Handy Home Products Monterey Instructions Manual

1000 Ternes Drive
Monroe, MI 48162
Toll Free 1-800-437-0784
- BEFORE YOU BEGIN -
Always wear OSHA-APPROVED safety
glasses throughout assembly process
■ ■ ■ ■ ■ First...
Read these instructions thoroughly before you begin assembly.
Assembly is easiest if you follow the steps in the order shown.
In a drawing, a dotted line represents a part hidden from view (like
a part under a panel).
Lumber is graded from only one side. Check the part for the most
attractive face and make sure to face it to the outside.
■ ■ ■ ■ ■ Check all parts
Compare parts you have to the list on page 2. If a part is missing,
circle the part in question in the parts list and call us toll-free at
1-800-437-0784.
■ ■ ■ ■ ■ Assistance required
We recommend that you assemble this Gazebo on level ground in
the location it will be used. Assistance is necessary to handle, fit,
and secure some components. Two people are needed for some
steps.
■ ■ ■ ■ ■ Check local zoning
Before starting construction, check with your local building code
official for any required permits, variances, etc.
Monterey 10'x14' - 10 sided Gazebo shown with optional Floor Kit (Not Included)
Monterey 12'x16' - 12 sided Gazebo (not shown)
Monterey 14'x18' - 14 sided Gazebo (not shown)
Monterey
10',12' and 14'
Oval Gazebo Instructions
■ ■ ■ ■ ■ Check Floor Kit Size
Before starting construction on your floor, make sure that you
check in the instruction manual to make sure that you are
building the correct size floor kit for your Gazebo. See page 3
for more information.
- TREATING YOUR GAZEBO -
■ ■ ■ ■ ■ Staining...
This Gazebo is constructed of a long-lasting western cedar.
Untreated cedar exposed to sunlight will eventually weather to a
silver-grey color. To validate your warranty and to help keep the
original red color, read your warranty page on maintaining your
Gazebo. Apply a minimum of two coats of oil based penetrating
stain WITHIN 30 DAYS (required by warranty). Some sanding to
remove rough edges and natural wood stains may be required
prior to staining. Your Gazebo roof is not waterproof unless it is
shingled. Caulking the roof seams before shingling will improve the
water resistance of your Gazebo.
STAIN REQUIREMENTS FOR GAZEBOS
SIZE # OF GALLONS
10'
12'
14'
■ ■ ■ ■ ■ Tools required
❑ Hammer
❑ #2 Phillips Screwdriver
❑ 6' Step Ladder
❑ Tape Measure
❑ Pencil
■ ■ ■ ■ ■ Optional tools
❑ Electric Drill w/ #2 Phillips Tip
❑ Nail Pouch
❑ 1/8" and 3/16"Drill bit-for predrilled holes
❑ Wood Glue
Revision: 02-12-07
Run:
Made in the U.S.A.
Add for Options
FLOOR SCREEN KIT
2 1
3 1
4 1.5
#16691
Visit us on the Web at:
www.HandyHome.com
.5
.5
1
