ACE LEDS Pencil AC12CD350APT7L Manual

AC12CD350APT7L Pencil
PRIMARY SPECIFICATIONS:
Output Input Input
Power Power Current
0.15 A @ 120 V
12 W 14 W
0.06 A @ 277 V
PHYSICAL:
WIRING:
BLACK
LED
(LINE)
DRIVER
WHITE
(NEUTRAL)
SAFETY, RATINGS AND PROTECTION:
• UL and CUL recognized
• Class 2 output
• Over current protection: 95-108%
• Open circuit and short circuit protection
• Working ambient temperature range: -36-70°C
• Working relative humidity: 5-100%
• Storage temperature: -40-85 °C
• Storage relative humidity: 5-100%
• Damp location: Use only within an enclosure
• Inrush current: 25 A @ 230 Vac cold start ±
• MTBF: >200 khrs to MIL-HDBK-217 @ 25˚C, GB
• Vibration: 10-500 Hz, 5G 12 min./lcycle, period for 72 minutes each
along X, Y, and Z axis
For questions or to place an order contact us at
or your local WPG American Sales representative at
©2022 5July2022
Input Voltage 120-277 Vac, 50/60 Hz
Output Power 12 W (max)
Programmable LED Driver
TM
Min PF Max THD Output
Voltage
(full load) (full load)
>0.95 <20% 9-32 V
RED +
BLUE -
PURPLE (DIM+) V+
0-10V DIMMER
PINK (DIM-)
V-
Formerly Gray
0
25˚C
Data is based upon tests performed by AC Electronics in a controlled environment and representative performance. Actual performance can vary
depending on operating conditions. Specifications are subject to change without notice. All specifications are nominal unless otherwise noted.
Output T Case
Starting
Current Max
140-350 mA, ±5%
90˚C -35˚C
*If Vf < 24 V, ±7%
Dimensions
AC12CD350APT7L
Lead Lengths
Black
White
10V
INSTALLATION:
• IP64
• Mounting: 5.1"
• LED driver cases should be grounded
• LED drivers shall be installed inside electrical enclosures
• Use 18 AWG 600 V, 105
• Max ambient temp if mounted on metal surface to achieve
50,000 hour lifetime (case @ 75 °C) : 62 °C.
• Max ambient temp if not mounted on metal surface to achieve
50,000 hour lifetime (case @ 75 °C) : 51 °C.
WARRANTY:
• 5 Year Limited Warranty, 3 Years @ T case max
APPROVALS:
• UL 8750
• EMC: EN55015, EN61000-4-2,3,4,5,6,8,11
• EN61000-3-2 Class C
• Class P listed
oemsales@aceleds.com
inquiry@wpgamericas.com
LISTED
E332747
Min
IP Efficiency Dimming
Rating Up To
Temp
64 84% 0 to 10 V
Length Width
5.5" 0.75"
5.9" Blue 5.9" Purple
5.9" Red 5.9" Pink
˚C tinned stranded copper wires
or 800-375-6355
or 888-WPG8881
RoHS
COMPLIANT
L E A D - F R E E
Dimming
Protocol Range
0.5-100%
to off
Height
0.75"
5.9"
5.9"
90˚C
LISTED
E332747
