Summary of Contents for AAUK UBAS610SS
- Page 1 Built-in Electric Oven UBAS610SS UBAS609G WARNING: Read the instructions before using the appliance.
- Page 2 Checking instructions These instructions are for your safety. Please read the following instructions carefully before proceeding with the installation and use of this appliance. Keep the instruction manuals for future reference. WARNING: All installation work must be carried out by a suitably qualified person, strictly following local building regulations and these instructions.
- Page 3 Safety Make sure that the supply cord is not caught under or in the appliance and avoid damage to the supply cord. Do not install the appliance outdoors in a damp place or in an area which may be prone to water leaks such as under or near a sink unit.
- Page 4 Safety Danger of burns! During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. Do not lean on the door or place any objects on the door of the appliance. This can damage the door hinges. The oven must be installed in accordance with installation instructions and all dimensions must be followed.
- Page 5 Safety The fused spur should be installed in an easily reachable place so that in case of emergency the appliance can be disconnected from power immediately. The fixed wiring must be protected against heat surfaces. Do not hang any objects on the handle of the oven door. CAUTION: Do not cover the bottom of the oven with aluminium foil or other objects.
- Page 6 Safety WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. The appliance must not be installed behind a decorative door in order to avoid overheating.
- Page 7 Let's get started... Getting started... Checking instructions Safety Before you start more detail... Your product Function & Settings Care and maintenance Troubleshooting Technical date Recycling & disposal Appendix Installation...
-
Page 8: Before You Start
Before you start [02] x 1 [03] x 1 [01] x 1 [04] x 1 [06] x 4 [05] x 4 To avoid the risks that are always present when you use an electrical appliance it is important that this appliance is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards. -
Page 9: Your Product
Your product 10 a c d 12 Control panel. Fixing openings Oven lamp Shelf level Door Power cable Temperature indicator Temperature knob Cooking mode knob Reduce Minutes Timer function selector Increase Minutes Display Description of the timer functions: Cooking in automatic Warning alarm mode (duration) End of cooking time... -
Page 10: Setting The Clock
Function & Settings Setting the clock Once the appliance is connected to the power source, the display shows12:00 and the indicator will flash until we enter the right time. . The clock is now available for setting in 24-hour format. To set the right time, press to adjust. -
Page 11: Function & Settings
Function & Settings Setting warning alarm You have the possibility to set a timer to remind you to turn on the oven. You can also use this function as a kitchen timer to set a time frame for other tasks not necessarily related to this oven. An independent audible signal that can be set to a maximum time of 23 hours and 59 minutes. -
Page 12: Practical Example
Function & Settings Setting Automatic cooking This function is used to cook for a certain duration and stop at a certain end time.Before using this function, ensure to:Place the food into the oven first. Start and end of cooking: 1. Programme the cooking time by pressing twice and selecting the required time with 2. -
Page 13: Care And Maintenance
Care and maintenance Cleaning Before cleaning or performing maintenance, disconnect the oven from the power supply. To extend the life of your oven, it must be cleaned frequently, keeping in mind that: Do not use abrasive powders or corrosive substances which could ruin the surfaces. The inside of the oven should preferably be cleaned immediately after use, when it is still warm, with hot water and soap. - Page 14 Care and maintenance WARNING! Ensure that the appliance is switched off and completely cool before replacing the lamp to avoid the possibility of electric shock or burns. Oven cleaning system equipped with the AQUASMART SYSTEM 1 Take out the internal components: tray, screen, side screens. 2.Pour 200 ml of soapy water on the bottom of the oven.
-
Page 15: Replacing The Oven Light Bulb
Care and maintenance Replacing the oven light bulb Remove all pans and grills from inside the oven to easily access the lamp cover (3). Unscrew the glass cover and remove the old lamp. Dispose of it safely and ecologically. Insert a new G9 halogen lamp into the lamp holder. -
Page 16: Troubleshooting
Care and maintenance Removing the Inner Glass for Cleaning To simplify cleaning, the Inner glass panel can be removed. After loosening 2 screws fixing the side supports of the glass, remove the supports and then the glass panel. Handle with care! After cleaning, replace the glass panel in the reverse order. -
Page 17: Recycling And Disposal
220-240V~50/60Hz Maximum Power 2000-2380W Item Symbol Value Declared Unit Model identification UBAS610SS & UBAS609G Type of oven Single fan oven Mass of the appliance Number of cavities Heat source per cavity (electricity or gas) Electricity Volume per cavity Energy consumption (electricity) -
Page 18: Installation
Installation All installation must be carried out by a competent person or qualified electrician. Before connecting the mains supply ensure that the mains voltage corresponds to the voltage on the rating plate. 1.Plug connection This appliance is equipped with a plug(conforming to BS1363) fitted with a 13 amp fuse.Should the fuse fail, then it must bereplaced with an ASTA approved fuse (conforming to BS1362) of the same rating. - Page 19 Installation Upper vent 25mm at rear...
- Page 20 Installation [03]X4 [04]X4 [02]x1...
- Page 21 AAUK Ltd, Unit 3 Normandy Landings, Pope Street, Castleford, WF6 2AG...
