Summary of Contents for JetBlack VOLT V2
- Page 1 QUICK START GUIDE ACCESSIBLE PERFORMANCE...
-
Page 3: Table Of Contents
CHANGING TO A CAMPAG OR XD-R FREEHUB BODY MOUNTING YOUR BICYCLE CONNECTIVITY LIGHT (LED) DISPLAY DEVICE COMPATIBILITY CONNECTING YOUR TRAINER TO THE JETBLACK VOLT APP UPDATING / CHECKING FIRMWARE VERSIONS PERFORMING SPIN DOWN CONNECTING TO 3RD PARTY TRAINING APPLICATIONS PRODUCT CARE AND MAINTENANCE TROUBLE SHOOTING AND FAQ’S... - Page 4 THANK YOU FOR PURCHASING THE JETBLACK VOLT™ V2 SMART TRAINER. BE SURE TO READ AND FOLLOW ALL INSTRUCTIONS BEFORE USE. VOLT™ V2 QUICK START GUIDE...
-
Page 5: Jetblack Volt™ V2 Ems Trainer
JETBLACK VOLT™ V2 EMS SMART TRAINER DESIGN SPECIFICATIONS Total weight 16.5KG Max User Weight 120 kg Power Requirements 100-240 VOLT™, 1.5A, 50Hz-60Hz Wireless Connection Bluetooth FTMS and ANT+ FEC Resistance type Electromagnetic braking system Accuracy Maximum Simulated Grade Maximum Power Output... -
Page 6: In The Box
IN THE BOX 1 VOLT™ V2 Electromagnetic unit 6 Power Adapter 2 VOLT™ V2 stabilisation legs x2 7 Adapter A- Quick Release- Drive Side Spacer 3 Bolt/Nut x4 8 Adapter B- Quick Release- Non-Drive Side Spacer (130mm/135mm) 4 Quick Release Kit 9 Adapter C- Thru Axle- Drive Side Spacer 5 Open-End Wrench 10 Adapter D- Thru Axle Non-Drive Side Spacer (12x142mm/12x148mm) -
Page 7: Bike Compatibility
BIKE COMPATIBILITY JETBLACK VOLT™ V2 IS COMPATIBLE OR ADAPTABLE WITH MOST ROAD AND MOUNTAIN BIKES BUT MAY NOT SUIT SOME SINGLE SPEED, RECUMBENT AND SOME THRU AXLE CONFIGURATIONS. • 130 / 135MM QUICK RELEASE • 12 X 142/148MM THRU AXLE REAR WHEEL SIZE: •... - Page 8 VOLT™ V2 QUICK START GUIDE...
-
Page 9: Setting Up Your Volt
VIEW VIDEO Unboxing & Installation SETTING UP YOUR VOLT™ ATTACH THE FRONT AND REAR LEGS USING TOOLS PROVIDED. Short leg to the rear. Long leg to the front. This ensures optimal stability; the front should have the longer side supporting the Drive side. VOLT™... -
Page 10: Cassette Replacement
VIEW VIDEO Cassette Replacement CASSETTE REPLACEMENT Your VOLT™ V2 comes with a pre-installed 11 speed cassette. Please view video online for a guide on changing your cassette. ATTACHING A 9-SPEED OR 10-SPEED CASSETTE Before attaching a 9-speed or 10-speed cassette, you need to put the 1.8mm cassette washer onto the cassette body first and then secure the cassette tightly on the VOLT™... - Page 11 130MM OR 135MM QUICK RELEASE INSTALLATION When using a quick release bicycle frame, you need to use adapter A, adapter B and the quick release kit (these three accessories are included in the package). Please refer to the figure on the right for the installation. 142MM OR 148MM THRU AXLE INSTALLATION When using a thru axle bicycle frame, you...
-
Page 12: Changing To A Campag Or Xd-R Freehub Body
CHANGING TO A CAMPAG OR XD-R FREEHUB BODY The stock free hub can be removed with or without the cassette installed. If you choose to remove the cassette prior to removing the free hub, follow the instructions on previous page. Remove the Adaptor C nut with the 17mm Remove the existing free hub by sliding off. - Page 13 VIEW VIDEO Cassette Replacement Install the free hub on the axle. Twist counter clockwise to help the pawls fall into place. You should not be able to see the pawls. Torque the nut to precisely 6Nm. Re-install the Adaptor C nut removed in step 1. IMPORTANT: Over-torquing the nut may cause damage to the bearings.
-
Page 14: Mounting Your Bicycle
VIEW VIDEO MOUNTING YOUR BICYCLE Shift the chain on your bicycle to the smallest sprocket on the cassette and then remove the rear wheel. Align the bicycle’s chain with the smallest sprocket on the trainer cassette, then Quick Release mount the bicycle frame onto the VOLT™ V2’s axle. Securely tighten the QR axle as you would on your... -
Page 15: Connectivity Light (Led) Display
SOLID BLUE = Bluetooth is connected and the trainer is active and sending signals to your device. TIP: The JetBlack VOLT™ will only connect to one Bluetooth device at a time. Please ensure App is properly closed before trying to connect to a different training App. -
Page 16: Device Compatibility
DEVICE COMPATIBILITY TRAINER TO THE JETBLACK VOLT APP APPLE iOS The JetBlack VOLT™ V2 is designed to work with the Ensure all 3rd party Apps are closed on your JetBlack Volt App which supports devices running iOS device. 11 and newer. -
Page 17: Performing Spin Down
We recommend performing a spin down calibration if your trainer has moved or there has been a significant change in temperature. For optimal calibration we recommend using the JetBlack Volt App. FOR BEST RESULTS WARM UP YOUR TRAINER FOR 10 MINUTES BEFORE PERFORMING SPIN DOWN CALIBRATION. - Page 18 VOLT™ V2 QUICK START GUIDE...
-
Page 19: Product Care And Maintenance
Regularly check the VOLT™ V2 and particularly the mounting system for damage. If you suspect your VOLT™ V2 may be damaged, do not use it and contact your supplier. JetBlack Trainer We recommend using an indoor training fan when training. -
Page 20: Trouble Shooting And Faq's
TROUBLE SHOOTING AND FAQ’S Visit support.jetblackcycling.com THIRD PARTY COMPATIBILITY The JetBlack VOLT™ V2 uses industry standard protocols allowing us to seamlessly connect to most Third Party Apps. INCLUDED FREE TRIALS: VOLT™ V2 QUICK START GUIDE... -
Page 21: Safe Use Guidelines
Do not put fingers, feet or dangling objects near any moving parts. • Do not attempt to dismount until all moving parts have stopped. • Do not attempt to modify your JetBlack VOLT™ V2 Trainer. • Do not attempt to stop the resistance unit or flywheel manually. •... -
Page 22: Warranty
It is the responsibility of the purchaser to retain receipt for proof of purchase if a warranty claim is required. If you have any questions or would like to resolve an issue, please visit the JetBlack Cycling website for trouble shooting information, frequently asked questions and instructional videos. - Page 23 MOST IMPORTANTLY... VOLT™ V2 QUICK START GUIDE...
- Page 24 INTRODUCING TRAINER SUITE JETBLACK WATER BOTTLE CONCEPT DESIGNS // 08 ACTUAL SEPTE JetBlack Turn Riser Block & Smart Turn JetBlack Riser Block Trainer Table JetBlack Rocker Plate JetBlack TV Stand JETBLACK WATER BOTTLE CONCEPT DESIGNS // 08 ACTUAL JetBlack JetBlack...
