Sundray Wireless AP-S800 Installation Guide
1 Product Overview
Sundray AP-S800 is an outdoor high-speed wireless access point supporting 802.11a/b/g/n,
developed by Sundray. It adopts the 2x2 MIMO technology and supports dual-band of
802.11ac/a/n and 802.11b/g/n and the maximum transmission rate can reach up to 600Mbps.
AP-S800 adopts the Gigabit port for uplink, ensuring high-speed wireless transmission. It
supports PoE, which makes deployment of AP-S800 much easier.
AP-S800 is designed with the shell of the IP 68 protection level and supports waterproof,
dampproof, dustproof, fireproof, and sun protection features. The shell can protect AP-S800
against harsh weather and outdoor environment. This ensures that AP-S800 can work in both
damp and cold areas. Additionally, AP-S800 supports point-to-point and point-to-multipoint
bridge functions, which boosts the feasibility of outdoor network construction. By working with
Sundray network access controller(NAC), AP-S800 makes access experience faster and more
secure.
AP-S800 is designed for outdoor environment, such as scenic spots, schools and parks, etc. It
provides four N-type external antenna interfaces. Omnidirectional or directional antenna can be
selected based on the actual environment.
1.1 Product Appearance
There are one 10/100/1000Mbps Ethernet port supporting PoE and four N-type external antenna
interfaces.
1 / 20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-S800 and is the answer not in the manual?

Questions and answers

Summary of Contents for SUNDRAY AP-S800

  • Page 1 Sundray Wireless AP-S800 Installation Guide 1 Product Overview Sundray AP-S800 is an outdoor high-speed wireless access point supporting 802.11a/b/g/n, developed by Sundray. It adopts the 2x2 MIMO technology and supports dual-band of 802.11ac/a/n and 802.11b/g/n and the maximum transmission rate can reach up to 600Mbps. AP-S800 adopts the Gigabit port for uplink, ensuring high-speed wireless transmission. It supports PoE, which makes deployment of AP-S800 much easier.
  • Page 2: Specifications

    Sundray Wireless AP-S800 Installation Guide Figure1-1 Front Panel Figure1-2 Side Panel 1.2 Specifications Model AP-S800 Hardware specifications Weight 2.25Kg Dimensions (Exclusive of antenna 210mmx210mmx70mm interfaces and accessories) Ethernet Port 1*10/100/1000Mbps 2 / 20...
  • Page 3 Sundray Wireless AP-S800 Installation Guide PoE 48 V/800 mA Power consumption < 35W External antenna, two 2.4 GHz N-type connectors and two 5 GHz N-type Antenna connectors Reset/Restore factory None settings Status indicator None Protection level IP 68 MTBF > 250000H RF specifications Tx Power ≤27dBm Tx Power Range 1dBm~the maximum allowed by local regulations Maximum transmission 2.4 G:300 Mbps speed(single frequency) 5 G:300 Mbps 802.11ac/n/a: 5.725GHz-5.850GHz, 5.15~5.35GHz (China)
 Operating frequency band 802.11b/g/n: 2.4GHz-2.483GHz (China) 3 / 20...
  • Page 4: Preparing For Installation

    Sundray Wireless AP-S800 Installation Guide 2 Preparing for Installation 2.1 Safety Precautions AP-S800 series products should be installed in an outdoor environment. To ensure that AP is operational and extend its lifetime, it must be installed in a qualified environment. Caution: To avoid damage to access point and bodily injury, please read and follow the safety precautions before installation of the AP-S800 series products. Please install the AP-S800 series products under the instructions of technical support representative. 2.1.1 Installation Site Selection Keep the AP away from places that are susceptible to high temperature, harmful gases, ü inflammable, explosive, electromagnetic interference (from radar station, transmitter station or substation), unstable voltage, violent shake, or loud noise, or places that are near source of pollutions. The product should be installed in the environment without any water leakage, dripping or ü dew. In engineering design, the site should be selected according to telecommunication network ü plan and technical requirements for telecommunication devices, and the following factors should be taken into account: hydrology, geology, occurrence odds of earthquake, electric power and transportation, etc. 2.1.2 Temperature and Humidity Requirements The requirements for temperature and humidity are listed below: Item...
  • Page 5: Grounding And Lightning Protection

    Sundray Wireless AP-S800 Installation Guide Operating humidity 0%~100% (non-condensing) Storage humidity 0%~100% (non-condensing) 2.2 Grounding and Lightning Protection In outdoor deployment, the following must be grounded separately: outdoor AP-S800, feeder lightning protector, lightning protector with Ethernet port and lightning rod. Ensure the grounding points are well grounded and take anti-oxidation measures against the grounding points(Grounding cable should be prepared by customers in advance).
  • Page 6: Installation Tools

    Sundray Wireless AP-S800 Installation Guide coiled. Outdoor The antenna support should be grounded. antenna A grounding lead-in is a metal conductor connecting a grounding net and a grounding strip. The grounding cable of the AP should be connected to the grounding strip. The grounding lead-in must be 30 meters or shorter. A Grounding piece of zinc-coated flat steel with a cross-section area of 40mm × 4 mm or lead-in 50mm × 5 mm is recommended. Connect the grounding strip and the grounding lead-in of the AP through the yellow and green grounding cable with an area of 35mm², or weld them directly. Take anti-erosion measures against the welding joint. Earth resistance should be less than 5 ohms. In an area with a higher earth resistance, reduce the earth resistance by using resistance reducing agent Grounding around the earthing conductor. resistance The top of the earthing conductor should be at least 0.7 meter away from the ground surface. In cold areas, the earthing conductor should be buried below the frozen soil layer. Use a shielded twisted pair cables for an AP deployed outdoors. Ensure that Network cable the devices at the two ends of the cable are well grounded. If a metal tube is used, the two ends of the tube should be grounded. 2.3 Installation Tools The following tools are required for installation of the AP-S800 series products and should be provided by customers(Sundray does not provide the following tools). Type of Tools Tools Phillips screwdriver, bolts, sleeves, cutting plier, steel measuring tape, marker Universal tool pen, percussion drill Special tool Cable stripper, crimping plier, electrical tape, network cable tester, waterproof 6 / 20...
  • Page 7 Sundray Wireless AP-S800 Installation Guide cement, waterproof glue Additional tool PC for troubleshooting 7 / 20...
  • Page 8 Sundray Wireless AP-S800 Installation Guide 3Installation Guideline 3.1 Installation Process Precautions: 8 / 20...
  • Page 9: Examining Installation Site

    Sundray Wireless AP-S800 Installation Guide You need to get the corresponding engineering drawing before beginning installation. ü AP-S800 series product should be installed at the specified site according to the engineering ü drawing. Before installation, you need to check whether the installation site is suitable. If it is not ü suitable, you can change the installation site but the distance between the new and the specified sites on the engineering drawing cannot be greater than 1 meter. Record the MAC address and installation site of the access point(MAC address is on the side ü panel of the AP), for example, MAC: 100D0E2020CDE1, location: on the top of the building XXX. 3.2 Examining Installation Site Outdoor access point must be installed on a pole or a bracket. The pole and bracket must be ü vertical. If the pole or bracket is made of iron, it should be protected from oxidation. The installation site of the access point and its height must meet the design requirements. If an outdoor AP-S800 is installed on a pole on the top of a building, it cannot be suspended ü outwards in the air. On the top of a building, outdoor AP-S800 should be installed in a place with less sunlight ü...
  • Page 10 Sundray Wireless AP-S800 Installation Guide Figure3-1 Pole Mounting Kit No. Component Long bolt Mounting bracket Fixing plate Flat washer Spring washer Nut Step 1: Install a pole and fix the bracket on the pole, as shown below: 10 / 20...
  • Page 11 Sundray Wireless AP-S800 Installation Guide Figure3-2 Install Bracket on a Pole Step 2: Insert two hex head bolts into the installation holes on the upper part of the plate of access point and do not tighten the bolts, as shown below: Figure3-3 Insert Hex Head Bolts 11 / 20...
  • Page 12 Sundray Wireless AP-S800 Installation Guide Step 3: Position the installation holes on the plate of access point over the holes on the mounting bracket, as shown in ①, and press the access point downwards, as shown in ②, until it is tightened. Figure3-4 View 1 of Installing AP on the Mounting Bracket Step 4: Insert the other two bolts into the installation holes on the lower part of the plate of access point. Figure3-5 View 2 of Installing AP on the Mounting Bracket 12 / 20...
  • Page 13 Sundray Wireless AP-S800 Installation Guide 3.4 Grounding Access Point Connect access point to protection grounding using a yellow and green grounding cable(provided by customers). For details, refer to Grounding and Lightning Protection section. 3.5 Installing Outdoor Antenna Outdoor antennas are classified as directional and omnidirectional antennas. The following introduces how to install the two types of outdoor antennas. Installation precautions: Outdoor antenna should be installed away from high-power electronic devices and no large ü obstruction or metal object is allowed in the coverage direction. The antenna height should meet the requirements of signal coverage and the tip of the ü antenna should fall within the 45° protection angle of the lightning rod. Outdoor antenna support should be solid. The pole on which the antenna is installed should ü...
  • Page 14 Sundray Wireless AP-S800 Installation Guide Figure3-6 Installation of Omni Outdoor Antenna 3.5.2 Installing Directional Outdoor Antenna The directional antenna pole should be 40mm to 70mm in diameter. ü You should select such an installation location for the pole that the antenna direction and ü tilt could be adjusted freely. 1) Weld the lightning rod onto the tip of the pole. 2) Install the antenna pole onto a cement pier. 3) Use a 40mm × 4 mm flat steel to connect the pole to the ground grid. 4) Use the pole-mounting bracket to install the directional outdoor antenna on the pole. 14 / 20...
  • Page 15: Connecting Cables

    Sundray Wireless AP-S800 Installation Guide Figure3-7 Installation of Directional Outdoor Antenna Notes: Directional outdoor antennas cannot be installed at the same height on a same pole. If two directional outdoor antennas are installed on a same pole, the vertical distance between those antennas should be more than 2 meters. 3.6 Connecting Cables RF and Ethernet cables need to be connected to AP-S800 after the access point and outdoor antenna are installed. Precautions: Cables should be placed according to design requirements. ü 15 / 20...
  • Page 16 Sundray Wireless AP-S800 Installation Guide Cables should not be placed near high-voltage pipe, fire pipe or lightning protection cable to ü avoid electromagnetic interference. It is recommended to use PVC pipe, iron pipe, Plica pipe, or cable trunking to run cables. If a ü metal pipe is used, the two ends of the pipe should be grounded. For outdoors PVC pipe placed horizontally, drill a small hole on the pipe so that the water ü can drain out. For the holes in the wall, through which cables go, they should be blocked with waterproof ü and fireproof materials. 3.6.1 Connecting RF Cable Follow the following steps to connect RF cables to RF interfaces(2.4GHz and 5GHz): (1) Install a feeder lightning arrester onto each RF interface, as shown below: Figure3-8 Installation of Feeder Lightning Arrester on RF Interface 16 / 20...
  • Page 17 Sundray Wireless AP-S800 Installation Guide (2) Connect one end of the RF cable to the feeder lightning arrester and the other end to the outdoor antenna. Figure3-8 Connect RF Cable to Feeder Lightning Arrester (3) Connect a grounding wire to lightning arrester and then wrap the joint of lightning arrester with waterproof tape. 3.6.2 Connecting Ethernet Cable Figure3-9 Connect Ethernet Cable Follow the following steps to connect an Ethernet cable: (1) An Ethernet cable needs to pass through a waterproof cover for waterproof purpose (an Ethernet cable with a RJ-45 connector is unable to pass through), you need to make an Ethernet cable connector on site. (2) Connect the Ethernet cable to the Ethernet port on the access point. (3) Tighten the waterproof cover. (4) Use waterproof tape to wrap the joint between the waterproof cover and the cable. 17 / 20...
  • Page 18: Examination After Installation

    Sundray Wireless AP-S800 Installation Guide Notes: In outdoor environment, Ethernet cable must have waterproof cover. It is recommended to use shielded Cat5 or enhanced Cat5 cable, and the length of the Ethernet cable used to connect AP to switch cannot exceed 100 meters. 3.7 Waterproof and Lightning Protection To ensure that access point and feeder lightning arrester are well grounded, refer to Grounding and Lightning Protection section. Make sure that the following joints are wrapped with waterproof tape: four joints of feeder lightning arresters, four joints between antennas and feeder lightning arresters, one joint of Ethernet port. For how to wrap joint with waterproof tape, refer to the attached figure 2. 3.8 Examination After Installation After the installation and cabling, check the following items before powering access point: Access point and antenna are installed firmly. ü Power source meets the power specifications of the AP. ü...
  • Page 19 Sundray Wireless AP-S800 Installation Guide Attached Figure1 Connect Involved Components 19 / 20...
  • Page 20 Sundray Wireless AP-S800 Installation Guide Attached Figure 2 How to use waterproof tape Official Site: http://www.sundray.com Hotline: 400-878-3389 20 / 20...
