- Page 1 SUNFORD A cell booster specially created for the young SF003 Cell phone booster Installation Guide sunford_after-sales@outlook.com NEED HELP ? 3-year manufacturer‘s warranty...
-
Page 2: Table Of Contents
CATALOG Package Contents Preparation Inside Antenna Placement STEP 1: Mount & Point Outside Antenna Toward Nearest STEP 2: Cell Tower STEP 3 : Route & Connect Outside Antenna To Booster Route & Connect Inside Antenna To Booster STEP 3 : Power Up The Booster &... -
Page 3: Package Contents
Package Contents Booster Inside Outside Loft 3L Antenna Antenna Roof/Pole 2*30 ft of Power Mount 3D-FB Supply Bracket Cables Wall Mount Bracket... -
Page 4: Preparation
Preparation You Will Need (tools not included) Make sure the following materials are prepared and ready for your installation. 1 to 2 hours 2 people (a person to help with antenna calibration) Ladder Drill (if routing cable through wall) ... -
Page 5: Step 1: Inside Antenna Placement
Step 1: Inside Antenna Placement Place the Inside Antenna where you need the greatest signal boost and place Booster in your desired location. NOTE: Do not connect booster to power until the system is fully installed. Choose right position for the indoor antenna •... - Page 6 (STEP 1 cont.) Booster Placement Mount the booster • Choose a ventilated and dry place • Keep away from heat • Don't cover booster Booster will about 30 degrees Fahrenheit higher than the ambient temperature, which is a normal phenomenon.
-
Page 7: Step 2: Mount & Point Outside Antenna Toward Nearest Cell Tower
Step 2: Mount & Point Outside Antenna Toward Nearest Cell Tower Pole mounting and wall mounting options are included. The pole mounting option is preferred because it will be easier to adjust to the direction of the cell tower. Attach the Mount to the Outside Antenna and use the Bracket Clamps to attach the Antenna to a pole or exhaust pipe. - Page 8 Point the Outside Antenna toward the nearest cell phone tower. To find the nearest tower, use an app such as 'Open Signal'. This is the most critical step of the installation process because it will determine the overall performance of the booster system.
- Page 9 Keep enough distance between outside and inside antenna NOTE: The Outside Antenna must be at least 40 feet (12 meters) Straight line distance or 30 feet (9 meters) horizontal 20 feet (6 meters) vertical from the Inside Antenna for best performance. The greater the separation between the Inside and Outside Antennas, the better performance you will get from the booster.
- Page 10 Select the optimal mounting location for the outside antenna After identifying the area of strongest signal, choose the surface where you will mount your outside antenna. 1. The location should allow for sufficient separation between the outside antenna and inside antenna. 2.
- Page 11 Antenna mutual position The outside antenna should be oriented in a way that it does not “face” the inside antenna. Caution: Do not aim an outside antenna towards inside antenna. Caution: The inside antenna cannot face the outside antenna.
-
Page 12: Step 3: Route & Connect Outside Antenna To Booster
Step 3: Route & Connect Outside Antenna To Booster Connect the white 3D-FB Cable to Outside Antenna and route cable into the home, secure the cable near the antenna. All connections should be finger tightened only. Route cable to the Booster and connect to the port labeled 'OUTSIDE'. -
Page 13: Step 3: Route & Connect Inside Antenna To Booster
Step 3: Route & Connect Inside Antenna To Booster Connect the Inside Antenna to the 'INSIDE' on the booster. port... - Page 14 (STEP 3‐A cont.) Wall Mounting Option Fasten bracket to back of Inside Antenna Tap anchors in Secure bracket to wall Drill holes Mounting Inside Antenna on wall bracket sideview...
-
Page 15: Step 4: Power Up The Booster & Optimize The System
Step 4: Power Up The Booster & Optimize The System Plug in the Power Supply and connect it to the nearest power outlet. NOTE: We strongly recommend using a power strip with surge protection. Outside Antenna Power Supply Booster Inside Antenna... -
Page 16: Measuring Booster Performance
Measuring Booster Performance How To Get Signal Strength As A Number iPhone® Dial *3001#12345#* then press Call. 1 Hold down power button until you see 'Slide to Power Off'. 2 Then release the power button. 3 Hold the Home button until your main screen appears. If you want to check 3G/1x but your iPhone is picking up 4G/ LTE signal, go to Settings>Cellular>Cellular Data Options>En_x0002_able .LTE>Select Off. - Page 17 How To Confirm That Your Installation Is Correct And Effective? Having an accurate measurement of signal strength in decibels (dBm) is crucial when installing your system. Decibels accurately measure the signal strength you are receiving. (MEASURING BOOSTER PERFORMANCE AFTER INSTALLATION cont.) Signal strength at 6 feet from indoor antenna Note here: Signal strength at 6 feet from outdoor antenna Note here: Compare Results If the signal strength in decibels (dBm)at 6 feet from the indoor antenna is 15‐20dB higher than the signal strength at 6 feet from the outdoor antenna, then your system has achieved the optimum results. Note: Since it is a negative number, the smaller the number, the greater the signal strength. DID YOU KNOW a signal increase of just 3dB is 2 times the power and signal amplification!
-
Page 18: Light Patterns
Light Patterns Band Indicator Lights Solid Green: • Every time the power is powered on, all the band indicators will turn orange for about 1 second. This indicates your booster has passed the self-test and is in good condition. When the booster is functioning properly, all the band indicators will remain solid green during operation. -
Page 19: Troubleshooting
Troubleshooting IF YOU ARE HAPPY WITH THE COVERAGE, THESE LIGHT ISSUES DON'T HAVE TO BE RESOLVED. YOUR CARRIER'S BAND HAS NOT BEEN AFFECTED. FIXING ANY BAND INDICATOR LIGHTS BLINKING RED ISSUES Band Indicator Lights Blinking Red 1. Band Indicator Lights Blink 1 To 15 Times ( 1 cycle) Then Turn Green That means the gain lowered 1~15 dB. - Page 20 How to solve the problem of oscillation: 1. Keep enough distance between inside and outside antenna Minimum Required Separation Distance Between Inside and Ouside Antenna: Straight line distance over 40 feet(12 meters) or 30 feet (9 meters) horizontal distance 20 feet (6 meters) vertical distance (as far as possible). 2.
-
Page 21: Safety Guidelines
Safety Guidelines To uphold compliance with network protection standards, all active cellular devices must maintain at least six feet of separation distance from inside unit antenna and outside unit antenna and at least four feet of separation distance from inside unit. Use only the power supply provided in this package. -
Page 22: Specifications
Specifications SF003 Model Number F‐Female on the Inside Antenna / F‐Female on the Outside Antenna Connectors 5 dB nominal Noise figure 75 Ohms / 75 Ohms Antenna lmpedance 0.35Kg Weight 698‐716MHz, 776‐787MHz, 824‐849MHz Frequency 728‐746MHz, 746‐757MHz, 869‐894MHz 700A‐MHz 700MHz 800MHz Power output for single cell phone Band12 Band13 Band5 (Uplink)dBm 60 60 62 700A‐MHz 700MHz 800MHz Power output for single cell phone Band12 Band13 Band5 (Downlink)dBm 62 62 65 1W Max EIRP 5℉ to 140℉ (‐15℃~60 ℃) Operating temperature lsolation >110 dB... -
Page 23: Warranty
(EN) This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. (FR) Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio dispense de permis. - Page 25 Notes SUNFORD A cell booster specially created for the young sunford_after-sales@outlook.com NEED HELP ?
