MOBISERV – FP7 248434

An Integrated Intelligent Home Environment for the

Provision of Health, Nutrition and Mobility Services to the

Elderly

Final Deliverable

D5.4: Multi-sensor system integrated into

wearable fabrics

Date of delivery: Month 38

Contributing Partners: CSEM, SMARTEX

Date: March 2013

Version: v1.2

Table of Contents

Need help?

Do you have a question about the MOBISERV FP7 248434 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cordis MOBISERV FP7 248434

Page 1 MOBISERV – FP7 248434 An Integrated Intelligent Home Environment for the Provision of Health, Nutrition and Mobility Services to the Elderly Final Deliverable D5.4: Multi-sensor system integrated into wearable fabrics Date of delivery: Month 38 Contributing Partners: CSEM, SMARTEX Date: March 2013 Version: v1.2...
Page 2 D5.4: Multi-sensor system integrated into wearable fabrics 2/42 Document Control Title: D5.4: Multi-sensor system integrated into wearable fabrics Project: MOBISERV (FP7 248434) Nature: Dissemination Level: Restricted Prototype Authors: CSEM - SMARTEX Origin: CSEM Doc ID: MOBISERV_WEARABLE_PLATFORM_USER_MANUAL Amendment History Version Date Author Description/Comments V1.0...
Page 3: Table Of Contents
D5.4: Multi-sensor system integrated into wearable fabrics 3/42 Table of contents GLOSSARY ..........................7 INTRODUCTION AND FEATURES ................8 ....................8 XECUTIVE SUMMARY ....................8 ENERAL OVERVIEW .................. 9 TRUCTURE OF THE DOCUMENT GARMENTS ........................10 ................10 ESIGN OF THE NEW PROTOTYPES ......................
Page 4 D5.4: Multi-sensor system integrated into wearable fabrics 4/42 WHSU MULTI-PARAMETER ACQUISITION SYSTEM ..........31 ......................31 NTRODUCTION ................32 OBISER OGGER ERVER ....................33 XERCISES ANAGER ELECTROMAGNETIC COMPATIBILITY ..............35 ........................35 ARNING ’ – EMC ....35 UIDANCE AND MANUFACTURER S DECLARATION EMISSIONS ’...
Page 5 D5.4: Multi-sensor system integrated into wearable fabrics 5/42 Table of Figures Figure 1: Direct connection with secondary user ..............8 Figure 2: Direct connection with secondary user ..............9 Figure 3: The sketch of the female (a) and male (b) day shirt ..........11 Figure 4: The visual label with instructions for the correct use of shirts .........
Page 6 D5.4: Multi-sensor system integrated into wearable fabrics 6/42 List of Tables Table 1 System specifications ....................17 Table 2 Module Specifications ....................18 Table 3 ANT Channel Description ..................18 Table 4 Global Data Message Format ..................19 Table 5 ANT Message Payload ...................
Page 7: Glossary
D5.4: Multi-sensor system integrated into wearable fabrics 7/42 Glossary Term Explanation MOBISERV An Integrated Intelligent Home Environment for the Provision of Health, Nutrition and Mobility Services to the Elderly 2 dimensional 3 dimensional Ambient Assisted Living Activities of Daily Living Advanced Encryption Standard Bayesian networks Breathing rate...
Page 8: Introduction And Features
D5.4: Multi-sensor system integrated into wearable fabrics 8/42 1 Introduction and features 1.1 Executive summary This document accompanies the actual / “physical” prototypes of the MOBISERV Wearable Health Supporting Unit (WHSU) (shirt and band for daily use, pyjamas for night use, together with a data logger and an application on PC).
Page 9: Structure Of The Document
D5.4: Multi-sensor system integrated into wearable fabrics 9/42 Figure 2: Direct connection with secondary user 1.3 Structure of the document This document is organized as follows. The first chapter provides a general overview of the system and possible configurations. The second chapter is dedicated to the description of the daily and nightly application and the garment that is used in each case.
Page 10: Garments
D5.4: Multi-sensor system integrated into wearable fabrics 10/42 2 Garments Within the scope of MOBISERV two different types of garments have been created for vital signs monitoring: the first one refers to sensorized shirt and band for day use, and the second one to nightgown for night use.
Page 11: Figure 3: The Sketch Of The Female (A) And Male (B) Day Shirt
D5.4: Multi-sensor system integrated into wearable fabrics 11/42 Figure 3: The sketch of the female (a) and male (b) day shirt The improvements to the final prototypes of shirts can be resumed in the following list of bullets: • Pockets are now closed by Velcro®. •...
Page 12: Figure 4: The Visual Label With Instructions For The Correct Use Of Shirts
D5.4: Multi-sensor system integrated into wearable fabrics 12/42 Figure 4: The visual label with instructions for the correct use of shirts A very simple label assists the user by means of four basic steps, during the use of the WSHU. The final prototypes of shirts for female and male are illustrated in Figure 5 and Figure 6.
Page 13: Figure 6: The Four Textile Electrodes In The Inner Side Of The Female Shirt
D5.4: Multi-sensor system integrated into wearable fabrics 13/42 Figure 6: The four textile electrodes in the inner side of the female shirt The day garments collection also includes a band that can be used during a short time window, for instance just to monitor an exercises session during the day. The band could help to overcome possible lacks in acceptability by the users that do not want to wear the sensorized shirt for the whole day.
Page 14: Night Garments
D5.4: Multi-sensor system integrated into wearable fabrics 14/42 2.3 Night Garments As for the day garments also night monitoring system has been completely redesigned to include all recommendations made by the users and by the experts within the evaluation trials. In particular, the idea to have a pyjama has been abandoned and replaced by a nightgown that seems to be easier worn and more accepted by elderly in general.
Page 15: Figure 9 The Label Inserted In The Nightgown
D5.4: Multi-sensor system integrated into wearable fabrics 15/42 The label for nightgown also contains the instructions to correctly use the ANT data logger for temperature monitoring, as shown in figure 7. Figure 9 The label inserted in the nightgown Two textile electrodes are available as conductive cuffs (see Figure 10). An elastic material together with a cord lock system has been inserted in order to let the user adjust and optimize the skin/electrode contact without losing comfort.
Page 16: Figure 11 Female Version Of The Nightgown
D5.4: Multi-sensor system integrated into wearable fabrics 16/42 A specific ANT module has been designed to interface properly the sensors as explained in chapter 3. Nightgown presents: a) Two textile electrodes placed on the cuffs that can be used to detect ECG and are adjustable by means of elastic ribs.
Page 17: Mobiserv Ant Module For Temperature Monitoring
D5.4: Multi-sensor system integrated into wearable fabrics 17/42 3 MOBISERV ANT Module for temperature monitoring A wireless module has been specifically designed to measure the resistance of the thermistors that are integrated in the nightgown to monitor the skin temperature of the subject. No changes have been made on this side with respect to the previous prototypes.
Page 18: Measurement Channels Specifications
D5.4: Multi-sensor system integrated into wearable fabrics 18/42 Characteristics Storage -20 to 50 °C Humidity Operational up to 95% non-condensing Communication interface Wireless wireless module ANT11TS33M5IB Certifications FCC Test ready (CFR47), RHOS compliant Device Dimensions 41 x 41 x 23mm Weight 27 gr.
Page 19: Data Format
D5.4: Multi-sensor system integrated into wearable fabrics 19/42 Channel Configuration (pairing bit disabled) No shared address, Global Transmission Type Data Identification Byte present Network configurations Bidirectional Master Transmit Channel type 0x10 Channel Channel Period 16384 2 Hz Message Rate Network number Default public network Message Rate 2 Hz...
Page 20 D5.4: Multi-sensor system integrated into wearable fabrics 20/42 ANT Message Parameters Type Range Description Payload Byte 8 most significant bits of Global Data Byte 5 Min (8-bit) UCHAR 0..255 the minimum recorded analogue level The measured A/D data Global Data Byte 6- Measured A/D Data USHORT 0..65536...
Page 21: Data Logger
D5.4: Multi-sensor system integrated into wearable fabrics 21/42 4 Data logger 4.1 Hardware description The first version of the MOBISERV data logger has been updated with the integration of an ANT module used for the wireless body array network. In the first version, the respiration sensor was a strain gauge, in this second version, there is the possibility to use either a strain gauge or the impedance plethysmography measurement.
Page 22: Connectors
D5.4: Multi-sensor system integrated into wearable fabrics 22/42 Data logger can only be filled with data from the MOBISERV Data logger. Once formatted by the device, it should not be used to store other files on it. If a new card is inserted, the device will refuse to use it until it is properly formatted.
Page 23: Data Logger Specifications
D5.4: Multi-sensor system integrated into wearable fabrics 23/42 Characteristics Weight About 60 gr 4.4.2 Data logger specifications The following table shows the characteristics of the data logger related to the vital signs monitoring and the user communication interface. Table 7: Data logger characteristics Characteristics Type of measurement Bio-potential measurements on thorax...
Page 24: Extracted Parameters Specifications
D5.4: Multi-sensor system integrated into wearable fabrics 24/42 Characteristics Communication interfaces Bluetooth 2.0, class 1/2/3 Wireless SPP (Serial Port Profile) Wired USB 2.0 FS (Full Speed) 4.4.3 Extracted parameters specifications The following table gives the characteristics of the extracted parameters related to the vital signs monitoring and the user communication interface.
Page 25: Mode Control
D5.4: Multi-sensor system integrated into wearable fabrics 25/42 Operating Status indicator Action to enter that mode Action to leave that mode mode Streaming Blue flash Connect through Controlled by the Bluetooth Bluetooth connection Recording Orange flash Press the mode button Press the mode button until the status light is until the status light is...
Page 26: Monitoring Signs And Data Processing
D5.4: Multi-sensor system integrated into wearable fabrics 26/42 LED status Mode Description ECG quality indication, RECORDING & STREAMING Memory writing, Streaming with viewer STREAMING Streaming with viewer CHARGING Connected through USB Connected through USB but the CHARGING / CLOCK not set device clock is not set BATTERY FULLY CHARGED Connected through USB...
Page 27: Table 14: Quality Index
D5.4: Multi-sensor system integrated into wearable fabrics 27/42 The monitoring of the ECG and the respiration is sensitive to the movement artefact. A quality index can be extracted from the processing algorithm to indicate a degree of confidence of the result. Table 14: Quality index Quality Description...
Page 28: Whsu Software Package
D5.4: Multi-sensor system integrated into wearable fabrics 28/42 5 WHSU Software package 5.1 Building blocks Figure 14 gives an overview of the WHSU stand-alone collaborating components. This is the first step before integrating the WHSU with the rest of the MOBISERV components to support “F08: Encouragement for exercising”...
Page 29: Device
D5.4: Multi-sensor system integrated into wearable fabrics 29/42 5.3 Device The device is the data logger embedded in the garment. This device has the ability to perform the operations listed hereunder. • Bluetooth operations − Connect. − Disconnect. − Start the streaming of the signals. −...
Page 30: Figure 15: Collaborating Components Of Exercises When Integrated Into Kompaï Robot
D5.4: Multi-sensor system integrated into wearable fabrics 30/42 the translation of the operations coming from the upper layer to the stack which is written in Java. Figure 15: Collaborating components of Exercises when integrated into Kompaï robot MOBISERV FP7 248434...
Page 31: Whsu Multi-Parameter Acquisition System
D5.4: Multi-sensor system integrated into wearable fabrics 31/42 6 WHSU multi-parameter acquisition system 6.1 Introduction This section details step by step the installation of the whole software package developed for the Mobiserv project. The second part concerns the use of the Graphical User Interface, that means: •...
Page 32: Mobiser Data Logger Server
D5.4: Multi-sensor system integrated into wearable fabrics 32/42 6.2 Mobiserv Data Logger Server USB driver used with the data logger has to be installed before doing anything else. The downloader tool can be downloaded from the following links: http://csnej106.csem.ch/sec251/sewOS/#host_software − −...
Page 33: Exercises Manager
D5.4: Multi-sensor system integrated into wearable fabrics 33/42 Table 16: Services offered by the Server to control the data logger Operation Description connect Connect to the data logger via the Bluetooth. This method throws an exception if the device is out of range or already connected disconnect Disconnect from the data logger and release the Bluetooth connection...
Page 34 D5.4: Multi-sensor system integrated into wearable fabrics 34/42 Handler Description actionAckHandler The acknowledgement of the action inform about whether the user is accepting the action or not. This method insert the action in the table "report" of the data base getReportHandler Gets the report of the actions in a day.
Page 35: Electromagnetic Compatibility
D5.4: Multi-sensor system integrated into wearable fabrics 35/42 7 Electromagnetic compatibility 7.1 Warning This data logger needs special precaution regarding EMC and needs to be installed and put into service according to the EMC information provided in this chapter. The radiated output power of this device is well below the FCC radio frequency exposure limits.
Page 36: Table 19: - Electromagnetic Immunity
D5.4: Multi-sensor system integrated into wearable fabrics 36/42 Table 19: – Electromagnetic immunity – IEC 60601 Compliance Electromagnetic environment IMMUNITY test test level level – guidance Electrostatic ± 6 kV contact ± 6 kV contact Floors should be wood, concrete discharge (ESD) ±...
Page 37: Recommended Separation Distances
D5.4: Multi-sensor system integrated into wearable fabrics 37/42 IEC 60601 Compliance Electromagnetic environment IMMUNITY test test level level – guidance Radiated 3 V/m 3 V/m From 80MHz and 800MHz IEC 61000-4-3 80 MHz to 2.5 GHz From 800MHz and 2.7MHz where P is the maximum output power rating of the transmitter in watts (W) according to the...
Page 38: Compliant Cables And Accessories
D5.4: Multi-sensor system integrated into wearable fabrics 38/42 Table 20: Recommended separation distances Rated maximum output Distance separation according to frequency of transmitter power of transmitter 80 MHz to 800 MHz 800 MHz to 2,5 GHz 0.01 0.12 0.23 0.10 0.38 0.73 1.00...
Page 39: Getting Started
D5.4: Multi-sensor system integrated into wearable fabrics 39/42 8 Getting started For a correct use of the smart garments, the user should follow the instructions listed below: 1. Moisten thoroughly the electrodes with tap water. Figure 19: Procedure to wet the electrodes 2.
Page 40: Figure 22: Placing The Electronic Inside The Band And T-Shirt
D5.4: Multi-sensor system integrated into wearable fabrics 40/42 4. Place the MOBISERV data logger inside the pocket on your: Band T-shirt Pyjama Figure 22: Placing the electronic inside the band and T-shirt 5. For the MOBISERV pyjama only: Turn on the MOBISERV ANT module by pressing the On/Off switch.
Page 41: Maintenance And Care
D5.4: Multi-sensor system integrated into wearable fabrics 41/42 9 Maintenance and care 9.1 General guidance for the garment The sensorized garments are realised using natural and synthetic yarns and must be treated as underwear. Garments have been tested for their endurance regarding number of washings and time of use.
Page 42: Disposal Of Device
D5.4: Multi-sensor system integrated into wearable fabrics 42/42 9.4 Disposal of device Please dispose of the device in an appropriate way, treating it as electronic waste. Do not throw it in the garbage. MOBISERV FP7 248434...
