- Page 1 DIL/NetPC DNP/8331 Board Revision 1.0 Hardware Reference SSV Embedded Systems Dünenweg 5 D-30419 Hannover Phone: +49 (0)511/40 000-0 Fax: +49 (0)511/40 000-40 Document Revision: 1.0 E-mail: sales@ssv-embedded.de Date: 2022-04-04...
-
Page 2: Table Of Contents
DIL/NetPC DNP/8331 – Hardware Reference CONTENT INTRODUCTION ....................... 3 Safety Guidelines ........................3 Conventions ........................... 3 Block Diagram ........................4 Features and Technical Data ....................5 PINOUTS .......................... 7 DIL-40 Connector – J1 ......................7 DIL-40 Connector Function Multiplexing ................8 MECHANICAL DIMENSIONS ................... -
Page 3: Introduction
DIL/NetPC DNP/8331 – Hardware Reference INTRODUCTION This document describes the basic hardware components of the DIL/NetPC DNP/8331. Safety Guidelines Please read the following safety guidelines carefully! In case of property or personal damage by not paying attention to this document and/or by incorrect handling, we do not assume liability. -
Page 4: Block Diagram
DIL/NetPC DNP/8331 – Hardware Reference Block Diagram Figure 1: Block diagram of DIL/NetPC DNP/8331 D o c u m e n t R e v i s i o n 1 . 0... -
Page 5: Features And Technical Data
DIL/NetPC DNP/8331 – Hardware Reference Features and Technical Data Processor Manufacturer / Type Sochip S3 with ARM Cortex-A7 CPU Clock speed 1008 MHz Memory 128 MB DDR3 SDRAM Storage media 1x internal microSD card holder (with pre-installed microSD) Interfaces Ethernet 1x 10/100 Mbps 1x USB 2.0 host port with max. - Page 6 DIL/NetPC DNP/8331 – Hardware Reference Figure 2: Board layout DIL/NetPC DNP/8331 D o c u m e n t R e v i s i o n 1 . 0...
-
Page 7: Pinouts
DIL-40 Connector – J1 Please note: The arrangement of the signals in groups has compatibility reasons. Other prod- ucts of SSV with DIL-40 pinout are fully or conditionally pin compatible to the DIL/NetPC DNP/8331 by observance of the corresponding application note. Name... -
Page 8: Dil-40 Connector Function Multiplexing
DIL/NetPC DNP/8331 – Hardware Reference Name Group Function DCD1 COM1 Serial Port, DCD Pin RTS1 COM1 Serial Port, RTS Pin CTS1 COM1 Serial Port, CTS Pin TXD1 COM1 Serial Port, TXD Pin RXD1 COM1 Serial Port, RXD Pin Parallel I/O, Port C, Bit 0... -
Page 9: Mechanical Dimensions
DIL/NetPC DNP/8331 – Hardware Reference MECHANICAL DIMENSIONS All length dimensions have a tolerance of 0.5 mm. Figure 3: Mechanical dimensions of DIL/NetPC DNP/8331 D o c u m e n t R e v i s i o n 1 . 0... -
Page 10: Helpful Literature
Information in this document is provided ‘as is’ without warranty of any kind. Some names within this document can be trademarks of their respective holders. © 2022 SSV SOFTWARE SYSTEMS GmbH. All rights reserved. D o c u m e n t R e v i s i o n 1 . 0...
