Alitronika DVS AT88IP Manual

Digital Video Interfacing Products
AT88IP
TS-over-IP
Receiver/Converter/Recorder
DVB-T2/T/C to DVB-ASI & IP Converter
Pro-MPEG Code Of Practice #3(COP3) FEC
Standard Features
DVB-T2/T/C to IP & DVB-ASI Receiver, Recorder Converter.
- Receives DVB-T2/T/C TS & converts into ASI & IP in real time.
- Records TS using Free application DVSStationIP.
- Web based Software as well as DVSStationIP.
- DVSStationIP runs on Windows XP, Vista, Windows 7.
- Remote Web-based configuration management.
- Remote firmware upgrade.
- Saved configuration settings.
- No re-configuration needed after system reboot.
- An alternative to dedicated satellite links.
- Connects digital video equipment to computer networks.
- Encapsulation of the TS data for Ethernet uses IP and the UDP),
with RTP encapsulation and Pro-MPEG COP3 FEC as an option.
- Dedicated hardware performs the encapsulation,
which maximizes the throughput and minimizes latency.
IP
- IP Maximum rate of up to 214 Mbps per ASI channel.
- Network jitter correction.
- Supports constant bit rate ASI output.
- IP address assignment from DHCP server & static IP.
- IP address also configurable through the web interface.
- Configuration for Time To Live (TTL) for Multicast.
DVB-T2/T/C Input
- RF Tuner Connector: 75 Ohms IEC female Type.
- Loop Through Connector: 75 Ohms IEC male Type.
Input Frequency Range:
High Band: 434.0 MHz to 858.0 MHz.
-
- Mid Band: 149.5 MHz to 426.0 MHz.
Low Band: 50.5 MHz to 142.5 MHz.
-
- Channel Bandwidth: 6, 7 & 8 MHz.
- RF Sensitivity: -80dBm
- COFDM Spectrum (DVB-T2/T):
2k and 8k carriers non-hierarchical and hierarchical.
- Modulation Modes: DVB-T/T2: QPSK, 16QAM, 64QAM
- Modulation Modes: DVB-C: 64QAM, 128QAM, 256QAM
- Guard Interval Modes: 1/4, 1/8, 1/16, 1/32.
© 2017 Alitronika DVS AT88IP
Application
Targeted for Digital Video Professionals,
Sophisticated End Users and OEMs
the AT88IP is an ideal solution for a
number of applications such as:
- Development Tools.
- DVB to IP Gateway.
- Video on Demand Server.
- Transport Stream Test Generator.
- Studio to Transmitter Links.
- ENG (Electronic News Gathering) Stream
content to and from remote locations.
- ASI input to Cable System.
- Providing an ASI input for decoders,
Multiplexers, Modulators.
Specifications
DVB-IP
- Ethernet encapsulation: IEEE 802.2 SNAP, Eth.
- Encapsulation: UDP or RTP
- IP support: IPv4
- IP-address assignment: DHCP link local or static
- Multicast support: IGMPv2
- Date Rate: 100/1000
- GigE port Physical layer: IEEE 802.3a
- GigE port Connector: RJ-45 with LEDs
- FEC: Pro-MPEG Code Of Practice #3(COP3)
- TSoverIP to ASI latency: Less than 1ms
- Jitter tolerance range: 500ms
DVB-ASI
- Port Physical layer: EN50083-9
- Connector: 75 Ohms Mini BNC
- Input Return Loss: >15 dB.
- Input Signal level: 800 mV +/- 10%
- Output Signal level: 1.0Vp-p nominal.
- Input/Output Bit Rate: 0 to 214 Mbit/s.
DVB-T2/T/C
- Standards: DVB-T2/T/C.
www.alitronika.com
