Summary of Contents for Kendall Howard ESDC-7836-1000
- Page 1 Save This Manual for Future Reference ® The Answer is Yes! What’s the Question?™ ESD CABINET Owner’s Manual Part Number ESDC-7836-1000 & ESDC-7836-2000 For Your Safety Read and understand the entire manual before use Page | 1...
-
Page 2: Table Of Contents
The information contained in this document is subject to change without notice or obligation. Kendall Howard LLC assumes no responsibility for the accuracy, completeness or reliability of the information contained in this document. -
Page 3: Dimensional Drawing
Save This Manual for Future Reference Dimensional Drawing Specifications Dimensions Height 78” x Width 36” x Depth 18” Weight (ESDC-7836-1000) 270 lbs (122 kg) Weight (ESDC-7836-2000) 341 Lbs (155 kg) Color Gloss Black Powder Coat Individual Replacement Components Description Part Number... -
Page 4: Component Identification
Save This Manual for Future Reference Component Identification What’s included (ESDC-7836-1000)? ESD Cabinet Part Number ESDC-7836-1000 What’s included (ESDC-7836-2000)? Drawer Assembly (2) ESD Shelf (2) Part Number ESDC-7836-1200 Part Number ESDC-7836-1204 23” x 32” Pegboard (1) Part Number ESDC-7836-1201 Page | 4... -
Page 5: Installation And Setup
Save This Manual for Future Reference Installation and Setup Step 1: Cut and remove the two plastic banding and any shrink wrap material. Remove the cardboard packaging. Remove accessories boxes from cabinet. Lift the Cabinet out of the packaging. Step 2: Place the Cabinet on the preinstalled leg levelers. -
Page 6: Cabinet Use
Save This Manual for Future Reference Cabinet Use ESD Control The ESD 2-layer vinyl mats are required for proper ESD protection when using this ESD Cabinet. This unit provides a RTT value of < 1 X 10⁹ ohms for each shelf. This unit provides a RTG value of 1 X 10⁵... -
Page 7: Care And Cleaning
Save This Manual for Future Reference Care and Cleaning Painted Surfaces All painted surfaces can be cleaned with a non-abrasive, non-ammonia or non-bleached based cleaner. Do not use soap or detergents on exposed metal surfaces of the sliding drawer, fixed shelf, or pegboard. -
Page 8: Troubleshooting
Save This Manual for Future Reference Troubleshooting ESD non-compliant on Shelves, Drawers and Mats • Verify that the flooring has a RTT value of 10⁵<10⁹. If not use the provided equipment ground wire and connect from one of the grounding boots to define a ground. •... -
Page 9: Warranty
MISCELLANEOUS: NO SALESPERSON, EMPLOYEE OR AGENT OF KENDALL HOWARD IS AUTHORIZED TO ADD TO OR VARY THE TERMS OF THIS WARRANTY. Warranty terms may be modified, if at all, only in writing signed by a Kendall Howard officer. This Warranty is effective as of the da te of Kendall Howard receipt of full payment and supersedes all previous warranties Kendall Howard reserves the right to supplement or change the terms of this Warranty in any subsequent warranty offering to User or others.
