALL INSTRUCTIONS AND VIEW THE ONLINE VIDEOS ON SHOULDERDOLLY.COM BEFORE USE.
DO NOT USE THIS PRODUCT UNLESS YOU FULLY UNDERSTAND THESE INSTRUCTIONS.
Manufacturer is not responsible for any misuse or misrepresentation of the ShoulderDolly.®
WARNING!
• The ShoulderDolly® does not make you stronger than
you are without it.
• Steel toe shoes and back protection are always
recommended.
• Do not use if you have physical limitations or injuries.
• Always clear path of travel.
• Know your lifting capability. The ShoulderDolly® is
designed to lift up to 800 lb (370 kg) maximum.
1
2
1.
Each lifter puts on a shoulder harness like a t-shirt. (Metal buckle facing forward.)
2.
Make sure the shoulder harness crosses in the center of the back. Pull buckle down to remove slack.
3.
Place central lifting strap under the item to be lifted. Either by tipping item or sliding it under the item.
4.
Thread lifting strap through metal buckle. First back then front.
5.
With a straight back, bend knees slightly and adjust lifting strap to item being lifted until there is weight on
shoulders. Place hands on the item, palms at, ngers pointing up. To lift items higher bend knees more while taking in
excess slack from lifting strap.
6.
Con rm each other's state of readiness. When ready, simultaneously stand up and straighten your arms until elbows lock.
Keeping your arms straight is key to stabilizing the object being lifted.
Tip: When rst using the ShoulderDolly®, start with items that are light (small dressers, desks, mattresses, etc.), then slowly build
up to larger and more complicated items.
Tip: When using the ShoulderDolly® on stairs, be sure to keep the item centered and lifting strap tension consistent. Arms must
be kept straight, with elbows locked or slipping can result.
WARNING!
USING OPTIONAL SHOULDERDOLLY®
ARM LOOPS FOR HIGHER LIFTS
Only use the optional arm loops for
higher lifting (i.e. lifting onto a truck
tailgate or loading dock), not while
walking.
1.
Insert lifting strap into tension buckle and adjust length. Position the loops on the forearm, near the elbow. With your back
straight, bend your knees and adjust the strap for desired lifting height. Fold excess shoulder harness and lifting strap over
metal buckle to avoid tripping.
2.
Place palms at on the item, ngers pointed up while communicating with your partner during the lift. Push arms straight
out with a slightly upward angle for maximum vertical lifting. Replace arm loops into elastic when not in use.
Tip: Use a deeper squat when adjusting the lifting strap to lift item higher. The closer the buckle is to the bottom of object the
higher you may lift object.
ShoulderDolly® is a registered trademark of Nielsen Products, LLC. PO BOX 243, Boulder, CO 80306 www.shoulderdolly.com
3
Do not use both the shoulder harness and arm loops at the same time!
1
Be Social and Leave a Review!
#shoulderdolly #movingstraps
ShoulderDolly® Instruction Manual
• Keep consistent tension. Do not lift item from lifting
strap. Slipping can result.
• Always inspect moving straps for signs of wear or
damage before using. Do not use if straps are cut,
frayed or damaged as this may reduce lifting
capacity of the straps.
• Keep these instructions for future reference.
4
For LD1000/LD2000/LD2001
ENGLISH
5
6
2
