Spear & Jackson S21CPW Original Instruction Manual

21.6v cordless pressure cleaner

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

21.6V

CORDLESS

Pressure Cleaner

S21CPW

CAUTION Read the instructions before

using the machine

These instructions contain important information that will help

you get the best from your pressure Cleaner, ensuring it is assembled

correctly and safely. If you need help or have damaged or missing parts,

call the Customer Helpline on 0345 605 2067

ORIGINAL

INSTRUCTION

MANUAL

AFTER SALES SUPPORT

0345 605 2067

SAN NO.: 0321/8020/11ZA

Table of Contents

Need help?

Do you have a question about the S21CPW and is the answer not in the manual?

Questions and answers

Summary of Contents for Spear & Jackson S21CPW

Page 1 ORIGINAL INSTRUCTION MANUAL 21.6V CORDLESS Pressure Cleaner S21CPW CAUTION Read the instructions before using the machine AFTER SALES SUPPORT 0345 605 2067 These instructions contain important information that will help you get the best from your pressure Cleaner, ensuring it is assembled correctly and safely.
Page 2 SPEAR & JACKSON SINCE 1760 For more than 250 years gardeners have enjoyed high quality performance and great results using Spear & Jackson tools. Our garden power tools combine continuous innovation and the latest in manufacturing technologies with a proud heritage. Each product is carefully designed with performance, comfort and durability firmly in mind, which has earned Spear &...
Page 3: Table Of Contents
CONTENTS Safety Information Description of symbols General safety Personal safety Operating safety Maintenance and storage safety Intended use Box Contents / Parts Assembly Operation Before starting Switching on/off Adjusting the rotary handle Adjusting working pressure Using the foam sprayer Using the brush 3 in 1 nozzle Maintenance Overview of cleaning...
Page 4: Safety Information
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine DESCRIPTION OF SYMBOLS The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the pressure Cleaner. WARNING SYMBOLS ON THE MACHINE Read instruction handbook before Do not connect the hose to the tap...
Page 5: General Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine WARNING SYMBOLS ON THE BATTERY PACK GENERAL SAFETY WARNING Water jets can Batteries contain Li-ion, waste batteries should be sorted for eco- be dangerous if subject to friendly.
Page 6 SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine you are holding the gun manufacturer. securely, otherwise you WARNING Water that has could injure yourself or flowed through backflow other people. preventers is considered to be non-potable. IMPORTANT! WARNING Do not use the machine if a supply cord...
Page 7: Personal Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine machine in a safe way and PERSONAL SAFETY understand the hazards involved. WARNING! ■ Don’t use the machine ■ RISK OF FATAL INJURY! without reading the instruction sheet. Use special care when cleaning tyres.
Page 8: Operating Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine ■ Stay alert, watch what you OPERATING SAFETY are doing. ■ Pressure hose fittings and ■ Do not operate the product couplings are important for when fatigued or under the safety of the appliance.
Page 9: Maintenance And Storage Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine in order to avoid frost MAINTENANCE AND STORAGE SAFETY damage. WARNING! INTENDED USE ■ Retrofitting or making any unauthorised changes to This pressure cleaner is the machine, as well as designed for domestic use the use of unapproved only:...
Page 10: Box Contents / Parts
BOX CONTENTS PARTS 3 in 1 nozzle Foam sprayer Main body Net bag Hose & filter Brush Extension lance Foldable bucket Battery pack Instruction manual Charger If there are any parts missing, please call the customer helpline on 0345 605 2067 AFTER SALES SUPPORT 0345 605 2067...
Page 11: Assembly
ASSEMBLY Install the extension lance i. Press the extension wand into the gun. (You will feel a slight spring resistance) ii. Secure the attachment by twisting. iii. Make sure that the extension lance button is on the top. Fitting the 3 in 1 nozzle Press and hold the nozzle lock button on the extension lance, and then assemble the 3in1 nozzle to the lance, make sure that the nozzle is...
Page 12 ASSEMBLY There are 2 water connection options: Use the self priming function. Put the hose and filter unit into the water source and make sure the filter unit is sunk below the water level. ii. Use the garden hose to connect to cleaner. The water supply in keeping with current regulations- ie.
Page 13 ASSEMBLY iv. When the battery is fully charged the green light stops flashing v. Once the battery is fully charged , depress the battery release button on two sides of the battery pack and then remove the battery pack. Power indicator This Li-Ion battery pack is equipped with a power indicator which is used to show the battery pack’s remaining charge.
Page 14: Operation
OPERATION WARNING - Wear suitable clothing, ear and eye protection when working with the equipment. Before starting i. Check the machine for visual defects. Ii. Check that all parts of the machine have been securely fitted. iIi. Check if the water connector and the inlet hose are tight. Switch ON i.
Page 15: Adjusting The Rotary Handle
OPERATION RISK OF FATAL INJURY! Use special care when cleaning tyres. Vehicle tyres/ tyre valves may become damaged or burst when handled improperly. First signs of damage include discolourations on the tyre. Damaged vehicle tyres/ tyre valves pose a life-threatening risk. Keep the jet at a distance of at least 30 cm! The water jet may be dangerous when handled improperly.
Page 16: Using The Foam Sprayer
OPERATION Using the foam sprayer Fill the detergent into the bottle (detergent mixture level to be between 30-50%). Install the foam sprayer on to the device. Using the brush Install the brush onto the device like picture shown. 3 in 1 nozzle (Fig. R) 3 in 1 noozle can be adjusted to 3 different nozzles by rotating the head.
Page 17 OPERATION This noozle can be adjusted to 3 different settings by rotating the head. Whilst holding the lance rotate the nozzle to your selected position making sure the nozzle is align with the lance arrow. AFTER SALES SUPPORT 0345 605 2067...
Page 18: Maintenance
MAINTENANCE Overview of cleaning After every use, wipe the machine with a slightly damp ▪ cloth. Do not clean the machine by using a pressure cleaner jet. Clean the high-pressure jet nozzle. ▪ The pressure cleaner is equipped with a water filter in inlet adapter to protect the pump.
Page 19: Clearing Limescale
MAINTENANCE Storing Store the machine where it is dry and well ventilated. When placing the machine out of service for an extended period of time, remove the cleaning agent and drain all the water left in the hoses. Transport If shipping, use the original packaging wherever possible. Disposal Disposing of the machine Machines which are labelled with the this symbol...
Page 20: Technical Data
TECHNICAL DATA Model S21CPW Nominal voltage of product with battery 21.6V d.c. / 2.5 Ah Water inlet pressure < 0.6 MPa Working pressure Eco: 13 Bar High: 22 Bar Working flow rate 2.67 l/min Weight 1.8 kg Battery pack Model...
Page 21: Troubleshooting
TROUBLESHOOTING Suspected malfunctions are often due to causes that the user can fix themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly. WARNING - Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself!
Page 22: Guarantee
GUARANTEE If your device develops a fault, please don’t hesitate to contact our customer service department on 0345 605 2067, the majority of issues can be solved directly over the phone. 1. These warranty terms cover additional warranty rights and do not affect your statutory warranty rights.
