MCA furniture Nakuru 40253 SX3 Installation Manual

Item No.: 40253 SX3 / 40253 WW3
Attention: The drawings below are for guidance only and they may differ slightly from the product and fittings received. Please contact customer
service department if there are any missing tools or installation problems.
A x4 B x3 C x2 D
Wooden 4*4 Inner Hexagon Allen
Key/ 5*5 Allen Key
Plug Dowel Pins
(with cross head)
Component List
No. Part Qty No. Part
1 2
1
Front Tabletop Back Tabletop
3 4
2
Table Support Tube
5 2 6
Feet Beam Components
7 8
1
Baffle Power Plug
9 10
4
Cable Tie Switch Cord
11 1 12
Table Connect
Handset Sheet Metal
Installation guide
Item No. ET116G-2P4824
Column Stage
Max. Load Capacity
Max. Speed
Height Range 730-1230mm(with tabletop)
Tabletop Dimension
1200x600x16mm Particle Board
Frequency 10%（Work continuously for 2 minutes, pause for 18 minutes）
Temperature
x4 E x4 F x8 G
M6x12 M6x12 M6x16 ST4.2x13
Installation Diagram
Qty
2
1
1
7
2
6
Column
3
1
1
4
1
8
2
5
STEP1
B x3
Wooden
Dowel Pins
C x1
5x5(with
cross head)
G x4
2
ST4.2x13
2
50KG
25mm/s
0-40℃
12
x7 H x12
ST4.2x55
STEP2
A x4
Plug
12
C x1
5x5(with
cross head)
E
x4
11
M6x12
H x12
10
ST4.2x55
9
1. Set 3 Wooden Dowel Pins

Assemble Tabletop

Note: connect two tabletops closely.
2. Align the connecting sheet metal (12) of the two table plates with the holes as shown in the figure, press the
two table plates, and then use a 5x5 allen key (C) to tighten the screws (G).
Install Table Support Tube and
Beam Components
1. Tighten 4 screws(E)
6
3
C
H
1
B
G
A
E
3
C
2. Cover the plugs 4
screws on left and right
3. As shown in the figure, align the holes on the table
and tighten the 12 screws(H) with a cross allen key C.
Note: The motor faces the adapter side to prevent the
frame from being installed backwards and forwards
