JouSecu B245 Instruction Manual

INSTRUCTION MANUAL
Service Email: sales@jousecu.com
Setup and use your video baby monitor
Installing Baby Unit
A. Place Baby Unit on a flat surface, such as a desk or shelf or mount the camera on a wall.
Never place the baby unit or the cord
within 1 meter of the crib.
Connect the small plug of the power adapter to the Baby Unit and the other end to a
B.
suitable electrical outlet. Only use the enclosed adapter (5V DC 1000mA).
The baby unit is turned on and the power LED will be green.
WARNING THIS PRODUCT CANNOT REPLACE RESPONSIBLE ADULT SUPERVISION
· When an AC Adapter is plugged into an electrical outlet, do not the exposed end.
· Test baby monitor before first use, periodically, and when changing loca�on of the baby unit(Camera).
· Do not use monitor near water (Such as bathtub, Sink, etc).
· Keep parent unit away from heat sources (Such as stoves, radiators, etc).
· Make sure there is proper ven�la�on around baby unit and parent unit.
·This product is not a toy. Do not allow children to play with it.
· The mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily
operable.
· The baby monitor should not be considered as a medical device. While using the baby monitor, it is strongly
recommended to have an adult directly checking on your baby. Premature babies or children considered at risk must be
supervised by your pediatrician or other medical staff.
STRANGULATION HAZARD －
B245
Keep this cord out of reach of children (more than 3 feet/1 meter away
from the crib). Never use extension cords with AC adapters. Only use the
WARNING
AC Adapters provided.
Connec�ng the power supply for the Parent Unit.
C.
Connect the small plug of the power adapter to the base braket or the parent unit
and the other end to a electrical outlet. Only use the enclosed
adapter (5V DC/2000mA).
Recommend charging �me of at least 3 hours before first use.
1 meter
Precau�on: use of ba�ery for Parent Unit
Only charge the ba�ery when the ba�ery life indicator is low. Constant recharging of your
ba�ery before the low ba�ery indicator light comes on will decrease the life of your ba�eries.
When ba�ery is low, the power on off LED (icon) will flash red and on screen
display ba�ery icon will flash red indica�ng that the ba�ery needs to be
charged.
Function of keys and LED indicators
Ba�ery Warning
· Use only the original rechargeable ba�ery provided.
· Do not shot-circuit supply terminals.
· Remove ba�ery when product is stored for long periods of �me or when ba�ery is exhausted.
· Dispose of exhausted ba�ery properly.
· Keep all ba�eries away from children.
· The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
· Danger of explosion if ba�ery is incorrectly replaced. Replace only with the same or equivalent type.
· Ba�eries (ba�ery pack or ba�eries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
Children have STRANGLED in cords.
Parent Unit
Warning Information
WARNING
＊Keep this instruc�on manual for
Adult assembly required. Keep small parts
future reference.
away from children when assembling. ＊For adult use only.
Power on off status LED
Steady Green: Parent Unit is powered on. Steady Orange: Charging when monitor is on.
Flash Red: Ba�ery Low. Steady Red: Charging when monitor is off.
When monitor is off, the charging is completed and light will be off.
Power
"On/Off" the unit.
MENU:
menu op�ons.
OK: Short cut to switch camera view
Press OK key to view paired cameras one by
one and enter split screen.
Power Saving on off status
Steady Green: Power saving mode is ac�vated.
Microphone
Press to increase
Volume up:
volume.
Press to
Volume down:
decrease volume.
USB port
Press and hold to talk to baby unit.
Talk
Menu mode (Press to select menu op�on)
Select
OK
Press to switch on/off Power Saving (When power saving mode
Power Saving-on/off
is enabled, screen will be turned off)
VOX
Menu mode (Press to adjust menu se�ngs)
Up/Down
View camera mode(Press to control the current camera to rotate
Camera Up/Down
up/down)
Menu mode (Press to adjust menu se�ngs)
Left/Right
View camera mode(Press to control the current camera to rotate
Camera Left/Right
le�/right)
Precau�ons
· Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electrics
shock.
· The baby monitor works be�er in temperature ranging between 0℃ and 40℃(32℉ and 104℉).
· Do not dismantle the appliance. It does not contain any parts that may be used independently.
· Never expose the baby monitor for long period to sun's direct rays and never place it next to a source of heat, in a damp or
very dusty room.
· Never push objects of any kind into this product through openings they may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
· Do not a�empt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
·The product should be mounted to a wall or ceiling inly as recommended by the manufacturer .
:Press and hold to switch
Press to open and exit
