Pairing of 2nd Generation RF Transmitters with
Double shafted Motor 4240N, using external RF Receiver Module 216P:
Wall Mount Bracket (included)
EL-203P Single Channel Transmitter with
LED Light; Dimension: 1 1/8" x 2 1/8"
(1
st
generation transmitter has no LED light)
Magnetic
EL-204P-1
Wall mount
Handheld
(included with
Transmitter
Important: on the back of each transmitter you will find a small hole with a micro push button switch behind, used for
all transmitters)
(1-channel)
the pairing with Module 216P (see pairing instructions below).
407: R-1: 02/20
Quick Reference Guide (QRG) #13
EL-204P-2
Handheld
Transmitter
(2-channels)
EL-204P-16
EL-204P-6
Handheld
Handheld
Transmitter
Transmitter
(16-channels)
(6-channels)
Effective Date: Feb 2020
EL-213P "Wizard"
16-Channel handheld and/or
wall mounted RF Remote
Transmitter with LED Display
(1
st
generation Transmitter
has no LED display)
Dimension: 4 1/4" x 6 1/4
Dimension of all shown
Transmitters: 2" x 5"
Advertisement
Summary of Contents for AutoMotionShade EL-204P-1
- Page 1 Dimension: 4 1/4” x 6 1/4 EL-203P Single Channel Transmitter with LED Light; Dimension: 1 1/8” x 2 1/8” generation transmitter has no LED light) Dimension of all shown Transmitters: 2” x 5” Magnetic EL-204P-1 EL-204P-2 EL-204P-16 EL-204P-6 Wall mount Handheld Handheld...
- Page 2 All above transmitters will work with Motor 4240N in conjunction with Module 216P. Please note that 1 and 2 generation RF Transmitters are not interchangeable; the external Module 216P only works with 2 generation RF Transmitters. Special Feature: Module 216P gives you the option to control a motor both remotely with an RF transmitter and by means of a wall switch.
- Page 3 Note 1: To clear or un-pair a single channel on the remote, first select that channel on the remote transmitter, then press and hold the pair button hole on back of remote for a few second (on transmitter EL-213P “SET” appears on the display), then press “down”...
