Proxy-KeyAV, Proxy-KeyAH, Proxy-KeyMV, Proxy-KeyMH
1

DESCRIPTION

1.1 Purpose

1.1.1 Standalone access controllers with built-in proximity reader and keypad Proxy-KeyAV, Proxy-
KeyAH, Proxy-KeyMV, Proxy-KeyMH (hereinafter referred to as the controllers) are designed for
entering PINs and reading unique codes of proximity cards.
1.1.2 The controllers are non-recoverable, periodically serviced equipment.
1.1.3 The controllers are not designed to be used in corrosive and dusty environments as well as in fire and
explosion hazardous premises.

1.2 Specifications

No.
1.2.1
Power voltage
1.2.2
Average Consumed Current
1.2.3
Power Input
1.2.4
Pre-operation Time
1.2.5
Credential Capacity
1.2.6
Password Capacity
1.2.7
Relays
1.2.8
Relay Switched Voltage
1.2.9
Relay Switched Current
1.2.10 Ingress Protection Rating as per GOST 14254-2015
1.2.11 Resistance to mechanical stress as per OST 25 1099-83
Vibration loads:
1.2.12
- Frequency
- Max acceleration
1.2.13 Climatic Category as per OST 25 1099-83
1.2.14 Operating Temperature
1.2.15 Relative Humidity
1.2.16 Weight
Overall Dimensions:
1.2.17
Proxy-KeyAV, Proxy-KeyMV
Proxy-KeyAH, Proxy-KeyMH
1.2.18 Non-stop Operation
1.2.19 MTBF in quiescent mode
1.2.20 Non-failure Operation Probability
1.2.21 Average Lifetime
STANDALONE ACCESS CONTROLLERS
WITH BUILT-IN PROXIMITY READER AND KEYPAD
Characteristic
Instruction Manual
Table 1.2.1
Value
- 10 through 15 V dc
- 200 mA
- 1
- 1 s
- 1000 ones
- 8 ones
- 2
- 24 V dc
- 2 A
- IP65
- Category 3
- 1-35 Hz; (for Category 3)
- 0.5g (for Category 3)
- О3
- Minus 35 through +50°С
- 0 to 95%
- 0.5 kg
- 50.2 × 160.2 × 21 mm
- 86.2 × 120.2 × 21 mm
- 24/7
- 80000 hours
- 0.98758
- 8 years
1
