Summary of Contents for All Paws Pet Wash ADA813
- Page 1 2009 *ADA813 Shown MANUAL ADA Models ADA813 & ADA821 800.537.8231 www.AllPawsPetWash.com...
- Page 2 8642 US Highway 20 Garden Prairie, IL 61038 The ADA Modular buildings are the flagship products of All Paws Pet Wash. It is a piece of self-serve pet washing equipment that can be implemented and used in many different industries. These units are built with the quality and precision that our other products have been built with since 2009.
-
Page 3: Table Of Contents
CONTENTS page 3-5 I. OVERVIEW 1. Equipment 2. Plumbing 3. Electrical page 6-8 II. OPERATION 1. Set-Up 6 -7 2. Testing page 9 III. DAILY MAINTENANCE SCHEDULE page 10 IV. SECURITY page 11 V. TROUBLESHOOTING page 12 VI. ADA WARRANTY INFORMATION Please Note: Due to ongoing product changes, sales literature descriptions of product features and options may not reflect current product offering. -
Page 4: Overview
I. OVERVIEW 1. Equipment ADA Modular Building (813) Equipment Room Building A. Wash Tub B. Spray Control C. Sprayer D. Vacuum E. Dryer Water Column F. Vending Machine (optional) G. Equipment Room Equipment Room 1. Water Column a. Pressure Gauge b. -
Page 5: Plumbing
I. OVERVIEW (cont.) 2. Plumbing • Every ADA Modular Building comes with a trough which runs through the equipment room. The floor in the building is sloped toward the equipment room allowing gravity to carry discharge pump excess water under the wall and into the trough. Once the sensors detect that theres a collection of water in the trough, the discharge pump will kick on, draining the trough. -
Page 6: Electrical
I. OVERVIEW (cont.) 3. Electrical Electrical Box This box contains the electrical components that drive the spray controls. This box also contains the washdown and output test switches, used for maintenance and testing. Activates 2 minute timer. Resets with each button push. When light is on, timer is active. -
Page 7: Operation
Washdown switch again to reactivate the two minute timer. Filling Your Soap Containers • All Paws Pet Wash recommends a dilution ratio of 20:1 for our soap concentrates. This means that for every ounce of concentrate in your jug, you need to add 20 oz of water. If this ratio isn’t followed properly, you may end up with soap too viscous to syphon properly. - Page 8 II. OPERATION (cont.) Bleeding Air from Hot Water Heater • Before use of your pet wash, it is important to bleed the air from your hot water heater. Failure to bleed air can cause failure of heating element. • Locate the pressure relief valve on your water heater. It’s a brass colored valve with an aluminum lever extending from it, pointed towards the floor.
-
Page 9: Testing
II. OPERATION (cont.) • Turn on the sprayer to get the water flowing. Lock the sprayer Sprayer Lock in the “on” position and place in tub to keep the water flowing. • In your cabinet, you should see the soap from the Oat Shampoo begin the fill the line leading from the container up to the solenoid valves. - Page 10 The following are general, suggested guidelines for daily, weekly, monthly, and bimonthly maintenance on your All Paws Pet Wash self serve pet wash vending station. You may find more applicable methods of maintenance in the daily operation of your personal unit.
-
Page 11: Security
IV. SECURITY • All of the sales from your washes will end up in one place, behind the spray control system. The spray control system opens on the back side and is accessed via the equipement room. To access the back end of your control system, open your door and remove the pin keeping the panel in place. -
Page 12: Troubleshooting
TROUBLESHOOTING Common Problems & Solutions Problem: No water pressure flow in the wash tub. Solution: Check water flow from incoming water line. Check pressure gauge on water column in cabinet of APW. The unit requires 40-50 PSI to function properly. If you have sufficient flow form the incoming water line, and 40-50 PSI of required pressure, you will need to adjust the flow screw [Reference image on page 3 / #4 Inside... -
Page 13: Ada Warranty Information
[8642 US Hwy 20 Garden Prairie, IL 61038] for repair or replacement. All Paws Pet Wash will ship the repaired or replaced part back to the purchaser. Purchaser is responsible for the shipping charge to return to seller and seller is responsible for shipping charge to return to purchaser. - Page 14 est. 2009 Everything you need for Find a Pet Wash Near You! your pet wash business! 8642 US Highway 20 Garden Prairie, IL 61038 800.537.8231 www.allpawspetwash.com...
