Summary of Contents for SimpLinx SMX-RNS02
- Page 1 SMX-RNS02 Remote Access Module User's Guide 07/2020 man-en-smx-rns02.docx Version 1.3...
-
Page 2: Legal Notices
We have reviewed the contents of this publication to ensure consistency with the hardware and software described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. The information in this publication is reviewed regularly and any necessary corrections are included in subsequent editions. © 2020 SIMPLINX - 1 -... -
Page 3: Change Log
Change Log Version Date Description V1.0 07/2020 Draft V1.1 07/2020 Typos V1.2 07/2020 Typos V1.3 01/2021 New Features © 2020 SIMPLINX - 2 -... -
Page 4: Preface
Preface Purpose of the Document This document contains information about the following topics; SMX-RNS02 Product Information SMX-RNS02 Setup Use of SMX-RNS02 SMX-N1559 (Optional) SMX-RS01 (Optional) Required Level of Knowledge In order to fully understand and apply this document, it is necessary to have knowledge of IT, Automation and Electricity. -
Page 5: Table Of Contents
5.2. Use of Ethernet Ports as a Switch ................. - 13 - 5.3. USB Devices ........................- 15 - Registering SMX-RNS02 ......................- 16 - Preparing SMX-RNS02 ....................... - 17 - 7.1. Internet Connection Options ..................- 17 - 7.2. -
Page 6: Product Description And Certificates
1. Product Description and Certificates The SMX-RNS02 module is an Industrial Remote Connection device that provides the infrastructure needed for Industry 4.0, allowing you to connect to your remote field devices under high security measures and collect data from your devices. -
Page 7: Properties
Access to the module from the office network where the SMX-RNS02 module is located is blocked by the Firewall. Access of devices connected to the SMX-RNS02 module to the office network is blocked by the Firewall. © 2020 SIMPLINX... -
Page 8: Approvals / Ce
1.3. Approvals / CE The SMX-RNS02 module has received approval from the CE standards tests listed below. Electromagnetic Compatibility EN 55032:2015 Emissions (Diffusion) Tests EN 55024:2010/A1:2016 Immunity Tests EN 61000-4-2: 2009 EN 61000-4-3: 2006/A2:2010 ... -
Page 9: Physical Properties And Drawings
1xRj54 WAN 100 Mb/s 2xRj45 LAN 100 Mb/s DIN Rail Mounted Temperature C to 70 Work C to 85 Storage Dimensions (mm) Width : 42 Height : 101 Depth : 114 Weight (Kg) 0.202 © 2020 SIMPLINX - 8 -... -
Page 10: Drawings
2.1. Drawings © 2020 SIMPLINX - 9 -... -
Page 11: Setup
3. Setup The SMX-RNS02 module can be mounted to DIN rail. It is recommended to be mounted vertically to increase the performance of the device and to provide space advantage. 3.1. Mounting Bring the top of the device to the top edge of the standard profile rail and place the device on the rail track. -
Page 12: Electrical Connection
4. Electrical Connection The SMX-RNS02 module has 1 terminal group. The terminal group is called X1. The X1 terminal group has 3 terminals. These are as follows respectively; + - GND After you have completed the physical installation of your device, you can run your device by connecting the device (+), (-), and GND terminals to the appropriate terminals at the power supply output. -
Page 13: Schema
4.1. Schema © 2020 SIMPLINX - 12 -... -
Page 14: Device Connections
5. Device Connections 5.1. Ethernet Devices To connect your Ethernet devices to the SMX-RNS02 module, you must set up an IP in the IP range that you have given to the SMX-RNS02 module. Example If your SMX-RNS02 module is in the following settings ... - Page 15 Device 1 to Device 2 Device 2 to Device 1 Also If you connect to the SMX-RNS02 module by using Wi-Fi as AP than you can access to Device 1 and Device 2. Switch Chipset Features Chipset KSZ8895...
-
Page 16: Usb Devices
5.3. USB Devices The SMX-RNS02 module has 2 USB slots. You can plug storage devices, SMX-N1559 Wi-Fi module or SMX-RS001 (USB to RS-232) converter. You can increase your number of slots by using an intermediate device, such as a USB Hub. -
Page 17: Registering Smx-Rns02
In order to use the SMX-RNS02 device, the device must be registered first. Each device has a "Register Info" card. This card has a serial number and registration password. For... -
Page 18: Preparing Smx-Rns02
This option requires the SMX-N1559 module. See "Installation of the SMX-N1559 USB WiFi Module"section. 7.2. Device LEDs and Meanings The front cover of the SMX-RNS02 module has 2 LEDs. These are, respectively from the top; Ready LED (Ready LED) ... -
Page 19: Installation Of Smx-N1559 Usb Wi-Fi Module (Optional)
If you have a Wi-Fi module and want to make settings over Wi-Fi, you can skip this step. Connect one end of the Ethernet Cable to the SMX-RNS02 LAN port (one of the 2 ports at the bottom), and the other end to your PC's Ethernet port. -
Page 20: Energizing Your Device
7.5. Energizing your device Turn on the power supply or adapter to which the SMX-RNS02 is connected. Make sure that your USB or Ethernet devices that you want to make a remote connection are also turned on. When given the first energy, the "Ready LED" will light up off. About 30 seconds later "Ready LED"... - Page 21 Enter the required internet settings from the "WAN" and "Wireless Settings" pages. Go to the "LAN Settings" page. In order to connect to your field devices, your Ethernet field devices and SMX-RNS02 device must be on the same IP network. Enter the settings correctly. Example 1 (Predefined) ...
-
Page 22: How To Get Device Status Via Communication
You can get the device status by connecting to the Modbus Server running on port number “502” of the device. Device information is sent over Modbus as follows. Holding Register 40001-40008: Serial No (16 Byte) 40009: EMPTY 40010: Status / 10:Offline, 11:Online © 2020 SIMPLINX - 21 -... -
Page 23: Web Interface
If you change the settings, you must restart the device for the new settings to take effect. The IP address you will provide to your SMX-RNS02 Device & PC must be IP addresses that are not used by other devices. -
Page 24: Wan Settings Page
Wi-Fi with its serial number. If you change these settings, you must restart the device for the new settings to take effect. The Hotspot SSID is the same as your device's serial number. © 2020 SIMPLINX - 23 -... -
Page 25: Proxy Settings
By checking the LAN-> USB pass-through permission option, you can distribute the internet connection coming from the USB (Phone) to your devices in the LAN and enable your devices in the LAN to access the internet. © 2020 SIMPLINX - 24 -... - Page 26 Use the following IP address: select and specify the values as follows IP Address: It must be in the LAN IP block of your SMX-RNS02 module. Subnet Mask: Must be the same as the LAN MASK of your SMX-RNS02 module.
- Page 27 Bridge WAN & LAN Port setting may prevent you to make a remote connection to the device. If you change these settings, you must restart the device for the new settings to take effect. © 2020 SIMPLINX - 26 -...
-
Page 28: Import/Export Page
If your device does not turn off and on automatically, your settings are not loaded. Check the configuration file! All settings on the device will be deleted and your new settings will be loaded. This action cannot be undone. © 2020 SIMPLINX - 27 -... -
Page 29: Change Password Page
If the WLAN is plugged in and connected to a network, IP, MASK and MAC information of the interface If the WLAN Hotspot is connected and broadcasting, the IP, MASK and MAC information of the interface © 2020 SIMPLINX - 28 -... -
Page 30: Accessories
Installation of the SMX-N1599 USB WiFi Module Place and tighten the antenna if it is un-mounted. Plug the USB Wi-Fi module into an empty USB slot of the SMX-RNS02. Your SMX-N1559 module is ready for use. See the relevant documentation for detailed information. - Page 31 SimpLinx Elektronik Ltd. 07/2020 man-en-smx-rns02.docx Version 1.3 Halil Rifat Pasa Mh. Nazli Sk. No:1/5 No:17 Sisli/Istanbul www.simplinx.com...
