Summary of Contents for ATTICAUDIO PASSIVE RE-AMP
- Page 1 PASSIVE RE-AMP TRANSFORMER ISOLATED INSTRUCTION MANUAL...
- Page 2 UNBALANCED OUTPUT TO AMPLIFIER OR PEDAL INPUT GROUND LIFT GROUND DISCONNECTED WHEN PUSHED IN OUTPUT LEVEL PHASE OUTPUT OUT OF PHASE Ø WHEN PUSHED IN BALANCED LINE XLR/JACK INPUT OUTPUT IMPEDANCE ADJUSTMENT INTERNAL TRIMPOTS...
- Page 3 RE-AMPING A DI TRACK INSTRUMENT TO INST/HI-Z INPUT GUITAR/BASS/SYNTH/ETC. RECORD A DI/CLEAN TRACK USING AN AUDIO INTERFACE A DI BOX MAY OPTIONALLY BE USED TO PLAY THROUGH THE AMPLIFIER AT THE SAME TIME BALANCED LINE OUT RE-AMP OUT TO TO RE-AMP INPUT EFFECTS AND AMPLIFIER RE-RECORD THE THE TRACK WHILST PLAYING IT THROUGH THE RE-AMP AND AMPLIFIER...
- Page 4 USING EFFECT PEDALS AS OUTBOARD GEAR EFFECT TO RE-AMP OUT TO INST/HI-Z INPUT EFFECTS BALANCED LINE OUT TO RE-AMP INPUT EXPAND YOUR MIXING TONAL POSSIBILITIES BY RE-RECORDING DRUMS, VOCALS AND SYNTHS TRACKS THROUGH GUITAR PEDALS OR AMPLIFIERS...
-
Page 5: Output Impedance
ADJUSTING THE INTERNAL OUTPUT IMPEDANCE REMOVE THE BACKPLATE BY UNSCREWING THE FOUR SCREWS AT THE BACK OF THE ENCLOSURE THE IMPEDANCE CAN BE SET SEPARATELY FOR THE TWO DIFFERENT OUTPUTS AS INDICATED ON THE PCB USING A SMALL FLAT SCREWDRIVER, START WITH THE IMPEDANCE AT NOON AND INCREASE OR DECREASE THE IMPEDANCE ACCORDING TO WHAT SOUNDS BEST HALF (12.5kΩ) - Page 6 NEED HELP? FEEL LIKE DISCUSSING SOUND OR MUSIC? DROP US A MESSAGE ATTICAUDIO.MT...
