MOS - UNO - IP
MANUAL
Status indication, white or red
Ethernet network connection
STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU
Mika microphone input
SUB-D 9 GPI input
Microphone output
Power supply: 12 till 24 volt DC,
polarity is not important.
Power consumption at 12 volts:
100mA, at 24 volts 70mA
Advertisement
Table of Contents
Summary of Contents for AeroAudio MOS - UNO - IP
- Page 1 Power supply: 12 till 24 volt DC, Ethernet network connection SUB-D 9 GPI input polarity is not important. Power consumption at 12 volts: 100mA, at 24 volts 70mA STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU...
-
Page 2: Gpi Control
After the reset boot the satus LED will turn white and facory default settings are restored. The MOS-UNO-IP can be reached at 192.168.0.101 again. GPI schematic: STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU... -
Page 3: Device Mode
Connect to device connects directly to an Axia node or QOR. Listen to server listens to TCP commands send from an external TCP server like Axia pathfinder to the MOS-UNO-IP on port 93. STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU... -
Page 4: Remote Device Settings
On a longer connection timeout the webpage will show the link has been disconnected. To restore the connection the MOS-UNO-IP has to be rebooted. STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU... -
Page 5: Gpi Settings
On the use of DHD global logics the name of TCP on and off will change After saving settings. STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU... -
Page 6: Standby Settings
After setting all system parameters these settings have to be saved. To save all settings click save and reboot. The MOS-UNO-IP will store all settings and reboot. After approximately 5 seconds the webpage can be reloaded. STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU... - Page 7 MOS - UNO - IP MANUAL Dimensions Dimensions:140 * 81,9 * 41,6 mm Weight 0,35 Kg STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU...
-
Page 8: Safety First
- Always follow the instructions of the supplier and manufacturer - Use only manufacturer specified accessories, spare and replacement parts. - Use the device only for the application the manufacturer intended. STEENWEG 148C - 9810 NAZARETH - BELGIUM - T +32 (0)9 396 76 40 - INFO@AEROAUDIO.EU...
