Blocklychain SB-103 Manual

Smart button
Hide thumbs

Advertisement

Quick Links

Download this manual
SMART
BUTTON
SB-103

Advertisement

loading
Need help?

Need help?

Do you have a question about the SB-103 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blocklychain SB-103

  • Page 1 SMART BUTTON SB-103...
  • Page 2 HELLO Thank you for purchasing Smart Button. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from Internet. Manual Press Use the Smart Button as a manual switch by pressing the button on the device.
  • Page 3 How to Install Smart Button Connect Smart Button to a Micro USB charger. Go to www.blocklychain.com www.blocklychain.com...
  • Page 4 Log into your account in BKC Control Panel. [or signup if you don’t have an account.] www.blocklychain.com Login Click on Devices on the menu. My Home My Home Today Devices Services Tuesday, 29 September 2021 Home 12:28 Home Europe/London Devices...
  • Page 5 Select Smart Button from the list. My Home Add New Device Choose your device type Home Choose the type of your new device you want to install Devices Service Market Installed Services Motion Detector Door Sensor Smart Button Smart Plug Smart Speaker Activity Service Creator...
  • Page 6 Go to the Wi-Fi setting on your laptop/mob- ile and switch it to Smart_Button Wi-Fi. Smart_Button HomeWi-Fi James ST1QTJ1 Tigerx 2:28 pm 12/6/2020 Go back to BKC Control Panel and click on Next. My Home Add New Device Change your Wi-Fi Home Go to Setting on your mobile and connect to the Wi-Fi name “Smart_Button”.
  • Page 7 Choose your home Wi-Fi from the list and type the password. Then, click on Check Wi-Fi. My Home Add New Device Set your home Wi-Fi Home Choose your home Wi-Fi from the list below. Devices Manual Setting Available Wi-Fi list My Wi-Fi Service Market Wi-Fi X...
  • Page 8 How to Control Smart Button Log into your account in BKC Control Panel. Then, go to the Devices page. Your Smart Button card will be like below. Name of the Smart Button Button modes Last activity time Battery indicator Device dashboard Device connection indicator...

  • Page 9: Button Modes

    Button Modes Pressed When the Smart Button is pressed, the 1 polygon will turn red for 3 seconds. Double When the Smart Button is pressed two times, the 2 polygon will turn red for 3 seconds. Triple When the Smart Button is pressed three times, the 3 polygon will turn red for 3 seconds.
  • Page 10 Update device Connect the device to a charger. Click on the button on your device. Go to BKC Control Panel. Go to Devices page. On the device card, click on the device dashboard button. Go to the Config tab. Click on Update Now. Reset Factory On your Smart Button Click and release the button, then press and...
  • Page 11 BKC Control Panel In BKC Control Panel, you can register, monitor, and control your BKC devices. www.blocklychain.com...
  • Page 12 Installing BKC Control Panel On the phone Open the Google Chrome browser. Go to www.blocklychain.com Click on Login. Log into your account. On the pop-up page, click on Add to Home Screen. On the desktop Open the Google Chrome browser.
  • Page 13 Blocklychain Services In BKC Control Panel, BKC Services are mini apps that add new functionalities to smart devices. You can access hundreds of BKC Services in Service Market or easily develop new services on Service Creator to extend the functionality of your Smart Button.
  • Page 14 Service Creator In BKC Control Panel, using Service Creator, you can develop new services. How to create Blocklychain Services There are two programming consoles in Service Creator: 1. Blockly Console 2. Coding Console My Home 8952 Created Service Published Service Installed Service...
  • Page 15 Play Emergency Alarm 1.mp3 Text Service Creator 2. Coding Console Coding Console enables professional devel- opers to program BKC services by JavaScript syntax for Blocklychain-enabled devices including Smart Button. My Home *Describe this function... function cron() { Power1.SEND_COMMAND('TURN_OFF');} Home Devices if ((Shortcut1.PAYLOAD.state === 'pressed')) {...
  • Page 16 Status Indicator Description Connection Orange Connecting to Blocklychain (Blinking every 4 seconds) server on the Internet Orange Connecting to Wi-Fi (Blinking every 1seconds) Battery Blinking Red Very low battery Solid Red Low battery Solid Blue Charging Solid Green Full charge...
  • Page 17 Caution 1. Do not disassemble the product or change the batteries. 2. Do not charge the product at high temper- ature. Keep the device away from open fire to avoid explosion. 3. Improper use of your device’s battery may result in fire or explosion.

  • Page 18: Specification

    Specification Product Name Smart Button Model SB-103 Size 7x2x2 cm Weight 22 g Material Communication Wi-Fi 802.11 b/g/n 2.4GHz Battery 3.7V 600mA Lithium-ion rechargeable battery Charger micro USB 500mA...

  • Page 19: Package Content

    Package Content 1x Smart Button For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Blocklychain...
