Bell'O Triple Play TP4463 Assembly Instructions Manual

Flat panel tv mounting system
Hide thumbs

Advertisement

Quick Links

Download this manual
OPTION 1
OPTION 1
OPCIÓN 1
ВАРИАНТ 1
Flat Panel TV Stand
Meuble pour TV à écran plat
Base para panel de TV de pantalla plana
Подставка под телевизор с плоским
экраном
INSTRUCCIONES DE ENSAMBLAJE
Patent pending / Brevet en instance / Patent pendiente / Заявлено на патент
Made in China / Fabriqué en Chine / Hecho en China / Сделано в Китае
Italian designed / De design italien / De diseño italiano/ Разработано в Италии
Do not discard these instructions / Ne pas jeter ces instructions
Conserve estas instrucciones / Не выбрасывайте эту инструкцию
FLAT PANEL TV MOUNTING SYSTEM
SUPPORT DE TÉLÉVISEUR À ÉCRAN PLAT
SISTEMA DE INSTALACIÓN DE TV DE PANTALLA PLANA
КОМПЛЕКТ ПОД ТЕЛЕВИЗОР С ПЛОСКИМ ЭКРАНОМ
ВАРИАНТ 2
Stand with TV Mounting System
Meuble avec support de TV
Base con sistema de soporte para TV
Подставка со стойкой для крепления
ASSEMBLY INSTRUCTIONS
INSTRUCTIONS D'ASSEMBLAGE
ИНСТРУКЦИЯ ПО СБОРКЕ
TP4463
OPTION 2
OPTION 2
OPCIÓN 2
телевизора
OPTION 3
OPTION 3
OPCIÓN 3
ВАРИАНТ 3
Stand with Wall Mount
Meuble avec support mural
Base con soporte de pared
Подставка с креплением на стене
DSYF-1_050714v1T

Advertisement

loading
Need help?

Need help?

Do you have a question about the Triple Play TP4463 and is the answer not in the manual?

Questions and answers

Related Manuals for Bell'O Triple Play TP4463

Summary of Contents for Bell'O Triple Play TP4463

  • Page 1 TP4463 FLAT PANEL TV MOUNTING SYSTEM SUPPORT DE TÉLÉVISEUR À ÉCRAN PLAT SISTEMA DE INSTALACIÓN DE TV DE PANTALLA PLANA КОМПЛЕКТ ПОД ТЕЛЕВИЗОР С ПЛОСКИМ ЭКРАНОМ OPTION 2 OPTION 1 OPTION 3 OPTION 1 OPTION 2 OPTION 3 OPCIÓN 1 OPCIÓN 2 OPCIÓN 3 ВАРИАНТ...
  • Page 2 BELL’O INTERNATIONAL CORPORATION WILL NOT BE RESPONSIBLE FOR FAILURE TO ASSEMBLE AS DIRECTED OR FOR THE IMPROPER ASSEMBLY, USE, OR HANDLING OF THIS PRODUCT. ! IMPROPER INSTALLATION OF THIS PRODUCT MAY CAUSE DAMAGE OR SERIOUS INJURY. BELL'O INTERNATIONAL CORPORATION CANNOT BE LIABLE FOR DIRECT OR INDIRECT DAMAGE OR INJURY CAUSED BY INCORRECT MOUNTING, INCORRECT USE, OR INCORRECT ASSEMBLY.
  • Page 3 à la clientèle au : 1-888-235-7646 (USA/Canada) ou +1-732-972-1333 (International) de 9h00 à 17h00 (heure de l'Est), lundi à vendredi. Bell'O International Corps décline toute responsabilité en cas d'assemblage non conforme aux instructions ou pour l'assemblage, l'utilisation ou la manutention incorrects de ce meuble.
  • Page 4 SE ENSAMBLA TAL COMO SE INDICA NI DE SU ENSAMBLAJE, USO O MANEJO INCORRECTOS. ! LA INSTALACIÓN INCORRECTA DE ESTE PRODUCTO PUEDE CAUSAR DAÑOS O LESIONES GRAVES. BELL'O INTERNATIONAL CORPORATION NO PUEDE SER RESPONSABILIZADA POR LOS DAÑOS O LESIONES DIRECTOS O INDIRECTOS CAUSADOS POR EL MONTAJE, USO O ENSAMBLAJE INCORRECTOS.
  • Page 5 ПОЗВОНИТЕ В ОТДЕЛ ОБСЛУЖИВАНИЯ КЛИЕНТОВ НАШЕЙ КОМПАНИИ ПО ТЕЛЕФОНУ: 1 888 235 7646. ПОЖАЛУЙСТА, ПРИГОТОВЬТЕСЬ НАЗВАТЬ НОМЕР МОДЕЛИ, КОД ДАТЫ, НОМЕРА ДЕТАЛЕЙ И ИМЕЙТЕ ПРИ СЕБЕ ЧЕК ИЛИ ДРУГОЙ ДОКУМЕНТ, ПОДТВЕРЖДАЮЩИЙ ПОКУПКУ. КОРПОРАЦИЯ BELL'O ОТПРАВИТ ВАМ ВСЕ НЕОБХОДИМЫЕ ДЕТАЛИ ДЛЯ ЗАМЕНЫ НА ТЕРРИТОРИИ КОНТИНЕНТАЛЬНОЙ ЧАСТИ США.

  • Page 6: Table Of Contents

    PARTS LIST / NOMENCLATURE DES PIÈCES / LISTA DE PIEZAS / ПЕРЕЧЕНЬ ДЕТАЛЕЙ Quantity Quantity Quantité Quantité Part / Pièce / Pieza / Деталь Part / Pièce / Pieza / Деталь Cantidad Cantidad Количество Количество YF11 12 mm YF12 18 mm YF13-3 28 mm YF14-3...
  • Page 7 PARTS LIST / NOMENCLATURE DES PIÈCES / LISTA DE PIEZAS / ПЕРЕЧЕНЬ ДЕТАЛЕЙ Quantity Quantity Quantité Quantité Part / Pièce / Pieza / Деталь Part / Pièce / Pieza / Деталь Cantidad Cantidad Количество Количество YF25 YF21 YF22 YF26 YF23-3 YF27 YF28 YF24-3...

  • Page 8: Yf11

    OPTION 1: FLAT PANEL TV STAND OPTION 1: MEUBLE POUR TÉLÉVISEUR À ÉCRAN PLAT OPCIÓN 1: BASE PARA PANEL DE TV DE PANTALLA PLANA ВАРИАНТ 1: ПОДСТАВКА ПОД ТЕЛЕВИЗОР С ПЛОСКИМ ЭКРАНОМ NOTE: 2 PEOPLE ARE RECOMMENDED TO ASSEMBLE THIS FURNITURE. TO AVOID DAMAGE DURING ASSEMBLY, IT SHOULD BE ASSEMBLED ON A SOFT SURFACE.
  • Page 9 Fig. 1-2 YF13-3 YF15-3 YF14-3 YF16-3 1-4. LIFT the front frame upright, and ATTACH the Left and Right Rear Support Frames (YF15-3, YF16-3) using four 12 mm Screws (YF1) as shown above. Fully tighten all Screws. 1-4. REDRESSER le cadre avant et ATTACHER les cadres supports arrière droit et gauche (YF15-3, YF16-3) à l'aide de quatre vis de 12 mm (YF1) comme sur l'illustration ci-dessus.
  • Page 10 Fig. 1-3 YF16-3 YF17-3 YF11 YF13-3 YF15-3 YF12 YF14-3 1-5. ATTACH the CMS ® (Cable Management System) Panel (YF17-3) to the Left and Right Rear Support Frames (YF15-3, YF16-3) using four 35 mm Screws (YF4) as shown above. Tighten Screws fully. 1-6.

  • Page 11: Yf14-3

    YF16-3 YF24-3 Fig. 1-4 YF13-3 YF15-3 YF23-3 1-8. From the front, carefully PLACE the Lower Glass Shelf (YF23-3) down onto the Soft Glass Pads (YF8) along the Bottom Crossbar (YF14-3) and the Right and Left Rear Support Frames (YF15-3, YF16-3). Make sure the Glass Shelf is well supported, level, and properly in place. 1-9.

  • Page 12: Yf18

    OPTION 2: FLAT PANEL TV MOUNTING SYSTEM OPTION 2: SUPPORT DE TÉLÉVISEUR À ÉCRAN PLAT OPCIÓN 2: BASE CON SISTEMA DE SOPORTE PARA TV DE PANTALLA PLANA ВАРИАНТ 2: КОМПЛЕКТ СО СТОЙКОЙ ДЛЯ КРЕПЛЕНИЯ ТЕЛЕВИЗОРА Fig. 2-1 Fig. 2-2 YF20 YF19 YF20 (View from Rear)
  • Page 13 Fig. 2-3 YF21 YF19 YF20 YF18 YF18 YF10 YF17-3 2-3. ATTACH the Mounting Pole (YF18) to the back of the CMS ® Panel (YF17-3) using four 54 mm Bolts (YF5) as shown. Tighten Bolts fully. 2-4. SCREW in two Tilt Adjustment Knobs (YF10) through the slots in the Tilt Bracket (YF20) and into the threaded hole in the Mounting Pole (YF18) as shown.
  • Page 14 INSTALACIÓN DEL TELEVISOR / УСТАНОВКА ТЕЛЕВИЗОРА ® CAUTION: CAREFULLY DETERMINE THE CORRECT MOUNTING PROCEDURE TO PREVENT DAMAGE TO YOUR TV AND/OR BELL'O MOUNTING SYSTEM. ALWAYS REMOVE THE TELEVISION & COMPONENTS BEFORE ATTEMPTING TO MOVE THE STAND. ATTENTION : DÉTERMINER AVEC ATTENTION LA PROCÉDURE DE POSE CORRECTE POUR ÉVITER D'ENDOMMAGER LE TÉLÉVISEUR OU LE SYSTÈME DE FIXATION BELL'O ®...
  • Page 15 YF22 Fig. 2-5 YF22 TVY10 TVY9 TVY12 TVY11 TVY2 TVY6 TVY4 TVY11 TVY8 TVY1 TVY3 TVY5 2-7. PLACE your TV face-down on a flat, very soft, non-abrasive surface, taking extreme caution to not damage the face of your TV. 2-8. ATTACH each Monitor Arm (YF22) to the back of your television as shown with selected Screws and Washers. Make sure that each Washer (TVY11 or TVY12) is placed between the Screw and the Monitor Arm.
  • Page 16 Fig. 2-6 YF22 Fig. 2-7 YF21 2-9. With the help of an assistant, carefully ATTACH the TV with Monitor Arms (YF22) to the Mounting Bracket (YF21) and SECURE the Monitor Arms using two 25 mm Screw (YF6) as shown in Fig. 2-7. Tighten Screws fully. 2-9.
  • Page 17 OPTION 3: STAND WITH WALL MOUNT OPTION 3: MEUBLE AVEC SUPPORT MURAL OPCIÓN 3: BASE CON SOPORTE DE PARED ВАРИАНТ 3: ПОДСТАВКА С КРЕПЛЕНИЕМ НА СТЕНЕ CAUTION: NEVER EXCEED THE MAXIMUM LOAD CAPACITY OF 125 LBS (56.7 KG) ATTENTION : NE JAMAIS DÉPASSER LA CAPACITÉ DE CHARGE MAXIMALE DE 56,7 KG (125 LBS) ADVERTENCIA: NUNCA EXCEDA LA CAPACIDAD MÁXIMA DE CARGA DE 125 LBS (56.7 KG) ПРЕДУПРЕЖДЕНИЕ: НИ...
  • Page 18 Fig. 3-2 • Height to bottom of TV • Hauteur jusqu'au bas du téléviseur • Altura hasta la parte inferior del TV • Высота до нижней грани телевизора 3-2. MEASURE the distance from the mounting holes on the back of your television to the top and bottom edges of the television to determine the true center of the television once it will be mounted.
  • Page 19 Fig. 3-3 2.5" (64 mm) 5/32" (4 mm) INSTALLING THE WALL MOUNT IN WOOD: 3-4. DRILL four holes 2.5" (64 mm) deep using a 5/32" (or 4 mm) size drill bit in the “A”, “B”, “C”, and “D” locations noted on the Installation Template.
  • Page 20 Fig. 3-5 3" (76 mm) MOUNTING TO SOLID CONCRETE OR CINDER BLOCK: 3-4. Carefully DRILL four holes using a 5/16" (or 8mm) masonry drill bit in the “A”, “B”, “C”, and “D” locations noted on the Installation Template. NOTE: EACH HOLE SHOULD BE AT LEAST 3" (76 MM) DEEP. [FIGURE 3-5] IMPORTANT: DO NOT DRILL INTO MORTAR JOINTS! DRILL HOLES AT LEAST 1"...
  • Page 21 3-5. REMOVE the Installation Template. Fig. 3-7 3-6. If mounting into concrete, INSERT four TOGGLER ® brand Wall Anchors (YF25) into the drilled holes. [FIGURE 3-9] YF21 3-7. PLACE the Wall Plate (YF21) over the holes and SCREW in the Lag Bolts (YF26) about half way.
  • Page 22 Fig. 3-10 YF22 YF21 Fig. 3-10a 3-8. With the help of an assistant, carefully LIFT and ATTACH the TV with the Monitor Arms (YF22) to the Wall Plate (YF21). MAKE SURE both Monitor Arms are correctly attached, then SECURE the Monitor Arms using two 25 mm Screws (YF6) as shown in Fig.
  • Page 23 Garantie limitée un (1) an Ce produit de meubles Bell'O International Corporation est garanti, à l’exception du verre, à l’acheteur initial au moment de l’achat et pour une durée d’un (1) an à compter de cette date. Le verre est garanti à l’acheteur initial au moment de l’achat et pour une durée de trente (30) jours à compter de cette date. Cette garantie se limite expressément aux produits neufs achetés dans des cartons scellés à...
  • Page 24 Garantía limitada de un (1) año Se le garantiza al comprador original este producto de mueble de Bell'O International Corporation, con excepción del vidrio, durante un período de un (1) año a partir de la fecha de la compra. Se le garantiza al comprador original el vidrio durante un período de treinta (30) días a partir de la fecha de la compra. Esta garantía se limita expresamente a los productos nuevos comprados en cajas cerradas en fábrica.
