Summary of Contents for SERVE CANADA DS 50 USA
- Page 1 DS 50 USA User/Install Manual 3/2019...
-
Page 2: Table Of Contents
TRANSLATION OF THE ORIGINAL INSTRUCTION CONTENTS Page WARNINGS 1. MACHINE INSTALLATION 1.1 Serial number data INSTALLER SECTION 1.2 Receiving the machine 1.3 Storage 1.4 Prepare for installation 1.5 Water connections 1.6 Water supply characteristics 1.7 Positioning the machine 1.8 Electrical connection 1.9 Temperature adjustment 1.10 Rinse aid dispenser operation 2. -
Page 3: Warnings
WARNINGS This instructions booklet must be kept with the machine for future consultations. If the machine is sold or transferred to other users, make sure the booklet always goes with the unit so that the new owner can have all the necessary information on operations and all relevant instructions. The dishwasher shall be installed in accordance with local codes, or in the absence of local codes, installed in accordance with the applicable requirements in the National Electrical Code, NFPA 70, Canadian Electrical Code (CEC), Part 1, CSA... - Page 4 • Make sure the appliance is linked to an efficient ground connection. • Do not open the machine doors when operating. After switching the machine off, wait for at least 15 seconds after the motors stop. WARNINGS: IT IS FORBIDDEN TO INSERT HANDS AND/OR TOUCH INTERNAL PART WHEN THE MACHINE IS OPERATING AND/OR AT THE END OF THE WASH CYCLE. • Before using the machine, the personnel shall know the position of the omni-polar switch that disconnected the machine from the electrical network, the position of the water connection shut-off valve and the procedures to switch off and secure the machine.
-
Page 5: Machine Installation
ATTENTION: At the end of installation make sure to remove the parts of this booklet relevant to the installer, for future consultation. 1. MACHINE INSTALLATION 1.1 Serial number data FAMIGLIA PRODOTTO RoHS PRODUCT FAMILY FAMILLE DU PRODUIT FAMILIA PRODUCTO FAMILIE DES PRODUKTES CODE DWXXXX FAMIGLIA PRODOTTO PRODUCT FAMILY FAMILLE DU PRODUIT FAMILIA PRODUCTO IPXX FAMILIE DES PRODUKTES CODE DWXXXX.YYYY... -
Page 6: Installer Section
INSTALLER SECTION 1.2 Receiving the machine Pay special attention in choosing the lifting points and the machine barycentre during the loading and unloading operations. Before accepting the machine, verify that all the data on the data-plate corresponds to the required ones (as shown on par. 1.1) and to the ones of the available electrical supply. After unpacking, make sure the machine has not been damaged during transportation. If so, do notify the seller immediately about the problem. If the damage might question the machine safety, do not install it. Double check the firm tightness of all hose-clamps on piping, nuts, bolts and electrical connection that might have come loose during transportation, to prevent water dripping leakages, or other damages, during the machine operation. See chap. 7 for disposing the packing material. -
Page 7: Positioning The Machine
INSTALLER SECTION 1.7 Positioning the machine Remove the packing with care. Maintain a minimum distance of about 2 inches (50mm) from the walls, so that motors are ventilated. Check that the machine is properly levelled, by adjusting the legs. Make sure the machine is not standing on the power cable or on the filling/drain hoses. Level the machine flat, by adjusting the support feet. 1.8 Electrical connection Only qualified and properly trained personnel can operate on the electric board and connections. Before the installation: Make sure that the voltage is the same as reported on the data-plate. Make sure the line voltage matches the machine power and voltage indicated on the machine data-plate (as shown on par. -
Page 8: Rinse Aid Dispenser Operation
INSTALLER SECTION 1.10 Rinse aid dispenser operation Operation: it utilizes the difference in combined pressure caused by turning the washing pump on and off, and the rinse pressure. Water connection: 1) Connect the dispenser tube fitting A to the pump, by means of the rubber tube installed in the appliance (pump pressure). 2) Connect the small black rubber tube by the brass delivery fitting B to the connection near the boiler (injector). 3) Make sure that the green product suction tube is inserted on the special fitting C and that the small filter and the ballast are inserted in the rinse aid tank. Priming: To prime the dispenser, turn on the appliance and carry out several complete wash cycles or press the adjustment screw during the wash cycle and open and close the door combined with pressing the pin D. -
Page 9: Detergent Dispenser Installation
INSTALLER SECTION 2. DETERGENT DISPENSER INSTALLATION 2.1 Electrical connection Follow the wiring diagram attached to the machine. 2.2 Water connection a) Remove the cap from the hole and fit the delivery connection. b) Correctly mount the injector C using the appropriate fixtures. c) Connect the suction tube to the suction attachment of the dispenser (see pict. 2 - point A). d) Connect the delivery tube to the other attachment of the dispenser, and the delivery fitting (see pict. 2 point B). e) Insert the suction tube with filter in the detergent tank. f) Prime the detergent and proceed to dispense. pict. 1 2.3 Dispensing the detergent The detergent dispenser capacity can be adjusted using a screwdriver as shown in picture 1. -
Page 10: User Section
USER SECTION 4. CONTROL PANEL AND RELATIVE SYMBOLS CONTROLS INDICATORS ON/OFF switch 0-1 Power on indicator Cycle START button Tub Temperature Supplementary cold rinse Washing cycle button indicator Water Pressure Manual empty button (optional) BoilerTemperature indicator Wash type selector (if provided) 5. OPERATION • Insert the overflow tube in the special seat inside the tub (pict. 4) • Check that the filter is correctly fitted in its seat (pict. 4). The filter must be cleaned after every 20 wash cycles and whenever necessary. -
Page 11: Warnings
USER SECTION • Place in tilted position the dishes with deep hollows, so that the water can drain. • Make sure that the smaller dishes do not fall from the baskets. • Check all the wash arms runs freely and they are not blocked by too tall or too prominent crockery. Eventually, run a manual rotation of the arms to check it. Some foods, such as carrots, tomatoes, and others, may contain some natural dyes substances, that in large amounts, can alter the crockery and plastic parts colors. Any discoloration does not mean that the plastic is not heat resistant. -
Page 12: Detergent Use
USER SECTION 5.2 Detergent use ONLY use NON FOAMING types suitable for industrial glass-washers and dishwashers. It is advisable to use liquid detergents. The detergent must be put directly in the tub. The correct amount will be suggested by the product manufacturer according to the water hardness. By request, the dishwasher can be equipped with an automatic detergent dosing pump (always recommended). inches (1 cm) of the product drawn into the tube is equal to about Dr (0,15g). A correct amount of detergent is very important for a successful wash. This machine must be operated with an automatic detergent dosing pump. -
Page 13: Maintenance
USER SECTION 6. MAINTENANCE 6.1 Routine maintenance ATTENTION: The machine is not protected against pressurized water sprays. Do not use pressure cleaning systems against the machine. It is recommended to contact your chemicals distributor for proper cleaning instructions, in order to have detailed indications on methods and products suitable for the correct periodical machine sanitation. -
Page 14: Ecological Aspects
USER SECTION 8. ECOLOGICAL ASPECTS 8.1 Recommendations for optimal use of energy, water and additives Use the machine fully loaded when possible This shall prevent detergent, rinse aid, water and energy waste. Detergent and rinse-aid Use detergent and rinse-aid chemicals with high biodegradability, to respect the environment best. Verify the proper dosage in relation to water hardness at least once a year. Excess of product pollutes rivers and seas while an insufficient dosing will cause unsatisfactory dish washing and/or hygiene. -
Page 15: Troubleshooting
USER SECTION 9. TROUBLESHOOTING Type of problem Possible causes Cure The machine does not Main switch not ON. Turn switch ON. turn on The machine does not Water valve shut. Open the hot and/or cold water valve. load water. The spray arm nozzles or the Clean the rinsing arm nozzles, the pipes and the filter. Check solenoid filter are clogged and/or that the water hardness is <10°f. Equip the machine with...
