- Page 1 User Manual v1.2 User Manual...
- Page 2 TO RELEASE Hiss-Tec Fehmarn and all related parties from any and all liability for any loss, damage, injury or expense that you or any users of your Core Kiteboarding Product may suffer, or that your next of kin may suffer, as...
-
Page 3: Short Manual
CORE CONTROL SYSTEM Setup Bar and flying lines The new Core ESP Control System is ready for plug & play. Just unwind your lines, attach them to the kite and have fun! The following instructions and the picture on the left should give you a quick overview how to setup your new kite and bar. - Page 4 User Manual v1.2 Rigging the Kite Step 1 Check the wind conditions in order to choose the correct kite size. Lay out the kite. The arrow in the sand indicates the wind-direction. Secure the upwind wingtip with sand and make sure that all FAST- PUMP cleats are open to allow proper inflation of the kite.
- Page 5 User Manual v1.2 Rigging the kite Step 5 Push the pump nozzle into the inlet (smaller) valve and start to inflate the kite. Step 6 Inflate until the kite is almost full and then turn around until your back is facing towards the wind. Step 7 Now fully inflate the kite up to 6-7PSI.
- Page 6 User Manual v1.2 T H E E J E C T O R S Y S T E M Push the yellow Ejector upwards and This releases the Safety-pin. The Chickenloop opens. The rider is away from you to open the system. now only connected to the kite via the 5th Line.
- Page 7 User Manual v1.2 Activating the EJECTOR SECURITY SYSTEM In an emergency grab the The bar slides along the 5th The kite descends without pull Ejector with one or both hands line up to the Stopperball. at the edge of the wind and push upwards away from window.
- Page 8 User Manual v1.2 Relaunch: Face to face To start the kite again from the face to face position you have to pull in one steering line for around 2m. Keep tensioning the steering-line to enable the kite to right itself up further.
- Page 9 User Manual v1.2 Relaunch Relaunch is very easy. Depower the kite and pull on one floater. The kite will immediatly travel to one side. Keep tensioning the steering-line. When the kite reaches the border of the powerzone let the floater go and wait until the kite is fully in restart position.
- Page 10 Trim Via Adjuster / Function Of The Adjuster The CORE Bar has a pull-pull adjuster, that means depowering and powering of the kites is done with the two pull straps. pulling the right slope. The yellow strap is for depowering the kite: pull it towards you to shorten the front lines and depower the kite.
- Page 11 Always check the pulleys for free movement! Bridle Line Trim (experienced users only) The GT has some bridle tuning points for the front bridle. Using the point pointing to the middle of the kite will increase kite feedback, using the point more to the tip will decrease bar pressure.
- Page 12 Hiss-Tec Fehmarn will make the final warranty determination, which may require inspection and/or photos of the equipment, which clearly show the defect(s). If necessary, this information must be sent to the Core Kiteboarding distributor in your country, postage prepaid.
