ROXX B.FLEX User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User
Manual
B.FLEX | B.FLEX mini
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B.FLEX and is the answer not in the manual?

Questions and answers

Summary of Contents for ROXX B.FLEX

  • Page 1 User Manual B.FLEX | B.FLEX mini USER MANUAL...

  • Page 2: Table Of Contents

    1.2. Regulations for equipment that connects to power mains 1.3. Technical warnsigns and explanation 1.4. Battery Safety 2. Introduction 2.1. About us 2.2. B.FLEX/B.FLEX mini 3. General Product Information 3.1. Scope of delivery 3.2. Control Functions 3.3. Features 4. Installation & Setup 4.1 Physical Installation and Rigging...
  • Page 3 7. Technical Data / Diagrams 7.1 Technical drawings and measurements 7.2 IP Rating 7.3 Technical Data - B.FLEX 7.4 Technical Data - B.FLEX mini 7.5 DMX-Charts / Color Macro Charts / CCT Chart 7.6 RDM Templates 7.7 Firmware Update 8. Troubleshooting...

  • Page 4: Safety Informations

    1.1.1. Please read, understand and follow the instructions. 1.1.2. Store the instructions and information in a safe place. Best solution is the ring binder provided by ROXX. 1.1.3. Follow all safety warnings. Under no circumstances remove safety warnings or other information from the equipment.

  • Page 5: Regulations For Equipment That Connects To Power Mains

    User Manual 1.1.20. Observe all disposal laws applicable in your country. Especially for the packaging. 1.1.21. Plastic bags are not a toy! Keep away from children! 1.1.22. Please note that changes or modifications which are not approved by the party responsible for compliance will void the user’s authority to operate the device.

  • Page 6: Technical Warnsigns And Explanation

    This limits the maximum charging capacity to 40% and thus preserves the life of the battery. Do not charge the battery of the B.FLEX / B.FLEX mini headlamp at ambient temperatures below 0°C / 32°F and above 40°C / 104°F.

  • Page 7: Battery Safety

    User Manual • This is a product which has been developed for professional usage in event technology. It is not suitable as a houshold lighting. • NEVER stare, not even temporarily, directly into the light source. • Don‘t use magnifiers or any other optical instrument to look at the beam. •...

  • Page 8: Introduction

    2.2. B.FLEX/B.FLEX mini The B.FLEX/B.FLEX mini is a battery driven, dual light source fixture for professional use in indoor and outdoor ap- plications such as wall washer, spotlight, deco-effect light and many more. The very narrow beam lens from centric LED, in combination with various filters and the single pixel controllable HALO EFX ring gives room for unlimited creativity.

  • Page 9: General Product Information

    • Stand Alone Functions including cinema effects, various auto programs, customisable scenes, CCT, LEE adjusted color macros and custom color templates (RGBL) • Master & Slave (by DMX and Wireless DMX) • Wireless DMX (Lumenradio CRMX ® • ROXX App - Bluetooth 5.0 3.3. Features...

  • Page 10: Installation & Setup

    Hanging: A centric hole on the yoke´s bottom (d=13mm / 0,51 inch) provides a mounting point for more rigging options like a (Mini-) TV Spigot, to use the B.FLEX/B.FLEX mini on a tripod or for example with a superclamp.

  • Page 11: Anti-Theft

    The position of the safety eyelet and the lamp body balancing makes that possible in a perfect way. Included safety eye bolt for hanging down the B.FLEX / B.FLEX mini.

  • Page 12: Dc Power

    • The battery charge status is shown on the display both when the headlamp is on and when it is in standby mode. • The charging time from 0% charge status to 100% charge status is approximately 5 hours at B.FLEX and 3 hours at B.FLEX mini.

  • Page 13: Dmx Connection

    If using a cabled DMX system, connect the DMX IN cable to the input connector (male 5-pin XLR connector).Once you want to connect DMX Out at the same time, please use optional ROXX DMX I/O split cable (male/female 5-pin XLR connectors). For outdoor installations, use only IP65-rated XLR connectors.
  • Page 14 User Manual 4.3.2.2. Wireless Connection CRMX Disabled Operation Mode n.a. •DMX 19 CH Linked The indicator infront of "DMX" shows that DMX is active. Receive Reset Next Enabled ( 20 ) BLE (Bluetooth) Disabled CRMX Enabled • CRMX(RX) The indicator infront of "CRMX Operation Mode (RX)"...
  • Page 15 Enabled + Paired DMX). BLE (Bluetooth) Enabled CRMX CRMX(TX) Operation Mode No indicator infront of "BLE", 19 CH Linked fixture is not paired to ROXX Receive Reset App. Next Disconnect ( 20 ) BLE (Bluetooth) Enabled, not paired CRMX Enabled...

  • Page 16: Operation

    Once the fixture is switched On, the boot process starts and the following information will appear on the display: “Ready to ROXX”, the product name and the current software version. After this process, the fixture is ready for operation, and starts in the previously enabled mode.
  • Page 17 User Manual Display Off Pressing ESC + arrow down simultaneously the display backlight function will set to off and the display will turn off immediately. Once a control is pressed the display backlight will turn on. BLE enabled / disabled Pressing ESC + Arrow Up simultaneously the Bluetooth will enabled or disabled.

  • Page 18: Configuration

    User Manual 5.4 Configuration Home Screen After boot process the fixture is ready for operation and starts in the previously enabled mode. At home screen the following information will appear, depending on the current operating mode: DMX Adress Operating Mode (DMX Mode, Quick Light or Standalone Mode) Next available DMX address depending on the fixtures DMX footprint External Data protocol (CRMX, DMX, BLE).

  • Page 19: Stand Alone

    User Manual Level 1 Level 2 Menu DMX Mode 3CH CCT DMX Mode 8CH COLOR MACRO Stand Alone 6CH RGB Slave 9CH RGB Settings 10CH RGB System Info 19CH RGB (default) 21CH RGB 28CH PATTERN 80CH PIXEL 7CH DIRECT 11CH DIRECT 20CH DIRECT 5.4.3 Stand Alone* Press ENTER to access to main menu (level 1).
  • Page 20 User Manual To adjust brightness please select “Dim” as per the procedure previously described and confirm with ENTER. After use UP / DOWN arrows again to adjust the brightness value between 000-100 and confirm by ENTER or jump back by ESC. Once it´s confirmed or denied the display will automatically jump back to level 3.
  • Page 21 User Manual Editor* At Editor you have up to three customizable programs which can be defined and run from the menus. Each of the three values contains twenty four user-definable scenes with its own values for RGBL (RAW) or RGB (Calibrated) and shutter, playing continuously in a loop.
  • Page 22 User Manual Color Macro* 44 different color macros (34x matched LEE color filters, 4 LED colors and 6 different Whites) are available as presets. For each the brightness can be adjusted separately. Level 1 Level 2 Level 3 Level 4 Level 4 Menu Stand Alone Mode...
  • Page 23 User Manual Quick Color* The standalone mode “Quick Color” allows a direct adjustment of the single LED colors R, G, B, L Dimmer and Shutter. Level 1 Level 2 Level 3 Menu Stand Alone Mode Quick Color DMX Mode Stop Stand Alone Dimmer (C) <0-255>...
  • Page 24 User Manual Starting from home screen press ENTER to access to main menu (level 1). While using the UP / DOWN arrows select the menu item “Stand Alone” and confirm by pressing ENTER. After please select the item “Tunable White” by using the up/down arrows and press ENTER again. Using UP and DOWN controls to select your desired menu item, confirm by ENTER and adjust the desired value by up and down controls and confirm all entries with ENTER.
  • Page 25 User Manual Timer* Via the internal timer function, all Stand Alone modes except "Auto" and "Editor" can be conveniently faded in and out after the function is enabled in the previously activated standalone mode, without the need for an external controller. Also it remains active even the fixture is switched off and restarted.

  • Page 26: Slave Mode

    User Manual Level 1 Level 2 Level 3 Menu Stand Alone Mode Color Settings DMX Mode Stop Stand Alone Color Calibration Stand Alone Auto Slave Editor Settings Color Macro Quick Color System Info Tunable White User Color Timer Color Settings 5.4.4 Slave Mode* Slave Mode allows same model fixtures to be controlled by the “Master”...
  • Page 27 User Manual Main Menu Menu level 2 Menu level 3 Menu level 4 Description CRMX <on/off> On=CRMX enabled / Off= CRMX disabled Receive= CRMX module as Receiver Operating Mode <receive/transmit> Transmit= CRMX module as Transmitter Yes= pair with CRMX devices. CRMX must be activated on all devices and the pairing must be Transmit Link <no/yes>...
  • Page 28 User Manual Hold= last command retains Hold DMX Fail Blackout Blackout= Activates Blackout Emergency Light Emergency Light= Fixtures changes to 5600K Hold= last command retains Hold AC Fail Blackout Blackout= Activates Blackout Emergency Light Emergency Light= Fixtures changes to 5600K Linear= Light intensity increases linear Linear with DMX value...
  • Page 29 User Manual Main Menu Menu level 2 Menu level 3 Menu level 4 Menu Level 5 Description 3CH CCT / 8CH Color Macro / 6CH RGB / 9CH RGB / 10CH RGB /19CH RGB / 21 CH RGB / 28CH PATTERN / 80CH PIXEL / 7CH DMX Mode.

  • Page 30: System Info

    User Manual 5.4.6 System Info Level 1 Menu DMX Mode Stand Alone Slave Settings System Info Main Menu Menu level 2 Menu level 3 Menu level 4 Display installed firmware version Firmware Version vx.xx Serial Number 103xxxxxxxx Display unique RDM ID for identification RDM UID 0X6a6a0103xxxx Celsius...

  • Page 31: Accessories

    User Manual 6. ACCESSORIES 6.1 Filters (Light Shaping Diffusors) Available filters for ROXX FLEX series with order numbers: Filter 5° Art.: 12907800 Filter 10° Art.: 12907900 Filter 20° Art.: 12908000 Filter 5° x 20° Art.: 12908100 Filter 5° x 30°...

  • Page 32: More Accessories

    Art.: 12908801 Art.: 12908701 Art.: 12909701 B.FLEX Mini B.FLEX Art.: 12909231 EU Art.: 12909331 EU Art.: 12909232 INT Art.: 12909332 INT Single PSU B.FLEX Single PSU B.FLEX mini Safety Cable Tubes M4 Adapter Art.: 12909100 Art.: 12909000 Art.: 12908900 Art.: 12909800...

  • Page 33: Technical Data / Diagrams

    User Manual 7. TECHNICAL DATA / DIAGRAMS 7.1 Technical drawings and measurements - B.FLEX 120.00...
  • Page 34 User Manual 7. TECHNICAL DATA / DIAGRAMS 7.1 Technical drawings and measurements - B.FLEX-mini 120.00...

  • Page 35: Ip Rating

    Manual 7.2 IP Rating ROXX products conform to officially classified IP standard levels. B.FLEX/B.FLEX mini is rated to IP65 when using the covers for the housing parts. IP stands for Ingress Protection and IP65, according to classified standard, means shielded against dust and high-pressure jets of water from any side.

  • Page 36: Technical Data - B.flex

    User Manual 7.3 Technical Data - B.FLEX Photometrics LED expected lifetime 50.000 hours Lightsource 1x40W RGBL Total Internal Reflection lens (TIR) Type of optical system selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz LED PWM Frequency 2,7° (native) 4,8° (with 5° Filter) 10,1°...
  • Page 37 User Manual 7.3 Technical Data - B.FLEX Physical Head Straight Up Height (including optional 250mm (9,84 inches) Yoke) Net weight (without Yoke) 2,49 kg (5,49lbs) Net weight (including optional Yoke) 2,85 kg (6,28lbs) Electrical Data 100 – 240V 50/60Hz Operating Volatge...

  • Page 38: Technical Data - B.flex Mini

    Hanging or ceiling / pendant mount Rigging possibilities Safety features rear mount for safety wire Minimum distance from flammable materials 0,3 meters (11,8 inch) 7.4 Technical Data - B.FLEX mini Photometrics LED expected lifetime 50.000 hours Lightsource 1x15W RGBL Total Internal Reflection lens (TIR) Type of optical system selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz...
  • Page 39 User Manual 7.4 Technical Data - B.FLEX mini Dimensions & Weight IP class IP65 Body material Aluminum, Nylon Lens material Tempered glass front Net dimensions (w x h x d) 120 x 140 x 120mm Net dimensions inches 4,72 x 5,51 x 4,72 inches...
  • Page 40 User Manual 7.4 Technical Data - B.FLEX mini Included / Optional Included items Single DC Power Supply, Safety Eye Bolt YOKE, FILTER (5°, 10°, 20°, 5°x20°, 5°x30°, Batwing) TUBE (S, M, L, XL, XXL, HAT, GROUND PLATE , BASE EXTENSION, HALO, FULL ANTI-GLARE SHIELD, HALF...

  • Page 41: Dmx-Charts / Color Macro Charts / Cct Chart

    User Manual 7.5 DMX Chart 3CH CCT 28CH PATTERN 8CH COLOR MACRO 80CH PIXEL 6CH RGB 7CH DIRECT 9CH RGB 11CH DIRECT 10CH RGB 20CH DIRECT 19CH RGB (default) 23CH DIRECT 21CH RGB 29CH PATTERN 3 CH CCT MODE - Color Calibrated - (Halo not controlable) Function Value Setting...
  • Page 42 230 - 244 Strobe 10: burst (fast slow) 245 - 255 Shutter open ® Color Macro Center Please use color macros from ROXX color macro chart 000 - 005 No function Color Macro 006-105 0,1s - 10s (0,1s steps) Crossfade Center...
  • Page 43 User Manual ® Color Macro Halo Please use color macros from ROXX color macro chart 000 - 005 No function Color Macro Crossfade Halo 006-105 0,1s - 10s (0,1s steps) (Transition Time 106-214 11s - 119s (1s steps) between Color...
  • Page 44 User Manual 150 - 164 Strobe 6:random closing pulse (fast slow) 165 - 169 Shutter open 170 - 184 Strobe 7: burst pulse (fast slow) 185 - 189 Shutter open 190 - 204 Strobe 8: random burst pulse (fast slow) Shutter Center 205 - 209 Shutter open...
  • Page 45 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Center Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 46 (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Halo Please use color macros from ROXX® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105 0,1s - 10s (0,1s steps)
  • Page 47 User Manual 000 - 005 no function - Stop Program 006-011 Center - 7 Color Fade 012-017 Center - 7 Color Jump 018-023 Center - 15 Color Jump 024-029 Center - 15 Color Jump 030-035 Center - Police RB 036-041 Center - Police B 042-047 Center - Candle Light...
  • Page 48 User Manual 000 - 005 No function - Auto Porgram Speed Stop 006 - 126 Auto Program fast to slow - Forward (clockwise) Auto Program Speed 127 - 127 Stop 128 - 255 Auto Program slow to fast - Backward (counter-clockwise) 000-029 No function 030-034...
  • Page 49 2000K-6500K linear in 20-21K steps (please see detailed CTC chart) CTC Center 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Center ® Please use color macros from ROXX color macro chart (override RGB/CTC)
  • Page 50 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Halo Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 51 User Manual 000-029 No function 030-034 Battery Runtime Off (hold 3s) 035-039 Battery Runtime 8 hours (hold 3s) 040-044 Battery Runtime 12 hours (hold 3s) 045-049 Battery Runtime 16 hours (hold 3s) 050-054 Battery Runtime 20 hours (hold 3s) 055-059 Battery Runtime 24 hours (hold 3s) 060-064 No function...
  • Page 52 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Center Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 53 (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Halo ® Please use color macros from ROXX color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105 0,1s - 10s (0,1s steps)
  • Page 54 User Manual 068-079 Effect Pattern 6 080-091 Effect Pattern 7 092-103 Effect Pattern 8 104-115 Effect Pattern 9 116-127 Effect Pattern 10 128-139 Effect Pattern 11 140-151 Effect Pattern 12 Effect Pattern Halo (colors are still 152-163 Effect Pattern 13 selectable by channel 11-15) 164-175...
  • Page 55 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Backlight Halo Please use color macros from ROXX ® color macro chart (override RGB) 000 - 005 No function Color Macro 006-105...
  • Page 56 User Manual Dimmer Response LED (Hold 1,5s) 145-149 Dimmer Response Halogen (Hold 1,5s) 150-154 155-159 No function LED Frequency 800Hz (hold 3s) 160-164 LED Frequency 1200Hz (hold 3s) 165-169 LED Frequency 2000Hz (hold 3s) 170-174 LED Frequency 3600Hz (hold 3s) 175-179 Device Settings LED Frequency 12kHz (hold 3s)
  • Page 57 User Manual Green Center 000-255 0 - 100% Blue Center 000-255 0 - 100% Dimmer Halo 000-255 0 - 100% 000 - 019 No function 020 - 024 Shutter open 025 - 064 Strobe 1 (fast slow) 065 - 069 Shutter open 070 - 084 Strobe 2: opening pulse (fast...
  • Page 58 User Manual 065-069 Display Backlight On (hold 3s) 070-074 Display Backlight Off (hold 3s) 075-079 No function 080-084 DMX Fail - Blackout (hold 3s) DMX Fail - Hold (hold 3s) 085-089 090-094 DMX Fail - Emergency Light (hold 3s) 095-099 No function AC Fail - Hold (hold 3s) 100-104...
  • Page 59 User Manual Red (Halo) 000-255 0 - 100% Green (Halo) 000-255 0 - 100% Blue (Halo) 000-255 0 - 100% 11 CH DIRECT MODE (RAW) Function Value Setting Red (Center) 000-255 0 - 100% Red Fine (Center) 000-255 0 - 100% Green (Center) 000-255 0 - 100%...
  • Page 60 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Center Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 61 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Halo Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 62 User Manual Halo - Weldingt 162-167 Center & Halo - 7 Color Fade / Uniform 168-173 Center & Halo - 7 Color Fade / Offset 174-179 Center & Halo - 7 Color Fade / Rainbow 180-185 Center & Halo - 7 Color Jump / Uniform 186-191 Center &...
  • Page 63 User Manual 125-129 Exponential Dimmer Curve (hold 3s) 130-134 Logarithmic Dimmer Curve (hold 3s) 135-139 S-Curve Dimmer Curve (hold 3s) 140-144 No function Dimmer Response LED (Hold 1,5s) 145-149 Dimmer Response Halogen (Hold 1,5s) 150-154 155-159 No function LED Frequency 800Hz (hold 3s) 160-164 LED Frequency 1200Hz (hold 3s) 165-169...
  • Page 64 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Center Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 65 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Halo Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 66 User Manual 135-139 S-Curve Dimmer Curve (hold 3s) 140-144 No function Dimmer Response LED (Hold 1,5s) 145-149 Dimmer Response Halogen (Hold 1,5s) 150-154 155-159 No function LED Frequency 800Hz (hold 3s) 160-164 LED Frequency 1200Hz (hold 3s) 165-169 LED Frequency 2000Hz (hold 3s) 170-174 Device Settings LED Frequency 3600Hz (hold 3s)
  • Page 67 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Center Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 68 182-182 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Halo Please use color macros from ROXX ® color macro chart (override RGB/CTC) 000 - 005 No function Color Macro 006-105...
  • Page 69 5600K (affects RGB) 226-226 6500K 227-255 6621K-10.000K linear in 120-121K steps (please see detailed CTC chart) Color Macro Backlight Halo Please use color macros from ROXX ® color macro chart (override RGB) 000 - 005 No function Color Macro 006-105...
  • Page 70 User Manual 000-029 No function 030-034 Battery Runtime Off (hold 3s) 035-039 Battery Runtime 8 hours (hold 3s) 040-044 Battery Runtime 12 hours (hold 3s) 045-049 Battery Runtime 16 hours (hold 3s) 050-054 Battery Runtime 20 hours (hold 3s) 055-059 Battery Runtime 24 hours (hold 3s) 060-064 No function...
  • Page 71 User Manual 7.5 Color Macro Chart for DMX Gels - Color Macros for DMX Gels - Color Macros for DMX DMX value Gel Name Color Number DMX value Gel Name Color Number 000-005 no function 102-104 Special Med Lavender LEE 343 006-008 100% Red LED 105-107...
  • Page 72 User Manual 7.5 Color Macro Chart for Stand Alone Gels - Color Macros for Standalone Mode Gels - Color Macros for Standalone Mode Position Gel Name Color Number Position Gel Name Color Number 100% Red LED Lavender LEE 058 Fire LEE 019 Magenta LEE 113...
  • Page 73 User Manual 7.5 CTC channel DMX / Color temperature 10.000 9.500 9.000 8.500 8.000 7.500 7.000 6.500 6.000 5.500 5.000 4.500 4.000 3.500 3.000 2.500 DMX (step) 2.000...
  • Page 74 User Manual 7.5 CTC-Chart Color Color Color Color Color Color Temp Temp Temp Temp Temp Temp (Step) (Step) (Step) (Step) (Step) (Step) (°K) (°K) (°K) (°K) (°K) (°K) 5600 4525 2774 3649 5400 6276 5600 4545 2794 3670 5421 6296 5600 4566 2814...

  • Page 75: Rdm Templates

    0128xxxxxxxxx / 0129xxxxxxxxx * Note: During RDM identifying process B.FLEX/B.FLEX mini flashes white to blue color alternately. RDM functions B.FLEX For easy identifying ROXX B.FLEX during RDM process the unit will jump from white color to blue color every second. Function Action...
  • Page 76 Sensor 1 LED Temperature read n.a. RDM functions - B.FLEX mini For easy identifying ROXX B.FLEX mini during RDM process the unit will jump from white color to blue color every second. Function Action Values 0x00F0 DMX Start Adress...

  • Page 77: Firmware Update

    / xxx°F Software Version SW-Version Errors 7.7 Firmware Update To update B.FLEX / B.FLEX mini to newest firmware, please use ROXX update box and make sure the fixtures are connected to DC power. Please download update instructions here: https://roxxlight.com/support/ 8. TROUBLESHOOTING...

  • Page 78: Manufacturer´s Declaration

    ROXX GmbH, Hansestr. 91, 51149 Köln Email: info@roxxlight.com or the ROXX authorized reseller in your country, from where you purchased your product. Correct Disposal of this product This is for the European Union and European countries with electrical waste collection systems. When this label is shown on the product or brochure it means that the item cannot be disposed with household waste.
  • Page 79 User Manual CE Compliance The equipment marketed by ROXX GmbH complies (where applicable) with the essential requirements and other specifications of the following Directives: • 2014/53/EU (RED) • 2014/30/EU (EMC) • 2014/35/EU (LVD) • 2011/65/EU (RoHS) The complete EU- and UK-Declaration of Conformity can be found at www.roxxlight.com/support, or you can also request it at info@roxxlight.com...
