Vigilant 80DSB Quick Start Manual

Detector Base Sounder

Summary of the device

Product Details
Sounder - Detector Base
80DSB Detector Base Sounder
Accessories
A-CON Conduit Adaptor for Sounder/VID/VAD bases
Performance characteristics
Weight (g)
Housing material
Housing colour
Operating temperature (°C)
Storage temperature (°C)
Humidity
Pressure
AS7240.3 sounder
Vibration, shock, corrosion
Ingress protection
Indoor
EMC
High volume
Mid High volume
Mid Low volume
Low volume
Addressable loop voltage
Quiescent
Sounder only - Low/Mid Low volume
Sounder only - High/Mid High volume
*The Low setting on the 80DSB does not meet the sound level requirements of AS 7240.3
Note: For IP21C protection a fire detector must be fitted.
1/4
The Detector Base Sounder is a loop powered device that is controlled by the detector plugged into it.
A DIL switch sets the required tone and volume level.
The Detector Sounder base prevents the 850 detector built-in short circuit isolator from functioning.
Order number
576.080.001
557.080.002
Up to 95% non-condensing
Sounder SPL output quoted for 1000 mBar
Complies with AS 7240.3 series requirements
EN50130-4, EN61000-6-3
Typical Sounder output at 1 metre
Electrical characteristics
90 uA (without detector fitted)
2.1 mA (without detector fitted)
3.9 mA (without detector fitted)
In scope/fitted
□
□
144
PC-ABS
White
-25 to +70
-25 to +70
Yes
IP21C
Type A
90 dBA
80 dBA
70 dBA
60 dBA*
20 V - 40 V, 35 V Typical
Loop loading
120.515.396.ANZ V1
