Summary of Contents for IHS Roof Pro 12000
- Page 1 Roof Pro 12000 Portable Generator Operators Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PROPER INSTALLATION & USAGE Introduction Pg. 2 You must be sure your new generator/engine set is: Basic Information Pg. 2 Properly serviced before starting. - Proper Use & Installation Operated in a well ventilated area. - Specifications Properly exhausted and gases safely dispersed. -
Page 3: Ansi Safety Section
ANSI Safety Definitions d. Keep a fire extinguisher nearby and know its proper *********************************************************** use. Fire extinguishers rated ABC by NFPA are ap- DANGER: propriate. ‘DANGER’ indicates an imminently hazardous situation e. Store fuel only in an approved container, and only in a which, if not avoided, will result in death, or serious injury. -
Page 4: Testing Policy
Check the appliance or tool nameplates for the current TESTING POLICY and voltage to insure compatibility. Remember that power Before any generator is shipped from the factory, it is taken from receptacle C reduces the power available at fully checked for performance. The generator is loaded both A and B and vice versa. -
Page 5: Preparing The Unit - Unpacking
The generator responds with high initial starting current, GASOLINE USAGE but the engine speed drops sharply. The overload may stall the 1. When using gasoline always use a good grade of un- engine. If allowed to operate at very low speeds, the elec- leaded fuel. -
Page 6: Battery Charging
b. Reverse the sequence when disconnecting, discon- BASIC OPERATION nect the negative cable first. These engines produce enough direct current to keep a battery charged under ELECTRIC STARTING normal operating conditions, but is not intended to be If the engine is cold and stiff or if the battery is not fully used as a battery charger. -
Page 7: Operating Speed
Note: Load vs. Output Genera- Speed Frequency Voltage The use of a fuel additive, such as STA-BIL or an equiva- tor Load lent will minimize the formation of gum deposits during (RPM) (Hz) storage. Such an additive may be added to gasoline in None 3690 61.5... -
Page 8: Grounding The Unit
The generator/engine set is inherently a self regulating A 4-wire receptacle (two hot, one ground, and one neu- unit based on engine speed. The engine governor will tral) has been provided on the control panel for use in automatically adjust itself to the load. No harm to the temporary power applications requiring 120/240 volt generator will result if it is operated with no load con- power. -
Page 9: Generator Care
1. Change the oil after the first month or 20 hours of op- 5. Carbon Canister: Designed to collect, store, and dis- eration and every 6 months or 100 hours thereafter un- pose of fuel vapors created in the fuel tank / fuel sys- der normal operating conditions. -
Page 10: Troubleshooting
TROUBLESHOOTING HINTS PROBLEM (SYMPTOMS) - POSSIBLE CAUSES _____________________________________________________________________________________________________________________________________________________________________________ 1. WON’T START Low Oil Level Fouled Spark Plug Out of Fuel Start Switch in Off Position _____________________________________________________________________________________________________________________________________________________________________________ 2. VOLTAGE TOO LOW Engine Speed is Too Low Generator Overloaded ... -
Page 11: Maintenance Log
MAINTENANCE LOG DATE - ITEM WORK PERFORMED HOURS... -
Page 12: Warranty Information
24-MONTH LIMITED WARRANTY Industrial Heat Sources, Inc., warrants to the original purchaser for 24 months that goods manu- factured or supplied by it will be free from defects in workmanship and material, provided such goods are installed, operated and maintained in accordance with Industrial Heat Sources, Inc., written instructions.
