Summary of Contents for ALDERWOOD Cyclops
- Page 1 ALDERWOOD Hand Crafted Sound...
-
Page 2: Table Of Contents
MANUAL CONTENTS - CYCLOPS Thank you for supporting Australian jobs, Alderwood products are proudly made in southwest Victoria by highly trained and skilled artisans. To ensure that this product provides you with many years of musical enjoyment please read and understand this manual before using our installing this product. -
Page 3: Cylops Specs
CYLOPS SPECS Dimensions 34cm x 34cm x 12.5cm Weight 10kg Input Connection 1 meter marine grade cable, IP67 gland Frequency Range 25-250hz Nominal Impendanc e 8 Ohms Sensitivity 1W/1 M 85db Cabinet Material F17 Birch Ply Beamwidth Omnidirectional Long stroke 10 inch with 76MM Driver copper voice coil Maximum cone excursion... -
Page 4: Run In Period
The Cyclops is rated IP66, which offers complete dust protection and limited water resistance including salt water. It is always recommend to install the cyclops in a position that allows water to drain out of the grill. Face the electrical cables pointing down. -
Page 5: Wiring
WIRING The Cyclops is supplied with a short length of cable designed to be soldered onto for long lasting performance in harsh outdoor environ- ments. It is recommended to properly cover the soldered joint with glued heatshrink to keep moisture out of the joint. -
Page 6: Trouble Shooting
ATTACHING THE FEET The 4 feet provided with the cyclops can be attached to the front or the rear of the subwoofer depending on how you are using it. To attach the feet undo the 4 M5 countersunk screws and bolt... -
Page 7: Warranty
This product is covered by a 5 year warranty against defects and workmanship including commercial usage. Alderwood reserves the right to repair or replace defective products in the event of a warranty claim, all warranty claims will need to be returned to the place of purchase with a proof of purchase receipt. - Page 8 56 Curdie Street Cobden, Victoria, Australia 3266 sales@alderwoodspeakers.com.au www.alderwoodspeakers.com.au...
