info@bathcogroup.com
Oropesa
Ref. 4565
Installation INSTRUCTIONS
Before proceeding with installation, please read these instructions carefully to
familiarise yourself with the required tools, materials and installation sequences.
Please leave these instructions for the consumer after installation.
Prior to installation, inspect the toilet to ensure that no damage has occurred in
transit. If damage has occurred, or a visible defect exists, do not proceed with
installation, and advise your supplier immediately.
CAUTION: risk of personal injury or product damage. Handle with care. Porcelain
can be broken or chipped if the product is handled carelessly.
- Observe all local plumbing and building codes.
- Carefully inspect the new toilet for damage.
- If the existing toilet does not have a supply shut-off valve below the cistern,
install one before installing the new toilet.
Tools and material required
Tape measure
Pencil
Wall - hung bidet
Level
Allen key
Safety glasses
Caulking gun
Advertisement
Table of Contents
Related Manuals for BATHCO Oropesa 4565
Summary of Contents for BATHCO Oropesa 4565
- Page 1 Wall - hung bidet info@bathcogroup.com Oropesa Ref. 4565 INSTALLATION INSTRUCTIONS Before proceeding with installation, please read these instructions carefully to familiarise yourself with the required tools, materials and installation sequences. Please leave these instructions for the consumer after installation. Prior to installation, inspect the toilet to ensure that no damage has occurred in transit.
- Page 2 Installation Installing D into the screw rod and Parts identification keeping screw notch vertically upward. 50 mm Insert B into A. Insert part A into B to Check the shut-off valve position. rotate. Installation E into the screw hole of Fix to wall.
